Summary of Contents for LionEight ELD Rider
- Page 1 Instruction Manual for Drivers ON DUTY 5538876 2 hr 6 min Connected 4 Log edits Wednesday Aug 10 11:00 11:54 60:36 05:54...
-
Page 2: Table Of Contents
Table of Contents Installation & Connection Install the ELD Rider device in your vehicle Install the ELD Rider App Login to the ELD Rider App and select a vehicle Complete Pre-Trip DVIR Populate Log Form Data 9-10 Connect your mobile device to the ELD Rider device... -
Page 3: Installation & Connection
Installation & Connection Install the ELD Rider device in your vehicle With engine off, locate the diagnostic port inside the vehicle. It is located in one of the four places: Attach the device to the diagnostic port of the vehicle. -
Page 4: Install The Eld Rider App
Installation & Connection Install the ELD Rider App For android phones and tablets download the ELD Rider App from Google Play Store. For iPhones and iPads download the ELD Rider App from the App Store. Open the ELD Rider App. - Page 5 Dashboard View After successfully login & vehicle selection, the Dashboard page is open. Use Tap to Connect bar to connect to your vehicle. 9:41 Dashboard ON DUTY 5538876 2 hr 6 min Tap to Connect 11:00 11:54 DRIVE SHIFT SHIFT 60:36 05:54 CYCLE...
-
Page 6: Complete Pre-Trip Dvir
Installation & Connection Complete Pre-Trip DVIR Start a new pre-trip inspection report by tapping the DVIR button. 60:36 05:54 CYCLE BREAK Cycle Available Tomorrow: 60:36 Logs DVIR Co-Drivers Trailer/Docs You can also Start Inspection from the left side menu by tapping the DVIR option. From DVIR view, enter the odometer value and tap Start Inspection, if you are in Off Duty or Sleeper Berth status you will be placed to On Duty status. - Page 7 Tap Add/Remove under Vehicle Defects and review each item from the list against your vehicle. Pre-Tip Post-Tip Vehicle Vin WS3KN3U33A334456 Odometer Location San Francisco Vehicle ID 8000000 Add/Remove Vehicle Defects No Defects Found If you identify a defect, select the appropriate defect in the list and enter a comment and photo.
- Page 8 If Trailer is applicable, repeat step 2 and 3 under Trailer Defects. Tap Sign and Save the Report. Location San Francisco Vehicle ID 8000000 Vehicle Defects Add/Remove No Defects Found Trailer ID 1000000 Trailer Defects Add/Remove No Defects Found Sign and Save the Report...
-
Page 9: Populate Log Form Data
Installation & Connection Populate Log Form Data Select Trailer/Docs button from your Dashboard to add the Trailer/Shipping Docs number. 60:36 05:54 CYCLE BREAK Cycle Available Tomorrow: 60:36 Logs DVIR Co-Drivers Trailer/Docs 9:41 Dashboard Trailer/Docs YARD MOVE 5538876 22 hr 46 min Wednesday, Sep 04 Connected Trailer... - Page 10 Trailers & Shipping Docs are also available through the Logs folder. From your Dashboard view, tap the icon. Select Logs. Tap the daily log at the top of the list. 9:41 Daily Logs Wednesday, Sep 04 00:00 hrs Tuesday, Sep 03 00:00 hrs Monday, Sep 02 00:00 hrs...
-
Page 11: Connect Your Mobile Device To The Eld Rider Device
Installation & Connection Connect your mobile device to the ELD Rider device Enable Bluetooth Please ensure that Bluetooth is enabled on your device before you connect to the ELD Rider device. In the main Dashboard view there is Tap to Connect bar - just below... - Page 12 An icon will appear in connection bar upon successful connection. 9:41 Dashboard ON DUTY 5538876 2 hr 6 min Connected 11:00 11:54 DRIVE SHIFT SHIFT 60:36 05:54 CYCLE BREAK Ready to Drive Once you’ve completed all of the pre-trip tasks in this section, you’re ready to drive.
-
Page 13: Record Hours Of Service
Installation & Connection Record Hours of Service When your vehicle reaches 5 MPH or greater, ELD Rider is indicating that vehicle is In Motion and your duty status will automatically change to Driving. 9:41 Dashboard Driving (05 hr 41 min) -
Page 14: Dot Inspection
DOT Inspection Inspect Logs To begin the DOT inspection tap the menu icon on the top left and select the DOT Inspection John Doe Welcome Dashboard Log in to continue 5538876 Connected Logs EMAIL Unidentified Driving 13:07 DVIR PASSWORD SHIFT DOT Inspection Settings 5:54... -
Page 15: Data Transfer
DOT Inspection Data Transfer If the officer asks for the output file tap Transfer Data Tap the Transfer Data to send the file via web service or email. 9:41 DOT Inspection Begin Inspection ELD Data Transfer Transfer ELD data upon officer request Transfer Data Select Web Service or Email transfer method. -
Page 16: Malfunction Responsibilities
Malfunction Responsibilities Carrier Responsibilities Regarding Malfunctions The carrier must: Provide drivers with an instruction sheet describing the various ELD malfunction events and record-keeping procedures (this document) Provide drivers with a supply of 8 days’ worth of blank paper driver records Repair, replace or service The motor carrier must correct the malfunction of the ELD within 8 days of discovery of the condition... -
Page 17: Eld Malfunctions
Mon, Aug 25, 10:15 AM ELD has reported Engine Synchronization compliance malfunction. Contact your manager immediately. Please stop using the ELD Rider and switch to paper logs until the ELD malfunction has been corrected. Mon, Aug 25, 10:15 AM... - Page 18 ELD has reported Timing compliance malfunction. Contact your manager immediately. Please stop using the ELD Rider and switch to paper logs until the ELD malfunction has been corrected. Mon, Aug 25, 10:15 AM ELD has reported Position compliance malfunction. Contact your manager immediately. Please stop using the ELD Rider and switch to paper logs until the ELD malfunction has been corrected.
- Page 19 Data Diagnostic ELD has identified the Power data diagnostic event. Mon, Aug 25, 10:15 AM ELD has identified the Engine synchronization data diagnostic event. Mon, Aug 25, 10:15 AM ELD has identified the Missing required data diagnostic event. Mon, Aug 25, 10:15 AM ELD has identified the Data transfer data diagnostic event.
- Page 20 Powered by...
