Pollux Series - 50M CXP About OZRAY Co., Ltd. Founded in 1984, OZRAY is a Machine solution company that has been coexisting along with the history of the Korean machine vision system. Our company provides cameras, interface, library, machine vision components which is part of the optical machine system and technical service.
OZRAY Pollux Series - 50M CXP 1 Introduction The Pollux CoaXPress(CXP) series is a family of high-speed CMOS area scan monochrome cameras designed for a broad range of applications. Table 1 shows the camera models covered in this manual. Model...
OZRAY Pollux Series - 50M CXP 1.2 Sensor Specifications Specifications PX50M30MCP Sensor CMOSIS CMV50000 Resolutions (Active Pixels) 7920 x 6004 36.43 x 27.61 mm Optical Format (diagonal : 45.71mm) 4.6 x 4.6 μm Pixel Pitch Full Well Charge >14500 e- Conversion Gain 0.27 DN/e-...
OZRAY Pollux Series - 50M CXP 2 Mechanical Camera housings are made with high precision from machined aluminum. Mechanical drawings are shown below Figure 1. Figure 1. Mechanical drawings Page 7 of 24 Manual 1.5...
OZRAY Pollux Series - 50M CXP 2.1 Mechanical Specifications Summary of mechanical specifications are shown below Table 3. Specification Description Size 80 mm x 80 mm x 43.3 mm Weight 400 g (no lens) Mounting Holes Sides : 8x M4x0.7 Front : 4x M4x0.7...
OZRAY Pollux Series - 50M CXP 2.3 Power Connector The Pollux CoaXPress cameras powered using a 12-24V ± 10% DC power source. The power connector is shown in Figure 3, and the pinout is shown in Table 4. • Connector type: HR10A-10P-12 (male) •...
OZRAY Pollux Series - 50M CXP 3 Power Over CoaXPress (PoCXP) The Pollux CoaxPress Protocol cameras comply with “Power over CoaXPress” which enables power to be supplied to the camera through the CoaXPress cables. Power must be supplied via both CoaXPress cables in order to utilize the PoCXP capabilities.
OZRAY Pollux Series - 50M CXP 3.2 Trigger Input Design There are two input triggers and an output trigger on the power connector (pin 5, 7 and 9). The inputs and output are connected to Opto-islolated I/Os in the camera, with an input/output voltage range of 2.5 V to 5.0 V.
OZRAY Pollux Series - 50M CXP 3.3 LED Status Indicator A tri-color (orange/green/red) LED on the back of the camera is used to indicate operational status. Table 6 summarizes the operating states indicated by the LED. LED State Description Slow flash alternate Red/Orange...
Page 13
OZRAY Pollux Series - 50M CXP 틀린 부분 Figure 5. Installation using a power supply 3. If you are using PoCXP Frame Grabber: a. Plug one ends of the other two coax cables into CH3, and CH4 of the CXP connector on the camera and the other ends of the coax cables into the CH3 and CH4 of the CXP Frame Grabber respectively.
Page 14
OZRAY Pollux Series - 50M CXP Figure 6. Installation using PoCXP Page 14 of 24 Manual 1.5...
OZRAY Pollux Series - 50M CXP 4 Camera Functions 4.1 CoaXPress Output Format The CoaXPress downlink outputs can run at CXP 6-4 (25 Gbps). The frame rate will automatically be adjusted to reflect the change in output bandwidth as shown in table 7.
OZRAY Pollux Series - 50M CXP 4.2 Frame Rate and Exposure The frame rate in free-run exposure mode is controlled with the FrameRate command. The frame period is specified in microseconds. The minimum frame period of the camera (maximum frame rate) is determined by the output format and the resolution.
OZRAY Pollux Series - 50M CXP 4.3 Camera Mode The exposure mode of the camera is controlled using the Camera Mode command, and there are three options: • Free-running • External Trigger Timed • External Trigger Width 4.3.1 Free-running In this mode, a rising edge of internal trigger the start of integration and readout.
OZRAY Pollux Series - 50M CXP 4.3.2 External Trigger Timed In this mode, a rising edge on the synchronization pin is used to trigger the start of integration and readout. The integration time is defined by a Exposure Time Command. The sensor autonomously integrates during this predefined time, after which the GLOB starts and the image array is readout sequentially.
OZRAY Pollux Series - 50M CXP 4.3.3 External Trigger Width In edge-triggered level-controlled exposure mode the exposure of the frame is controlled by the active state of the input trigger. The frame period and exposure commands have no effect in this mode. Timing for this mode is shown in Figure 9.
OZRAY Pollux Series - 50M CXP 4.4 Image Region of Interest The Image Region of Interest (ROI) feature allows you to specify a portion of the sensor array. You can acquire only the frame data from the specified portion of the sensor array while preserving the same quality as you acquire a frame from the entire sensor array.
Page 21
OZRAY Pollux Series - 50M CXP ROI Offset X ROI Width ROI1 Offset Y ROI1 Height ROI2 Offset Y ROI2 Height ROI3 Offset Y ROI3 Height ROI4 Offset Y ROI4 Height 7920 Figure 10. ROI Example Page 21 of 24...
OZRAY Pollux Series - 50M CXP 4.5 Offset and Gain 4.5.1 Black Level Offset The outputs from the sensor have a black level offset which is programmed using the Black Level Offset command, respectively. For optimum image quality these values are calibrated on every camera at the various output formats.
