PC/104 format Single Board PC
Document Reference
Document Issue Level
Manual covers PCBs with the following Issue
Blue Chip Technology Ltd.
Chowley Oak
Tattenhall
Chester
CH3 9EX
U.K.
Telephone: +44 (0)1829 772000
Facsimile: +44 (0)1829 772001
www.bluechiptechnology.co.uk
MICRON
User Manual
MICRON Manual
1.3
2.x
(where 'x' is any alphanumeric).
Advertisement
Table of Contents
Related Manuals for BLUE CHIP MICRON
Summary of Contents for BLUE CHIP MICRON
- Page 1 PC/104 format Single Board PC User Manual Document Reference MICRON Manual Document Issue Level Manual covers PCBs with the following Issue (where 'x' is any alphanumeric). Blue Chip Technology Ltd. Chowley Oak Tattenhall Chester CH3 9EX U.K. Telephone: +44 (0)1829 772000 Facsimile: +44 (0)1829 772001 www.bluechiptechnology.co.uk...
-
Page 2: Table Of Contents
BOARD LAYOUT .........................13 Top Surface of the PCB.........................13 Lower Surface of the PCB........................14 INSTALLATION ......................15 MOUNTING ..........................15 COOLING ............................16 CABLING.............................16 ISSUES..........................17 USING THE BOARD....................18 BIOS SETTINGS..........................18 JUMPERS............................18 LOADING OPERATING SYSTEMS & DRIVERS................18 Blue Chip Technology Limited Page 2... - Page 3 General Purpose I/O..........................34 CD-ROM Audio Input ...........................34 Ethernet Connector..........................35 VGA Connector ............................35 Dual USB Connector ..........................35 Audio Microphone Input ........................35 Audio Line Input ...........................35 Audio Line Output ..........................35 STANDARD CONNECTORS..................36 AMENDMENT HISTORY..................37 Blue Chip Technology Limited Page 3...
-
Page 4: Introduction
IMITATIONS OF IABILITY In no event shall Blue Chip Technology be held liable for any loss, expenses or damages of any kind whatsoever, whether direct, indirect, incidental or consequential, arising from the design or use of this product or the support materials supplied with this product. If this product proves to be defective, Blue Chip Technology is only obliged to replace or refund the purchase price at Blue Chip Technology's discretion according to their Terms and Conditions of Sale. -
Page 5: Related Publications
MSDOS and WINDOWS are registered trademarks of the Microsoft Corporation. CyberBlade i7 is a trademark of Trident Microsystems, Inc. VIA is a trademark of VIA Technologies, Inc. iDragon and mP6 are trademarks of Rise Technology Company. Blue Chip Technology Limited Page 5... -
Page 6: Precautions
This product meets the requirements of the European EMC Directive (89/336/EEC) and is eligible to bear the CE mark. It has been assessed operating in a Blue Chip Technology housing. However, because the board can be installed in a wide variety of chassis, certain conditions have to be applied to ensure that the compatibility is maintained. - Page 7 Failure to observe these recommendations may invalidate the EMC compliance. Warning This is a Class A product. In a domestic environment this product may cause radio interference in which case the user may be required to take adequate measures. Blue Chip Technology Limited Page 7...
-
Page 8: User Guide
Troubleshooting guide; Connector Pin-Out details. We strongly recommend that you study this manual carefully before attempting to interface with MICRON or change the standard configurations. Whilst all the necessary information is available in this manual we would recommend that unless you are confident, you contact your supplier for guidance. IT IS PARTICULARLY IMPORTANT THAT YOU READ THE SECTION 'PRECAUTIONS' BEFORE HANDLING THE BOARD. - Page 9 MICRON S INGLE OARD OMPUTER UIDE MICRON Processor Board MICRON CONNECT Development Board Blue Chip Technology Limited Page 9...
