Translation of the German original
© Vonamic GmbH 2021
Configuration Manual Web Interface
VIPCOS 900 4x Up0 Gateway
L. No. 10158 (old: 704100)
communication – simple – flexible – unlimited
Subject to technical modifications
1
Advertisement
Table of Contents
Related Manuals for Vonamic VIPCOS 900
Summary of Contents for Vonamic VIPCOS 900
- Page 1 Configuration Manual Web Interface VIPCOS 900 4x Up0 Gateway L. No. 10158 (old: 704100) Vonamic GmbH Im Lipperfeld 27 46047 Oberhausen Germany Phone: +49 (0) 208 / 30 99 06 - 0 Fax: +49 (0) 208 / 30 99 06 - 99 Web: http://www.vonamic.com...
-
Page 2: Table Of Contents
....................29 Set up Relais .......................... 30 3.10 Time synchronization (NTP) ....................31 3.11 Store and restore of configuration files ................32 Subject to technical modifications communication – simple – flexible – unlimited © Vonamic GmbH 2021... -
Page 3: Introducing The Vipcos Web Interface
1. Introducing the VIPCOS Web Interface 1.1 Overview This document describes the detailed configuration of the VIPCOS 900 4x Up0 Gateway using the internal web interface. The web interface is divided into six segments Network Settings, Web / SIP settings, Device Settings, Time Synchronization, Key Configuration and Group selection. -
Page 4: How To Get Access To The Web Interface
Login: User (limited write) / admin / superadmin Password: Vonamic / Vonamic / Vonamic Note: If you are using a system that has already been configured, please use the IP address range of your system. The examples in this manual use the IP address range of the factory default. - Page 5 Check to see if there is an IP conflict issue. Clean browser cookies and temporary internet files. Check your PC settings again and repeat step 2. Subject to technical modifications communication – simple – flexible – unlimited © Vonamic GmbH 2021...
- Page 6 Read / Write Superadmin Read / Write / Password Control To get the full access, login as administrator by entering Username: Admin and Password: Vonamic. Note: If you are using a pre-configured system, please use the current passwords. If you are not sure, ask your system administrator.
-
Page 7: Distribution Of The Web Interface
Note: After saving, please wait with further settings until the browser has loaded the page completely. Some settings require a restart of the device so that the charging process can be delayed. Subject to technical modifications communication – simple – flexible – unlimited © Vonamic GmbH 2021... -
Page 8: Web / Sip Settings
Use the set password for each user level. (Default: Vonamic) SIP Proxy: IP address of the SIP server. Stun Server: IP address of the stun server. Subject to technical modifications communication – simple – flexible – unlimited © Vonamic GmbH 2021... -
Page 9: Device Settings
2.3 Device Settings NF Test: Setting the time for the recurring self-test of the audio peripherals. Possible settings between 1 and 1440 minutes (24 hours) Subject to technical modifications communication – simple – flexible – unlimited © Vonamic GmbH 2021... -
Page 10: Time Synchronization
2.4 Time Synchronization NTP Server: IP address of the NTP server. Date / Time: current date and time display. (no automatic refresh) GMT: Time Zone. Subject to technical modifications communication – simple – flexible – unlimited © Vonamic GmbH 2021... -
Page 11: Port 1 - 4 Configuration
Volume setting of the internal loudspeaker in dB. (Max. 63) RelaisMode: Setting the operating mode of the internal 230VAC / 10A relay. (On, Off, Answer, Online) Subject to technical modifications communication – simple – flexible – unlimited © Vonamic GmbH 2021... - Page 12 SIP calls. The last incoming unknown number is stored in the assigned key and can therefore be answered and called back. (Requires SIP server registration) Subject to technical modifications communication – simple – flexible – unlimited © Vonamic GmbH 2021...
- Page 13 Enter the phone number of the phone you want to reach here. Hang up: Terminate a telephone connection. Press to end a phone call. Partyline: Live announcement to a dynamic group or party Line. Subject to technical modifications communication – simple – flexible – unlimited © Vonamic GmbH 2021...
