- Page 1 Tomsk Scientific Industrial Introduction Company “SIAM” LLC DYNAMOMETER «DDIM-2» Operating manual Russia...
- Page 2 Dynamometer “DDIM-2”...
-
Page 3: Table Of Contents
8. SENSOR OPERATION IN THE “DB SIAM” SOFTWARE 8.1. Connecting the Bluetooth sensor to a computer 8.2. Working with sensors in “DB SIAM” 8.3. Study procedure 9. WORK WITH SENSORS IN THE “SIAM SERVICE” PROGRAM 26 10. STORAGE AND TRANSPORTATION OF THE PRODUCT 11. CLAIMS APPENDIX 1. - Page 4 2014 (IEC 60079-0:2011), GOST 31610.11-2014 (IEC 60079-11.), GOST 31610:2011), and have 1Ex ib IIB T3 Gb Х explosion proof mark. “DDIM-2” is designed for indoor and outdoor installation in hazardous areas where atmospheric explosives of IIA, IIB categories and T1, T2, T3 groups can form according to GOST R IEC 60079-20-1-2011 in the operating temperature range from -40 ºC to +50 ºC.
-
Page 5: General Product Information
2014 (IEC 60079-0:2011), GOST 31610.11-2014 (IEC 60079-11.), GOST 31610:2011), and have 1Ex ib IIB T3 Gb Х explosion proof mark. “DDIM-2” device is designed for indoor and outdoor installation in hazardous areas where atmospheric explosives of IIA, IIB categories and T1, T2, T3 groups can form according to GOST R IEC 60079-20-1-2011 in the operating temperature range from -40 ºC to +50 ºC. -
Page 6: Safe Operation Guidelines
Dynamometer “DDIM-2” 2. SAFE OPERATION GUIDELINES 2.1. General Provisions (regulatory framework) The design of the wellhead equipment is to be approved by the Russian Technical Surveillance Agency (RTSA). Preparation of the well for tests should be conducted in accordance... -
Page 7: Requirements To Test Objects
Dynamometer “DDIM-2” 2.3. Requirements to Test Objects Pressure measurement and control of fluid level is carried out in oil and gas producing wells of different operational modes (flowing, gas lift, artificial lift, etc.), as well as in injection, intake, control and other wells... - Page 8 Dynamometer “DDIM-2” Figure 1. The pumping unit control station is to have a mode select switch with the manual control option. The moving parts of the pumping unit (the crank-conrod mechanism, the V-belt drive) are to be properly fenced.
-
Page 9: Basic Specifications
Dynamometer “DDIM-2” Figure 2. Wellhead equipment If the height of the polished rod packing is low (up to 2 m above ground level), portable platforms are to be used provided they comply the above requirements. 3. BASIC SPECIFICATIONS The device is designed for operation at the wellhead equipped with a sucker rod pumping unit (SRPU), in oil and gas fields and provides: ... - Page 10 Dynamometer “DDIM-2” The device maintains its operability at ambient temperatures from minus 40 C to + 50 C. The device operates autonomously and is powered by a special internal battery with 3.6 V voltage. The minimum operating voltage of the battery which does not lead to a loss of performance of the device is 1.8 V.
-
Page 11: Ensuring Explosion-Proofness Of The Product
Dynamometer “DDIM-2” 4. ENSURING EXPLOSION-PROOFNESS OF THE PRODUCT. 4.1. Explosion-proofness of the product Explosion-proofness of the device is provided by the type of protection "intrinsically safe electric circuit" “ib” level, according to the requirements of GOST 31610.11-2014 (IEC 60079-11:2011), which is achieved by the following: Basic circuit diagram includes the protective component “Fib”. -
Page 12: Measures To Ensure And Keep The Device Explosion-Proofness
Dynamometer “DDIM-2” The device is powered by a special internal battery type ER18505 according to GOST 31610.11-2014 (IEC 60079-11:2011). The maximum temperature of overheating of components and connections in the circuit diagram during normal operation is 15 °C max. Thus, the surface temperature of conductors and elements during operation and at maximum operating temperature plus 50 °... - Page 13 Dynamometer “DDIM-2” - the short-circuit current and open circuit voltage at the output of the protective component are checked; - visual inspection of the filling location is carried out in order to confirm the absence of any foreign inclusions, bubbles, cracks or stratification.
