Summary of Contents for Clean Logix ALX-ABB
- Page 1 USER MANUAL MODEL: ALX-ABB Chemical Allocation Manual Air Button Box English (Original Instructions) Updated: 03/24/21...
- Page 2 User Manual for the included ALX • Distance to Devices and pumps Controller for model-specific requirements. • Connections for air 2. Using appropriate mounting hardware (not included) to install. USER MANUAL (MODEL: ALX-ABB) Page 2 of 5 Updated: 03/24/21...
- Page 3 Installation (cont.) 1. Connect regulated compressed air supply to main airline inlet. • If ALX Tower or additional ALX-ABB is to be used with the system, remove plug from tee fitting and connect additional airlines as necessary. 2. Connect air lines from solenoid devices to the air inlet check valves.
- Page 4 2. Ensure there are no air line leaks 3. Verify air regulator settings (consult ALX controller manual for recommended regulator settings) More Information Please contact Clean Logix at: (616)-438-9200 or sales@clean-logix.com USER MANUAL (MODEL: ALX-ABB) Page 4 of 5 Updated: 03/24/21...
- Page 5 VALVE PUSHBUTTON ACTUATOR GREEN/ENP, QTY. BREAKS AT 50, 100 P1537 MANIFOLD 1/4" 4-PORT 3/8" INLETS P1538 STANDOFF 10-32 X 1 F-F HEX AL P1771 CHECK VALVE, 3/8 QUICK FIT X 3/8 QUICK FIT USER MANUAL (MODEL: ALX-ABB) Page 5 of 5 Updated: 03/24/21...
