Notes on safe use of door operators
There is a risk of serious or fatal injury if the ismartgate device is not used correctly.
ØKeep children away from the ismartgate and the user interface.
ØDo not drive through the door until it has fully opened.
ØObserve all warnings and safety information in the installation and operating manual for the operator.
INSTRUCTIONS SETUP
Notes on safe operation of the ismartgate device.
The ismartgate device may only be used on the operator in
combination with a photocell.
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Mini and is the answer not in the manual?

Questions and answers

Summary of Contents for Ismartgate Mini

  • Page 1 Notes on safe use of door operators Notes on safe operation of the ismartgate device. There is a risk of serious or fatal injury if the ismartgate device is not used correctly. The ismartgate device may only be used on the operator in combination with a photocell.
  • Page 2: Table Of Contents

    Page 12 Initial operation Page 3 Intended use Page 15 Ismartgate Reset Page 3 EU Declaration of Conformity Page 29 Ismartgate already configured Page 4 Technical Information Page 32 Garage installation Page 4 Functional description Page 33 Garage Motor installation...
  • Page 3: Legal Information

    INSTRUCTIONS SETUP LEGAL INFORMATION Intended use The ismartgate may be used in combination with any compatible garage door or gate operator. FCC / IC Statement (USA / Canada) With an established network connection, the door can be opened and closed, the current door status and the door status queried, settings can be made and administrators via the user interface (Apple, Android).
  • Page 4: Technical Information

    The ismartgate serves as an interface between end devices such as Tablet or Smartphone (Android and iOS) and any compatible garage door or gate operator. Up to one (1) door operator to one (1) ismartgate MINI. The ismartgate device is then connected to a network using Wi-Fi or LAN.
  • Page 5: Interfaces And Leds

    INSTRUCTIONS SETUP ismartgate MINI Interfaces & LEDS BACK VIEW LEFT SIDE RIGHT SIDE FRONT VIEW Power Light Wall Hanger Network RGB Status Light Light USB Port (Type A) DC Power Connector (5V2A) 2 pole connector (for pre-assembled cable 2 pole connector (for wired sensor...
  • Page 6: What's In The Box

    INSTRUCTIONS SETUP WHAT’S IN THE BOX Garage & Gate Packs Wireless Sensor LR1/Type-N 1.5V ismartgate MINI 1x Connection Cables (ISG-TWS) Batteries ismartgate MINI Garage Power Supply Quick Start Guide...
  • Page 7 INSTRUCTIONS SETUP WHAT’S IN THE BOX Garage & Gate Packs Wireless Sensor LR1/Type-N 1.5V ismartgate MINI 1x Connection Cables (ISG-GWS) Batteries ismartgate MINI Gate Power Supply Quick Start Guide...
  • Page 8 INSTRUCTIONS SETUP WHAT’S IN THE BOX Garage & Gate Packs Wired Sensor ismartgate MINI 1x Connection Cables Power Supply (ISG-WDS) ismartgate MINI Wired Quick Start Guide...
  • Page 9: Considerations For Installation

    INSTRUCTIONS SETUP CONSIDERATIONS FOR INSTALLATION Set Up environment We recommend programming the ismartgate in a room close to home main Wi-Fi router, in a clean surface like a desk. It is also recommended to have both a Smartphone and PC. Finally make...
  • Page 10 INSTRUCTIONS SETUP CONSIDERATIONS FOR INSTALLATION ismartgate Placement Make sure ismartgate is placed in the area with Door Motor + ismartgate 50% or more Wi-Fi signal strength. Wall Button + ismartgate Wi-Fi must be 2,4Ghs-802.11 b/g/n (NOT 5Ghz 802.11 Device can be placed next to...
  • Page 11: Download The App

    INSTRUCTIONS SETUP PROGRAMMING ISMARTGATE Download APP (ismartgate Access) Download the “ismartgate Access” APP for your iPhone/iPad or for your Android phone.
  • Page 12: Initial Operation

