Introduction
The Model D3605 Clamp Buddy can hold over 200 clamps,
including bar clamps, K-Body clamps, and dozens of
other special purpose clamps. The all-steel frame will
safely support up to 500 lbs. and the heavy-duty locking
casters make it easy to move your clamps and store them
in convenient locations. You can customize your Clamp
Buddy by adjusting the spacing of the rods.
Inventory
(Figure 1):
A. Front Rack ....................................................1
B. Rear Rack .....................................................1
C. Cross Brace ...................................................1
D. Bottom Brace ................................................2
E. Swivel Casters with Brake .................................4
F. Rack Rods ................................................... 12
G. Hair Pin Cotter Pins ....................................... 24
H. Hardware Bag (Not shown) ................................1
—Hex Bolts M6-1 x 16 (Frame) ..........................6
—Hex Bolts M8-1.25 x 16 (Frame) ......................2
—Hex Nuts M6-1 (Frame) .................................6
—Ext Tooth Washer 6mm (Frame) ......................6
—Lock Nuts M8-1.25 (Frame) ............................2
—Flat Washers 8mm (Frame) ............................2
—Flange Nuts M10-1.5 (Caster) ..........................4
If structural parts are missing, please contact Woodstock
International for replacements. If your Clamp Buddy is
damaged, contact your dealer immediately. For the sake
of expediency, replacements for non-proprietary parts
can be obtained at your local hardware store.
COPYRIGHT © FEBRUARY 2007 BY WOODSTOCK INTERNATIONAL, INC.
WARNING: NO PORTION OF THIS MANUAL MAY BE REPRODUCED IN ANY SHAPE OR FORM WITHOUT
#8956JC THE WRITTEN APPROVAL OF WOODSTOCK INTERNATIONAL, INC.
Model D3605
Clamp Buddy
Instructions
A
F
D
E
Figure 1. Model D3605 inventory.
