B088XWZ95X
Gate Latch - Stainless Steel, Black
Seguro para Puertas - Acero Inoxidable, Negro
Clenche de Grille - Acier Inoxydable, Noir
ゲートラッチ - ステンレス、黒
This product contains small items that could be a choking hazard if swallowed. Keep these items away from young children.
CAUTION
• Make sure these instructions are read and completely understood before attempting installation.
If you are unsure of any part of this installation, please contact a professional installer for assistance.
3/32" (1.6 mm)
Step 1: Place hook into the eyelet and hold in place in the desired installation location. Ensure hook can freely
enter and exit the hook. Mark holes with pencil.
NOTICE
The hook should be installed on the door and the eyelet on the molding or wall. For best fit,
install the hook first and then the eyelet.
Step 2: Using a drill and 3/32" (1.6 mm) drill bit, drill pilot let holes on each of the pencil marks. Do not drill
through the door or molding all of the way.
NOTICE
Pilot holes only need to be the length of the screw.
NOTICE
Wood doors require wood drill bits and metal doors require metal drill bits.
CAUTION
Use eye protection when drilling into doors to prevent injury from flying debris.
Step 3: Using a philips head screwdriver, install and tighten all screws "clockwise".
Step 4: Installation complete.
1.5"
4.7"
A (1x)
B (1x)
0.8"
C (4x)
01