-
Page 10: Board Level Features
• 128byte user EEPROM available. • Watchdog facility. The MICRON single board PC comes with Pentium-class Rise Technology iDragon mP6 Processors running at 2.0/3.3Volts. On-board voltage regulator circuits provide the required voltages for the processor from the incoming 5 volt power supply. This device gives a high performance/ power ratio. -
Page 11: Chip Set
UIDE CHIP SET The MICRON board uses the Trident CyberBlade i7 and VIA VT82C686B chipset. This is well known and widely used in the general purpose PC marketplace. It offers a high level of integration of standard functions, and with the latest iteration, UDMA-100 gives a high performance solution. -
Page 12: Specification
Required for board operation – may be linked from +5V STBY Note that those supply rails that are not required for operation of the MICRON may be required by other plug-in boards or LCDs. 5-Volt Power Consumption 1.7 A typical, 2.0 A peak 250 MHz CPU, 128 MB SDRAM 1.6 A typical, 1.9 A peak... -
Page 13: Board Layout
OARD OMPUTER UIDE OARD AYOUT TOP SURFACE OF THE PCB IC15 Figure 1. MICRON PCB - Top View Showing Connector Positions. Pin 1 of each connector is indicated by an arrow. Connectors Ident Description Ident Description 12mm Battery holder for RTC... -
Page 14: Lower Surface Of The Pcb
MICRON S INGLE OARD OMPUTER UIDE LOWER SURFACE OF THE PCB NORTH BRIDGE Thermistor Figure 2. MICRON PCB - Underside View Showing Hot Devices and Temperature Sensor. Connectors Ident Description PC/104 connectors (both surfaces) PC/104Plus connector See the section "Micron Connectors"... -
Page 15: Installation
The MICRON CPU has to be installed at the top of a PC/104Plus stack because of its’ interconnect restrictions. It is also difficult to mount any PC/104 boards on top of MICRON because of the two obscured mounting holes not being available to take standard pillars. -
Page 16: Cooling
EMC. Lengths should be limited to the necessary minimum. Connections may be made to the MICRON board directly, using custom cables to suit the application. Alternatively, connections may be made via the optional MICRON I/O cable, or the optional MICRON CONNECT board. -
Page 17: Emc Issues
Full wire-screened cables are much more effective than those with a foil screen and drain wire. Use metal connector shells/covers, and do not allow the external screen to pass into the enclosure. Blue Chip Technology Limited Page 17... -
Page 18: Using The Board
The board contains a custom implementation of the Phoenix BIOS 4, Revision 6.1 to suit the specific hardware features. Certain combinations of BIOS settings may prevent the MICRON from working correctly. If problems or lock-ups are experienced on boot-up, clear the CMOS memory and restart. The default settings will usually work in most instances. -
Page 19: Programming The Board
BIOS set-up program, and then controlled by software using the software interrupt INT 50h. USER EEPROM The EEPROM on the MICRON unit is a NM93C46 serially programmed device. It comprises 128 bytes of user programmable memory, organised as 64 x 16 bit words. The EEPROM does not have to be completely erased before writing to a single location. -
Page 20: General Purpose I/O Lines
Carry flag clear GENERAL PURPOSE I/O LINES MICRON provides four LVTTL-compatible programmable digital input/output lines. Before the lines can be used, the GPIO function has to be enabled within the BIOS Set-up program. Once enabled, BIOS functions are available to control this facility. -
Page 21: Accessing Software 'Int 50H' Functions
AH register followed by a specific set of parameters in the other registers before executing the interrupt. For example, in C :- #include <stdio.h> #include <dos.h> #define MICRON 0x50 void main(void) union REGS regs; regs.x.ax = 0x0400; /* read eeprom data */ regs.x.bx = 0x31;... -
Page 22: Maintenance
Then slide the battery out. Replacing the battery is the reverse procedure, ensuring that the new battery is placed with the positive face up (visible). Blue Chip Technology Limited Page 22... -
Page 23: Troubleshooting Guide
