Elipta Apollo 150 Technical Data Sheet

E94150W - Elipta Apollo 150 Spotlight
Part code
Diffuser
Dimensions (mm)
Cable length (mm)
Construction
Finish
Class
IP rating
Beam angle
Maximum wattage
Lamp base
Lamp included
Dimmable
Input voltage
Net weight (g)
Gross weight (g)
Warranty
Manufactured in accordance with
Origin of manufacture
Installation notes
Ensure mains supply is isolated prior to installation of this
product.
Unscrew the front plate and insert lamp. Apply small amount of
grease to the screws and secure front plate to the body of the
fitting.
Recommended 12 fittings per circuit.
Refer to the instruction manual for further guidance.
Note – This product must be installed by a qualified electrician.
Spike and accessories sold separately.
E94150W
Clear
251x223x210
2000
Grey Powder Coated
Aluminium/Borosilicate Glass
Grey Powder Coat
Class I
IP65
60°
Metal Halide – 150W Max
G12 single ended
No
No
240V 50Hz
4660
4800
2 Years
BS EN 60598
PRC
