Summary of Contents for Kidzmotion Tobi Junior
- Page 2 Трехколесный велосипед Tobi Junior 1. GB6675-2005 2. GB5296. 5-2006 3. GB14747-2006 4. Q /JHC001-2008 5. EN71-1A4/2004 6. EN71-2/2003E 7.EN71-3/1994 A1/2000...
- Page 4 Установка 01. Установите переднее колесо в раму 02. Установите руль Как показано на рисунке 01, поместите Как показано на рисунке 02, поместите руль в переднее колесо в раму и затяните зажим. раму и затяните зажим. 04. Установите каркас 03. Установите заднее колесо каркас...
- Page 5 06. Установите сиденье 05. Установите козырек Как показано на рисунке 06, установите Установите козырек, вставив его сверху сиденье на велосипеде, вставив его сверху, в раму, а затем закрутите. а затем закрутите. 07. Установите рулевой стержень 08. Установите зажим безопасности Установите зажим безопасности с обеих сторон и наденьте Установите...
- Page 6 Tricycle Tobi Junior KIDS TRICYCLE INSTALLATION MANUAL THE PICTURES IN THIS MANUAL ARE TO SHOW THE PRODUCT'S OPERATION AND STRUCTURE. IF THERE ARE ANY DIFFERENCES BETWEEN THE ACTUAL PRODUCT AND THE PICTURES, PLEASE TAKE THE PRODUCT INTO ACCOUNT. STANDARDS: 1. GB6675-2005 Toy safety regulations 2.
-
Page 7: Care And Maintenance
CARE AND MAINTENANCE: 1. After unpacking, the packing and protective material must be place into the dustbin. 2. Before each use, make sure that the solid parts are fastened and screws are well tied. 3. Before each use, an adult must inspect the tricycle to make sure that all parts are in good order. - Page 8 installation diagram 02. Install the handlebar. 01. Install the front wheel. As in the picture, insert the front wheel into the As in the picture, insert the handlebar into the front of the tricycle body in the direction from front wheel tube in the direction from the top to the bottom up and fix it with a clip.
- Page 9 05. Install the canopy 06. Install the seat. Insert the canopy frame into the rack from As in the picture, install the seat on the body top to the bottom and screw it tight. of the tricycle and screw it tight. 07.
