Important Safety Warning:
Read and keep these directions
Heed all warnings
Follow all instructions
Do not use this apparatus near water
Clean only with a dry cloth
Install in accordance with the
manufacturer's instructions
This installation should be made by a
qualified service person and should conform
to all local codes
See further safety instructions on page 3
INSTALLATION AND OPERATION MANUAL
CE-SETUP
IP CAMERA SETUP AND POE TESTER
The CE-SETUP provides a simple way to setup and focus PoE-powered IP cameras and
is an ideal tool for installers working with both CCTV and IT PoE-based systems. The
CE-SETUP is compatible with IEEE.802.3af and IEE.802.3at standards up to 30 W
See Figures 1 – 3 for complete installation details.
Vicon part number 8009-8246-00-00 Rev 0112
Page 1