Memory not fully seated in socket Action Remove and refit memory Possible Cause Add-in board requires other voltage rails (MICRON requires only 5V) Action Check power requirements of expansion board, and power supplies SYMPTOM Time and Date incorrect, loss of CMOS memory contents... -
Page 24: Micron Connectors
P26 - Screw Terminals Terminal Description -12V +12V Note: Neither of these supplies are required for operation of the MICRON board, the terminals provide power to other PCBs. 5V OUTPUT CONNECTOR TO FAN P1 - Connector: Molex 0.1” KK 3-way pin header Mating Connector: Molex 0.1”... -
Page 25: Jumpers
MICRON S MICRON C INGLE OARD OMPUTER ONNECTORS UMPERS CMOS CLEAR J1 Jumper Link Operation Normal Clear CMOS LCD PANEL SUPPLY VOLTAGE J2 Jumper Link Operation Blue Chip Technology Limited Page 25... -
Page 26: Input/Output Connectors
P23 - Connector: 50-way 0.1" pitch pin header Mating Connector: 50-way 0.1" pitch IDC socket Combination connector P23 may optionally connect to the "MICRON CONNECT" I/O board. A cable is available for this purpose. Pin 2 Pin 50 Pin 1... -
Page 27: Combined Serial Ports 1 & 2, Parallel Port, Utilities Connector
HD Activity LED Anode Reset Switch (to Ground) Ground Utilities Power Switch (to Ground) Ground External SMI (to Ground) External +3V (to Ground) External SMI: External Systems Management Interrupt. Pull to ground to interrupt. Blue Chip Technology Limited Page 27... -
Page 28: Lcd Panel Connector
See the document "LCD Connectivity" for details on individual LCD Panel types. PANEL VEE GENERATOR CONNECTOR P5 - Connector: 5-way 0.1” pitch right-angled pin header Mating Connector: 5-way SIL 0.1” socket Signal Vee IN Blue Chip Technology Limited Page 28... -
Page 29: Irda Interface
An external NTC thermistor (10 Kohm at 25ºC, ß= 3988) may be connected here. (Pin 2 is 0V) SODIMM SOCKET P9 - Connector: JEDEC standard Standard Pin Out. PC/104 CONNECTOR P8 - Connector: 104-pin PC/104 standard plug/socket Standard Pin Out. Blue Chip Technology Limited Page 29... -
Page 30: Pc/104Plus Connector
MICRON S MICRON C INGLE OARD OMPUTER ONNECTORS PC/104PLUS CONNECTOR P10 - Connector: 120-pin PC/104Plus standard plug Standard Pin Out. Blue Chip Technology Limited Page 30... -
Page 31: Micron I/Ocable
MICRON S MICRON I/O C INGLE OARD OMPUTER ABLE MICRON I/O CABLE This cable is available as an optional extra. It breaks out the cable from the Combined Serial, Parallel and Utilities ports to standard connections. PARALLEL Connector: 25-way D-type socket Standard Pin Out. -
Page 32: Micron Connect
OMPUTER MICRON CONNECT The MICRON CONNECT board is an optional board producing standard connectors for a number of the input/output functions of the MICRON board. It is generally employed as a development tool prior to application-specific enclosure and interconnecting cable design work. There is no requirement to use the CONNECT board, other than for analogue audio signals. -
Page 33: Multi-Function Interconnect
Mouse Clock Ground USB0 Data- USB0 Data+ USB1 Data- Ground USB1 Data+ GPIO0 GPIO2 GPIO1 General Purpose IO GPIO3 Ground Reset Data IN Ground Data OUT Ground Clock AC97 Audio Ground Sync Audio +5V Blue Chip Technology Limited Page 33... -
Page 34: Keyboard & Mouse
Keyboard Clock Mouse Clock Pin 1 Pin 2 Mouse Clock View on Connecting Sockets Issue 1 Micron Connect had upper and lower sockets reversed GENERAL PURPOSE I/O P4 - Connector: 8-way 0.1" pin header Mating Connector: 8-way 0.1" crimp and shell... -
Page 35: Ethernet Connector
Tip is microphone input. AUDIO LINE INPUT P9 - Connector: 3.5mm Jack-socket Mating Connector: 3.5mm Jack-plug Tip is right channel. AUDIO LINE OUTPUT P10 - Connector: 3.5mm Jack-socket Mating Connector: 3.5mm Jack-plug Tip is right channel. Blue Chip Technology Limited Page 35... -
Page 36: Standard Connectors
MICRON S INGLE OARD OMPUTER TANDARD ONNECTORS STANDARD CONNECTORS The attached guide is a general reference point for the following standard pin-outs. Standard Pin Out Blue Chip Technology Limited Page 36... -
Page 37: Amendment History
MICRON S INGLE OARD OMPUTER MENDMENT ISTORY AMENDMENT HISTORY Issue Level Issue Date Author Amendment Details 13/09/01 First Draft Issue 19/10/01 KDL/EGW Released 27/02/02 Up-Issued 29/04/02 Up-Issued 28/11/02 Micron Connect Iss 2 changes Blue Chip Technology Limited Page 37...
