- Page 1 Owner's Manual FUSION WiFi DAC Transport Dual Mono Vacuum Tube Stand-Alone Digital to Analog Converter with Compact Disc Player Black Ice Audio 21310 Ridgecroft Drive, Brookeville, MD 20833 Phone (301) 953-2014 Fax (301) 498-0554 Email: info@blackiceaudio.com Web: www.blackiceaudio.com...
-
Page 2: Table Of Contents
We at Black Ice Audio want to thank you for purchasing the Black Ice Audio Vacuum Tube Fusion WiFi DAC Transport. The company that stands behind your WiFi DAC Transport draws on two decades of tube design and manufacturing experience. In addition to our engineering knowledge is a commitment to our client to provide the highest level of quality sound at a value price. -
Page 3: Safety Precautions
SAFETY PRECAUTIONS IMPORTANT SAFEGUARDS PLEASE READ CAREFULLY ALL THE FOLLOWING IMPORTANT SAFEGUARDS THAT ARE APPLICABLE TO YOUR EQUIPMENT. _________________________________________________________________________ _________________________________________________________________________ The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to alert the user to the presence of un-insulated “dangerous voltage” within the product’s enclosure that may be of CAUTION sufficient magnitude to constitute a risk of electric... - Page 4 SAFETY PRECAUTIONS CONTINUED MAINTENANCE Cleaning - Unplug this product from the wall outlet INSTALLATION before cleaning. Do not use liquid cleaners or aerosol cleaners. Use a damp cloth for cleaning. ENVIRONMENT Do not use any type of abrasive pad, scouring 1) Water and Moisture –...
-
Page 5: General Information
GENERAL INFORMATION About Your Unit: Fusion WiFi DAC Transport The Fusion WiFi DAC Transport combines the proven sound quality of vacuum tubes and the convenience of the digital format. Our design objectives are 1) Sound quality, 2) High standards of build quality and sound quality at a value price, and 3) a high level of reliability and long life. -
Page 6: Getting Started
_______________________________________________________________________ Hooking Up the System: Fusion Wifi Dac-Transport Overview: The diagram to the right describes how to Line Out hook up the WiFi DAC Transport to an amplifier. -
Page 7: Front Panel Controls And Functions
FRONT PANEL CONTROLS AND FUNCTIONS 1. Indicator Light 6. Play/Pause Button 2. On/Standby/Off Power Switch 7. Stop Button 3. Display Window 8. Backward Skip Selection 4. Disc Holder 9. Forward Skip Selection 5. Open/Close Disc Tray Button 10. Selector Switch (CD, USB, Toslink, WiFi) __________________________________________________________________ Playing a CD... -
Page 8: Remote Control Diagram And Description
REAR PANEL CONTROLS AND FUNCTIONS 1. Digital inputs: USB, Toslink, or WiFi 2. Digital Outputs: Toslink, Coaxial 3. Analog Output: Unbalanced, Balanced 4. Ground: Used to ground other pieces of electronic equipment. Please Note: If there is a hum or static coming from the speakers with the unit on, there may be a ground loop that is being caused by a floating ground amplifier hooked up with a true grounded unit. -
Page 9: Where Do I Go Next: Functions
Remote Control PROG ON’OFF INTRO Overview: Some remote-control functions are the same as the front panel. In order for the remote-control unit to function properly while using the remote control, please point it directly at the remote sensor on the front panel of the CD Player. 1. - Page 10 1. Pause Mode: If the Transport is playing a disc, pushing the Play/Pause button will stop the disc and the pause indicator II will appear in the display window. If you push the Play/Pause button, the disc will resume playing. 2.
-
Page 11: Additional Information
_____________________________________ ADDITIONAL INFORMATION _____________________________________ Changing the Vacuum Tubes 1. Using a 3mm Allen wrench, you need to remove four bolts. 2. Remove the top cover. 3. With the front of the WiFi DAC Transport toward you, the tubes are located in the left- and right- hand compartments. - Page 12 Advice on Compact Disks Handling CD’s 1. To keep the disc clean, handle the disc by its edge. Do not touch the surface. 2. Do not stick paper or tape on the disc. 3. Do not expose the disc to direct sunlight or heat sources such as hot air ducts, nor leave it in a car parked in direct sunlight as there can be a considerable rise in temperature inside the car.
-
Page 13: Troubleshooting And Service
If you experience any of the following difficulties while using the player, use this troubleshooting guide to help you remedy the problem. Should any of these problems persist, consult your nearest Black Ice Audio Dealer. There is no sound. >Check that the player is connected to the amplifier. >Check that the power switch is on. - Page 14 Refer any needed service to your authorized Black Ice Audio dealer or other qualified technicians. The vacuum tubes inside the Fusion WiFi DAC Transport are high-quality and should last 20,000 hours. If you should need replacement tubes, please consult your dealer or service representative.
-
Page 15: Warranty And Conditions
HOW TO OBTAIN WARRANTY PERFORMANCE If your Black Ice Audio unit ever needs service, write to us at Black Ice Audio Inc., PO Box 218, Brookeville, MD 20833 (Att. Customer Relations Department). We may direct you to an Authorized Black Ice Audio Warranty Station or ask you to send your unit to the factory for repair. -
Page 16: Technical Specifications
Technical Specifications Fusion WiFi DAC Transport Frequency Response: 20-20KHz ± 0.5dB + 0.5dB S/N Signal to Noise > 98dB （Balanced signal 1KHz Ratio: THD + N ≤0.02% Distortion: > 96dB (1KHz) Channel Separation: Analog Output Balanced XLR, Unbalanced RCA Balanced signal output 5.0V, 47Kohms...