-
Page 14: Delivery Set
The device is supplied according to the set shown in Table 2. Table 2 Title Q-ty 1. Dynamometer «DDIM-2» 2. Certificate 3. Flash drive with the software «Siam Service 2» 4. «Siam Service 2» software user’s guide 5. Mounting plate IZM 8.683.235 6. Package... -
Page 15: Preparation Of Test Objects For Dynamometry
Dynamometer “DDIM-2” PREPARATION TEST OBJECTS DYNAMOMETRY Check the availability and serviceability of the handbrake, balancer horsehead lock, protective fences, service platform. If the beam pumping unit is operated in remote control mode or in automatic mode, switch the control to manual according to the instructions. -
Page 16: Dynamometry Sensor Removal
Dynamometer “DDIM-2” 6.2. Dynamometer removal Stop the SRPU in the lower clipping position and secure with the brake. Reload the clipping and smoothly extend the cross-arms according to the approved technology. Remove the device from the space between the cross-arms. -
Page 17: Switching On And Switching Off
Dynamometer “DDIM-2” Figure 3: DDIM-2 appearance 7.3. Switching On and Switching Off The dynamometer designed without on/off button is triggered via a smartphone via Bluetooth. For the correct operation, the device must be held at a temperature of at least 10 min before measuring. -
Page 18: Sensor Operation In The "Db Siam" Software
The device must be turned on and ready for connection. The sign of readiness is the green color of the LED "Power". As a result of the connection, a COM port is created through which the SIAM Database software establishes a connection to the device. - Page 19 Dynamometer “DDIM-2” Figure 4: Bluetooth Menu in Windows 7-10...
-
Page 20: Working With Sensors In "Db Siam
In figure 5, the outgoing port COM20 is assigned to device DDIN No. 356. 8.2. Working with devices in “DB SIAM” To work with devices with the “DB SIAM” software: start the program; switch to the “Settings” tab;... - Page 21 Dynamometer “DDIM-2” Figure 7. “Devices” dialog box in “DB SIAM” If no device is listed or if for some reason the connection port of this device does not correspond to the one assigned in "Bluetooth parameters" (see above), then register the device in the program.
- Page 22 Dynamometer “DDIM-2” Figure 9: Error of connection to wrong COM port This happens if the COM port is incorrectly specified or in case of the device is switched off. If the error occurs because the device has been switched off, switch the device on and the connection will take place after some time.
- Page 23 Dynamometer “DDIM-2” If the connection is successful, the device control panel appears (see Figure 10). Figure 10. Device control panel For each device type, the control panel will have a different look. Panel 1: The name and device number, the current battery voltage, temperature, load and acceleration readings are displayed here;...
- Page 24 Dynamometer “DDIM-2” Panel 3: allows you to specify the well survey operator, the type of survey, add explanations to the survey in the text form. The button "Write to Database" becomes available after receiving the dynamogram from the device and allows the operator to save the study into the database at the moment when he is sure that he has correctly specified the well details and other study parameters.
-
Page 25: Study Procedure
Dynamometer “DDIM-2” Panel 8: Buttons "1_" and "_2" do not enter the oscillation period directly, but allow the program to define it as the interval between pressing the buttons "1_" and "_2". 8.3. Study procedure Check and, if necessary, change the details of the well (p.2 Fig. 10). -
Page 26: Work With Sensors In The "Siam Service" Program
The Bluetooth communication module must be switched on in the terminal according to the instructions for the specific device (phone/tablet). Switch on the device with the “Power” button. “DDIM-2” should be displayed on the terminal in the list of detected Bluetooth devices. - Page 27 Dynamometer “DDIM-2” Fig. 11. Device list In the “Help” tab check the availability of information about the field on which you want to make measurements. If the information about the field is absent, it should be entered manually. To measure the dynamogram click on the device in the “Control panels”.
-
Page 28: Storage And Transportation Of The Product
Dynamometer “DDIM-2” After filling in all available fields, click on the checkmark and the instrument will enter the measurement mode according to the set parameters. After the measurement is completed the “Measurements” window will be opened with the diagram presentation. -
Page 29: Claims
Web-address: http://www.siamoil.ru For repair and maintenance of products manufactured by TSIIC “SIAM” LLC contact the service centers of the company: 1. Service center in Neftejugansk, Tyumen region 106 Microrayon 11B, Neftejugansk, 628305, Tyumen region, Russian Federation; tel.: (34632) 3-44-69; +7912-812-95-73. - Page 30 Dynamometer “DDIM-2” 3. Service center in Almetyevsk, Tatarstan Republic 7a Bazovaya Str, Almetyevsk, 423450, Tatarstan Republic, Russian Federation; tel.: (3822) 65-58-80; 45-021. 4. Service center in Tomsk 3 Belaya Str., Tomsk, 634003, Russian Federation. tel.: (3822) 90-00-08; 20-02.
-
Page 31: Appendix 1
Dynamometer “DDIM-2” APPENDIX 1. Defining Length of Stroke of the Polished Rod along Crank Holes of the Conventional Pumping Unit Table 2 Hole # Type of pumping unit PNS- 6SK6 7SK8 SKD8 SKR-8 Stroke length, m 1.67 0.95... - Page 32 Dynamometer “DDIM-2” REVISION RECORD SHEET Total sheets Incoming # Ref # of Numbers of sheets (pages) Signa- Revi- (pages) of of supporting docu- Date sion ture document ment document Revised Replaced Annulled...
