- Page 1 Garnet ADSL Modem PCI GAN-1030 User’s Guide ver 3.3 All rights reserved. Passing on and copying of this document, use and communication of its contents not permitted without written authorization from Garnet Systems Co., Ltd. All specifications are subject to change without notice.
- Page 2 FCC NOTICE THIS DEVICE COMPLIES WITH PART 15 OF THE FCC RULES. OPERATION IS SUBJECT TO THE FOLLOWING TWO CONDITION: (1) THIS DEVICE MAY NOT CAUSE HARMFUL INTERFERENCE, AND (2) THIS DEVICE MUST ACCEPT ANY INTERFERENCE RECEIVED, INCLUDING INTERFERENCE THAT MAY CAUSE UNDERSIRED OPERATION. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules.
-
Page 3: Table Of Contents
............................1.3 S PECIFICATIONS ..........................CHPATER 2. INSTALLATION 2.1 B EFORE NSTALLATION ......................2.2 D ELIVERY HECK ........................2.3 GAN-1030 PCI C NSTALLATION .................. 2.4 W 98 SE S INDOWS OFTWARE NSTALLATION ..............2.5 R DSL N UNNING THE ARNET... -
Page 4: Chapter 1. Overview
Modem supports either G.992.1(G.dmt) or Splitterless G.992.2(G.lite) standards via software upgrades. Garnet ADSL Modem is suitable to be installed into PC, with Plug and Play function. 1.2 Features Using Garnet ADSL Modem, you will experience stable, high speed Internet access and can connect to other multimedia service networks that ADSL delivers over existing PSTN copper wires. - Page 5 ☞ ☞ ☞ ☞ gauge, PC specification and other network environments. Trademark Notification ☞ ☞ ☞ ☞ Garnet is a registered trademark of Garnet Systems Co., Ltd. ▶ ▶ ▶ ▶ ™ Windows and Internet Explorer is a registered trademark of Microsoft ▶...
- Page 6 GARNET GAN-1030 Internet ADSL Modem Modem DSLAM...
- Page 7 GARNET GAN-1030 Chapter 2. Installation 2.1 Before Installation Please be advised that if you do not yet subscribe phone service, it is impossible to get ADSL service. In this case, please contact your local service provider to have new telephone service.
- Page 8 GARNET GAN-1030 F F F F ollowing materials are provided in the package. ☞ ☞ ☞ ☞ A. Garnet ADSL Modem GAN-1030 B. Driver CD C. RJ 11 cable D. User’s Guide A micro filter is built in the modem. If you have two or more phones in one phone ☞...
-
Page 9: Gan-1030 Pci C
PSTN 2.3 ADSL Modem Installation EXchange 2.3 GAN-1030 PCI Card Installation 1. Turn off your computer and all attached peripheral devices (printer, monitor, etc.) and unplug them from the electrical outlet. CAUTION : To avoid risk of electric shock, make sure your computer and all peripheral devices are turned off and unplugged. - Page 10 GARNET GAN-1030 6. Carefully replace the computer cover in accordance with the instructions in your system's user's guide. 7. There are two modular telephone jacks on the bracket of the modem which connect the modem to a telephone line and to a telephone handset (optional: for users subscribed both ADSL and telephone service only).
- Page 11 Peripheral, and PCI ADSL LAN Adapter. Garnet Software Installation After the Garnet hardware has been installed and the PC cover replaced, turn the power on. Windows will detect Tigris as new hardware and will prompt you to install the related drivers. You should have the Garnet and Windows 98 SE CD-ROMs ready.
- Page 12 GARNET GAN-1030 1. Add New Hardware Wizard will automatically pop up. Click next. 2. Click Search for the best driver.. and click Next to proceed.
- Page 13 GARNET GAN-1030 3. Insert installation driver CD and click Browse and select the directory according to the service protocol available by the ADSL service provider and O/S in your computer system. 4. Correct driver program is found. Click Next in this picture.
- Page 14 GARNET GAN-1030 5. Click Finish in this picture. Windows will direct next steps. 6. Windows is searching for the driver installation program required by the device. 7. Please insert Windows 98 CD in the CDRom drive in this picture.
- Page 15 GARNET GAN-1030 8. Click OK in this picture. 9. Windows is copying files from CDRom. Wait until all files are copied and driver program installation is finished. 10. When the driver installation program is properly installed, as shown in the picture,...
-
Page 16: Running Theg
GARNET GAN-1030 11. The picture proves that the driver program is prperly installed and working for the ADSL PCI Modem. Close the picture. 2.5 Running the Garnet ADSL Manager Program 1. Click My Computer and Control Panel. - Page 17 GARNET GAN-1030 2. You can find the Garnet ADSL Manager program icon in the picture. Double click the icon.
-
Page 18: Chapter 3. Uninstalling The Software
GARNET GAN-1030 3. The program shows how the Garnet ADSL Modem is managed, data transmission speed and Driver program version. Click OK. Chapter 3. Uninstalling the Software... -
Page 19: Uninstalling In The
GARNET GAN-1030 3.1 Uninstalling in the Windows 98 1. Click My Computer and Control Panel. 2. Click Install/Uninstall tab and select GAN-1030 ADSL PCI NIC. - Page 20 GARNET GAN-1030 3. Windows will ask, before you remove the Driver installation program. 4. To be sure to make all files are completely removed from the system, click OK in this picture. 5. Click OK in this picture. 6. Click OK in this picture.
- Page 21 GARNET GAN-1030 7. You can find the Driver Installation Program is completely removed. Close the Windows and reboot your computer to be sure to remove the Driver Installation Program.
-
Page 22: Chapter 4 Appendix
GARNET GAN-1030 Chapter 4. Appendix 4.1 Trouble-shooting You would better know Modem Name, Modem No., Serial No. and what is the problem, ☞ ☞ ☞ ☞ and then ask help to your Service Provider in order to get solutions. Q. In installing modem in Windows 95/98, Plug-n-Play Dialog box is not showing. - Page 23 GARNET GAN-1030 A. Contact your local service provider.