    INSTRUCTIONS SETUP PROGRAMMING ISMARTGATE Open ismartgate access app On your phone, look for the logo of the Wait for the introductory screen to go Press “No, Thanks” ismartgate app and click on it to open the away.
  • Page 13 INSTRUCTIONS SETUP PROGRAMMING ISMARTGATE Start Configuration Press “Start Configuration”. Power up the ismartgate. Afterwards, Wait 2 minutes. Then press “Next”. select the option “Model Mini”.
  • Page 14 INSTRUCTIONS SETUP PROGRAMMING ISMARTGATE Check connection light color blue green Connection light blinks Connection light blinks Connection light blinks Please go to page 18 Please go to page 15 Please go to page 29...
  • Page 15: Ismartgate Reset

    INSTRUCTIONS SETUP RESETTING ISMARTGATE The device must be powered ON With the help of a paperclip, press the RESET button for about 10 seconds.
  • Page 16 INSTRUCTIONS SETUP RESETTING ISMARTGATE The device must be powered ON CONNECTION DEVICE STATUS STATUS To check RESET has been successful, turn the ismartgate device to the front and check that “Connection & Status” lights are off.
  • Page 17 CONNECTION STATUS DEVICE STATUS BLUE GREEN Wait 2 minutes until you see blinking: ● Status green light ● Power red light ● Wi-Fi blue light Then re-program the ismartgate. If RESET is successful, re-program the ismartgate device go to page...
  • Page 18 INSTRUCTIONS SETUP PROGRAMMING ISMARTGATE Connect to the Wi-Fi network generated by the ismartgate device.
  • Page 19 INSTRUCTIONS SETUP PROGRAMMING ISMARTGATE Enable the wireless network (Wi-Fi) connection Go to Settings on your phone. Select “Wi-Fi” (aka. WLAN) Settings. Enable “Wi-Fi” settings on your phone if you haven’t done so yet.
  • Page 20 INSTRUCTIONS SETUP PROGRAMMING ISMARTGATE Connect to the Wi-Fi network generated by the ismartgate device. If you don’t find the “iSG-Mini-xxxxxxxxx” network, please check the Wi-Fi Connection lights: The Wi-Fi light blinks The Wi-Fi light blinks another color. GREEN. Please send us an email at: Please Reset the device.
  • Page 21 INSTRUCTIONS SETUP PROGRAMMING ISMARTGATE Connect to the Wi-Fi network generated by the ismartgate device. Please know that this message will ONLY appear if you are using an Android device. A message will “pop-up” indicating the You can check you successfully connected “isg-Mini-XXXXXXXXXX”...
  • Page 22 “Refresh” button. If it is still not there, please check the Wi-Fi lights: go to page Open the ismartgate access app again. You will be back to the same step you The app will now look for devices to were before connecting to connect.
  • Page 23 INSTRUCTIONS SETUP PROGRAMMING ISMARTGATE Configure your ismartgate device and sensor 1. Choose your preferred language Define what door type you have: Choose the Sensor type. Check 2. Choose the device’s name carefully! 3. Choose the door’s name 1. Garage means you will slide up to open (down to close) 2.
  • Page 24 INSTRUCTIONS SETUP PROGRAMMING ISMARTGATE Configure your ismartgate device Please, keep in mind that the Remote Access feature takes 10 minutes to be available to use. 1. Choose a password for your admin user (If you leave the 1. Choose the correct Wi-Fi Network (2.4GHz) Enter the Sensor ID.
  • Page 25 INSTRUCTIONS SETUP PROGRAMMING ISMARTGATE Connection status light The device is successfully The device is successfully The device has been setup in The device can't connect to the selected connected to the selected Wi-Fi connected to the selected Wi-Fi Access Point mode (Standalone)
  • Page 26 INSTRUCTIONS SETUP PROGRAMMING ISMARTGATE Connect your phone to the same network as the ismartgate Go to Settings on your phone. Select “Wi-Fi” (aka. WLAN) Settings. Enable “Wi-Fi” settings on your phone if you haven’t done so yet.
  • Page 27 INSTRUCTIONS SETUP PROGRAMMING ISMARTGATE Connect your phone to the same network as the ismartgate From the list of available Wi-Fi networks, Check that you are successfully connected select the one where you already connected to that network. For that, look for the your ismartgate device.
  • Page 28 Final connection to the ismartgate If you see the above screen, your If you see the above picture, it means ismartgate is successfully connected to the ismartgate is not connecting to your your WiFi network. smartphone. Please go to Page 32...
  • Page 29: Ismartgate Already Configured

