Above All LS Instruction Manual

SUITABLE FOR MODEL

SAFETY INSTRUCTION

READ CAREFULLY BEFORE INSTALLING FIXTURE. PLEASE KEEP THIS MANUAL FOR FUTURE USE.
Fixtures must be wired in accordance with the National Electrical Code and all applicable local codes. Proper grounding
is required for safety.
THIS PRODUCT MUST BE INSTALLED IN ACCORDANCE WITH THE APPLICATION CODE BY A PERSON
FAMILIAR WITH THE CONSTRUCTION AND OPERATION OF THE PRODUCT AND THE HAZARDS INVOLVED.
MAKE CERTAIN POWER IS OFF BEFORE INSTALLING OR MAINTAINING FIXTURE.
CHECK THAT VOLTAGE IS COMPATIBLE WITH FIXTURE DRIVER. USE APPROVED CONNECTORS FOR
ALL ELECTRICAL CONNECTIONS.
Maintenance Caution
2. For lighting controls, follow control instructions carefully.
4. Maintenance must be done by professionals.

WIRE CONNECTION

120-277V,347/480V
LINE
Black
ACL
COMMON
White
ACN
GROUND
GND
Yellow/Green
120-277V
LINE
Black
ACL(In)
COMMON
White
ACN(In)
LOAD
Black
ACL
White
ACN
GROUND
GND
Yellow/Green
Add: 1135 Thomas Busch Highway, Pennsauken, NJ 08110 Phone: 866-222-8866 E-mail: info@abovealllighting.com
Web: www.AboveAllLighting.com ©2016 ABOVE ALL, Inc. All rights reserved
Purple
DIM+
Grey
DIM-
LED
Driver
Red
Red(+)
DC(+)
Black
Black(-)
DC(-)
GND
SENSOR
DIM-
FSP-211
DIM+
Red(+)
Red
DC(+)
Black
Black(-)
DC(-)
LED
Purple
Driver
DIM+
Grey
DIM-
LS Parking Garage Light
Cap Off
Cap Off
LED Array
LED Array
Trunnion Mount
Instruction Manual
.
1