-
Page 14: Group Selection
Chapter 3 contains a description of this function. Subject to technical modifications communication – simple – flexible – unlimited © Vonamic GmbH 2021... -
Page 15: Configuration Description
First create an environment as described in chapter 1.2 and get access to the web interface of first V900: Cat.5e Cat.5e 192.168.100.91 / 192.168.100.90 / 255.255.255.0 255.255.255.0 192.168.100.250 / 255.255.255.0 Subject to technical modifications communication – simple – flexible – unlimited © Vonamic GmbH 2021... -
Page 16: Set And Adjust Ip
A second device is required for later examples. Please repeat the previous steps and set the IP address / subnet mask of a second V900 to 192.168.100.65 / 255.255.255.0. Subject to technical modifications communication – simple – flexible – unlimited © Vonamic GmbH 2021... -
Page 17: Setup And Adjust Id
A second device is required for later examples. Please repeat the previous step and set the device ID of the second V900 Port to 9002@local.net. Subject to technical modifications communication – simple – flexible – unlimited © Vonamic GmbH 2021... -
Page 18: Determine Device Ip-Address (Troubleshooting)
0 or a very low value, it can give the impression that the connection has not been established. We therefore recommend setting a volume of: Mic. Vol(dB): 45 (max. 72) Spk. Vol(dB): (max. 63) Subject to technical modifications communication – simple – flexible – unlimited © Vonamic GmbH 2021... -
Page 19: Direct Call Connection
If you now hold down the button 1 on the device of Port 1, the device establishes a unicast connection to the device with ID 9002 (Port 2) and maintains the connection for the duration of the button press. Subject to technical modifications communication – simple – flexible – unlimited © Vonamic GmbH 2021... -
Page 20: Group Call Connection
A total of 250 groups are available in the VIPCOS system. Each VIPCOS device can be a participant in all groups, including several at the same time. Subject to technical modifications communication – simple – flexible – unlimited © Vonamic GmbH 2021... -
Page 21: Set Up A Group Call
10 and hold the connection for the duration of the button press. All devices that are participants in group 10 are now addressed. Subject to technical modifications communication – simple – flexible – unlimited © Vonamic GmbH 2021... -
Page 22: Sip Connection
• RFC4566 compliant SDP (Session Description Protocol) • „Loose routing” and „strict routing” • „Early Media support” • „Offer/Answer” (RFC3264) • STUN Client (NAT traversal) Subject to technical modifications communication – simple – flexible – unlimited © Vonamic GmbH 2021... -
Page 23: Sip Server Registration
RFCs and repeat steps 1 - 4 or contact us at support@vonamic.com. When registration is successfully completed, you can configure SIP calls. Subject to technical modifications communication – simple – flexible – unlimited © Vonamic GmbH 2021... -
Page 24: Set Up An Outgoing Sip Connection
V900 loudspeaker and the connection will be terminated. You can actively end the call by executing the "Hangup" function on key 4. Subject to technical modifications communication – simple – flexible – unlimited © Vonamic GmbH 2021... -
Page 25: Set Up An Incoming Sip Connection
The key number you enter in this field must be unconfigured and is then used to store the last unknown number. The call function of the corresponding key is automatically switched to "SIP Call". Subject to technical modifications communication – simple – flexible – unlimited © Vonamic GmbH 2021... -
Page 26: Party Line Connection
The button becomes active as soon as the corresponding device has been added to the party by the master. Holding the button starts a group call to the current party. Subject to technical modifications communication – simple – flexible – unlimited © Vonamic GmbH 2021... -
Page 27: Set Up 10W / 40W Amplifier
Every further answer resets the activation timer. After the timer has expired, the additional amplifier is automatically activated again. Subject to technical modifications communication – simple – flexible – unlimited © Vonamic GmbH 2021... -
Page 28: Keypad
If you have purchased a V615 industrial call station with keypad from Vonamic GmbH, the hardware and software modification has already been done by the manufacturer. If you have carried out the conversion yourself, make sure that the connector to the keypad is correctly inserted and that the keypad is screwed in securely. -
Page 29: How To Use The Keypad
If you want to use the keypad to connect to a call station that is already assigned a connection to another call station, this status is signaled by a permanent light on the "Dial" button (assigned message). Subject to technical modifications communication – simple – flexible – unlimited © Vonamic GmbH 2021... -
Page 30: Set Up Relais
Puts the relay in the working position for the duration of an outgoing or incoming connection. Online: Puts the relay in the working position for the duration of the successful registration at the SIP server. Subject to technical modifications communication – simple – flexible – unlimited © Vonamic GmbH 2021... -
Page 31: Time Synchronization (Ntp)
GMT (Greenwich Mean Time) in the "GMT" field (e.g. for Germany +1). Confirm your entry with "Submit". Now the current date and time is displayed next to "Date / Time": Subject to technical modifications communication – simple – flexible – unlimited © Vonamic GmbH 2021... -
Page 32: Store And Restore Of Configuration Files
IP address. In this case you have to enter the new address in your browser line in order to be able to call up the device website. Subject to technical modifications communication – simple – flexible – unlimited © Vonamic GmbH 2021...