    INSTRUCTIONS SETUP PROGRAMMING ISMARTGATE Connect to an already configured ismartgate device (Wi-Fi light steady GREEN) On your phone, look for the logo of the Wait for the introductory screen to go Press “Join existing”. ismartgate app and click on it to open the...
  • Page 30 INSTRUCTIONS SETUP PROGRAMMING ISMARTGATE Connect to an already configured ismartgate device Contact to your ismartgate Administrator Wait for your phone to connect with to ask for: your ismartgate. 1) UDI 2) Login 3)Password Once you have these credentials, press “Done“.
  • Page 31 INSTRUCTIONS SETUP PROGRAMMING ISMARTGATE Final connection to the ismartgate already configured If you see the above screen, your If you see the above picture, it means ismartgate is successfully connected to the ismartgate is not connecting to your your WiFi network.
  • Page 32: Garage Installation

    GARAGE WALL PUSH OPENER BUTTON We recommend wiring the ismartgate We recommend wiring the ismartgate to directly to your Garage Door Opener if your wall mounted push button if you you don’t have push buttons or if power have power outlets nearby (less than 30 outlets aren’t close to push buttons.
  • Page 33: Garage Motor Installation

    INSTRUCTIONS SETUP INSTALLING ISMARTGATE GARAGE MOTOR INSTALLATION GARAGE DOOR OPENER Installation for 1 Door...
  • Page 34 INSTRUCTIONS SETUP INSTALLING ISMARTGATE GARAGE MOTOR PLACEMENT AND INSTALLATION ON TOP OF THE MOTOR ON THE SIDE OF THE MOTOR UNDER THE MOTOR To know how to connect the ismartgate to your specific motor, please go to the Compatibility Checker: https://ismartgate.com/compatibility-checker/...
  • Page 35: Garage Button Installation

    Unscrew the push button from the wall. Unscrew (not completely) the 2 screws from your opener. Wire the ismartgate outputs to the screws on your push Screw your push button back. button. Polarity does NOT matter. Then screw again. Installation for 1 Door...
  • Page 36: Gate Installation

    fit inside the gate operator / control box, we strongly recommend to put the ismartgate device inside an ismartgate IP waterproof enclosure To know how to connect the ismartgate to your specific motor, please go to the Compatibility Checker: https://ismartgate.com/compatibility-checker/...
  • Page 37: Wireless Gate Kit Sensor (Gws)

    INSTRUCTIONS SETUP ISMARTGATE WIRELESS SENSORS ISMARTGATE WIRELESS MAGNETIC SENSOR (GWS) INCLUDED IN THE GATE KIT Transmitter: 2401 Mhz Type: Magnet temperature indicator: included Range: 50 ft Operating temperature: -25ºC / 70ºC Batteries: 2x Type-N (1.5V) Life span: 18 months Waterproof: Yes...
  • Page 38 INSTRUCTIONS SETUP ISMARTGATE WIRELESS SENSORS ISMARTGATE WIRELESS MAGNETIC SENSOR (GWS) INCLUDED IN THE GATE KIT Test the sensor: move the sensor as the images above and see if the ismartgate status light (yellow) blinks rapidly...
  • Page 39 INSTRUCTIONS SETUP INSTALLING ISMARTGATE SENSORS COMPATIBLE GATES WITH THE GWS SENSOR SLIDING SWING FOLDING SENSOR PLACEMENT: SENSOR PLACEMENT: SENSOR PLACEMENT:...
  • Page 40 INSTRUCTIONS SETUP INSTALLING ISMARTGATE SENSORS COMPATIBLE GARAGE DOORS WITH THE GWS SENSOR ROLLER SIDE-SECTIONAL SWING SENSOR PLACEMENT: SENSOR PLACEMENT: SENSOR PLACEMENT:...
  • Page 41: Wireless Garage Kit Sensor (Tws)

