ICHECKEY XMZ01 Manual

Smart Wireless Car Charger
Manual

Product Introduction

Thank you for ordering this device. It is a smart wireless car
charging phone holder, supports scanning and auto-tracking
coils to charging different brands smartphones. Make you easily
experience the fun of wireless smart digital products. Please
read this manual carefully before operating this device and
keep it for future reference.

Product structure diagram

1.Movable alignment wireless sensing area 2.Work indicator
3.Touch button 4.Type-C interface 5.Car air vent clip
6.Multi angle rotating ball 7.Fixing nut 8.Air vent clip nut
9.Air vent clip support

Instructions

Air vent clip fixing method

2.Rotate and tighten the Air
1.Loosen the air vent clip nut, and
vent clip nut
insert the clip into the air conditioner
blade
3.Insert the Type-c data cable to 4.Place the phone on the holder,
the port, the clamp arms will the arm will auto close and lock,
automatically open. and then auto-scanning the coil
and charging
Electric clamp arm, please don't take out the phone forcibly by hand
Touch the button on the top of the Memory function: after the first
car holder when necessary, the coil alignment, it will charge
clamp arms will automatically open immediately if place the same
phone on the device

Product parameters

Input:
Power:
Receiving distance:
Product weight: Bare metal 182g With clip 205g
NOTE:
* Keep out of reach of children.
* Do not use under wet conditions.
* Please do not make any change to the product by yourself.
* Please avoid a strong collision of the product.
* Do not disassemble and repair the product if you are not a professional.
* Do not use external force to move the clamp arm.
* The product needs to be equipped with QC2.0/QC3.0 and other formally
certified car chargers to fit.
* The product uses the principle of wireless charging and capacitive sensing
to make charging more convenient.
* The product has a built-in battery. Please touch the button to open the clip
arm after charging for 5 minutes and disconnecting the power.

Installation steps

1.Please put the rotary ball of the car phone holder into the fixing nut first;
2.Then press the rotary ball and nut into the car phone holder;
3.Finally, tighten the nut according to individual needs.
The product has a foreign body detection function. It will affect
the wireless charging usage if equipped with ring holders, metal
objects, or other stuff that increases the phone thickness.