    INSTRUCTIONS SETUP ISMARTGATE WIRELESS SENSORS ISMARTGATE WIRELESS TILT SENSOR (TWS) INCLUDED IN THE GARAGE KIT Transmitter: 2401 Mhz Type: Gravity Sensor temperature indicator: included Range: 50 ft Operating temperature: -25ºC / 70ºC Batteries: 2x Type-N (1.5V) Life span: 18 months...
  • Page 42 INSTRUCTIONS SETUP ISMARTGATE WIRELESS SENSORS ISMARTGATE WIRELESS TILT SENSOR (TWS) INCLUDED IN THE GARAGE KIT Test the sensor: move the sensor as the images above and see if the ismartgate status light (yellow) blinks rapidly...
  • Page 43 INSTRUCTIONS SETUP INSTALLING ISMARTGATE SENSORS COMPATIBLE GARAGE DOORS WITH THE TWS SENSOR SIDE-SECTIONAL ROLLER SENSOR PLACEMENT: SENSOR PLACEMENT:...
  • Page 44: Wired Sensor (Wds)

    INSTRUCTIONS SETUP INSTALLING ISMARTGATE SENSORS ISMARTGATE WIRED MAGNETIC SENSOR (WDS) INCLUDED IN THE MINI WIRED KIT Output: Normally Open (NO) Max. switching voltage: 100V dc Max. contact rating: 10W Max. switching current: 0.5A Max. carrying current: 1.0A Temperature: -20ºC / 80ºC...
  • Page 45 INSTRUCTIONS SETUP INSTALLING ISMARTGATE SENSORS ISMARTGATE WIRED MAGNETIC SENSOR PLACEMENT ON A ROLLER GARAGE DOOR A) Installation on a Roller Door Attach your magnetic wired sensors to your roller door as per drawing below. MAKE SURE THE GAP BETWEEN PART B AND PART A IS LESS THAN 1.25 INCH (3 CM).
  • Page 46 INSTRUCTIONS SETUP INSTALLING ISMARTGATE SENSORS ISMARTGATE WIRED MAGNETIC SENSOR PLACEMENT ON A SECTIONAL GARAGE DOOR B) Installation on a Sectional Door Attach your magnetic wired sensors to your Sectional Door as per drawing below. MAKE SURE THE GAP BETWEEN PART B AND PART A IS LESS THAN 1.25 INCH (3 CM).
  • Page 47 INSTRUCTIONS SETUP INSTALLING ISMARTGATE SENSORS ISMARTGATE WIRED MAGNETIC SENSOR PLACEMENT ON A SLIDING GATE C) Installation on a Sliding Gate Attach your magnetic wired sensors to your sliding gate as per drawing below. PLACE THE SENSOR IN THE MIDDLE PART OF YOUR SLIDING GATE.
  • Page 48 INSTRUCTIONS SETUP INSTALLING ISMARTGATE SENSORS ISMARTGATE WIRED MAGNETIC SENSOR PLACEMENT ON A SWING GATE D) Installation on a Swing Gate Attach your magnetic wired sensor to your swing gate as per drawing below. MAKE SURE THE GAP BETWEEN PART B AND PART A IS LESS THAN PLACE THE SENSOR IN THE MIDDLE PART OF YOUR SLIDING GATE.
  • Page 49 CONGRATULATIONS! Your installation is done. www.ismartgate.com...
