- Page 1 12HP Eurorack Module Built & designed in E.U. www.shakmat.com Shakmat Mod Medusa Building Guide...
-
Page 2: Table Of Contents
................5 Front ..........................6 Electrolytic capacitors 4.2.1 ..................6 Jack connectors 4.2.2 ....................7 Tacticle switches 4.2.3 ..................... 8 Potentiometers 4.2.5 ....................9 LED push buttons 4.2.6 ..................10 LEDs 4.2.7 ......................11-12 First startup routine ......................13 • www.shakmat.com... -
Page 3: Preamble
1. Preamble Thank you for purchasing a Shakmat DIY kit ! We spare no effort in our kit packing process to prevent any mistakes or missing parts. In this document as well, we do our best to describe the assem- bly process in the most practical and comprehensive way. -
Page 4: Component List & Necessary Tools
Necessay tools 4x Metal potentiometer nuts 1x White LED push button Soldering iron Solder Cutting pliers Masking tape Pack 3 12x Jack connectors 12x Jack connectors nuts 4x Green/amber dual color LEDs 1x Green/red LED push button • www.shakmat.com 03/13... -
Page 5: Pcb Details
3. PCB details Front & back • www.shakmat.com 04/13... -
Page 6: Assembly
Take off the soldering iron but keep pressing. Avoid touching the pins themselves because they will become hot very quickly and move out of alignment within their plastic bracket. Once you are satisfied with you placement, solder the remaining pins. • www.shakmat.com 05/13... -
Page 7: Front
Flip the PCB and solder the three 22µF capacitors. You must pay attention to the orientation of these components. The long leg indicates the positive side, therefore it has to match the little dot on the PCB silkscreen. • www.shakmat.com 06/13... -
Page 8: Jack Connectors
If one of the jacks is not perfectly perpendicular with the PCB, you can reheat the pads and push it down with your thumb to re-align. • www.shakmat.com 07/13... -
Page 9: Tacticle Switches
It’s very important to solder the four push buttons flat with the PCB. If they are crooked or not thoroughly pushed through, the caps won’t pop properly through the front panel and the buttons will be hard to press. • www.shakmat.com 08/13... -
Page 10: Potentiometers
PCB. Mount the front panel and tighten the potentiometers nuts (this will ensure a proper placement of the pots) and then solder them. Once you have soldered everything, remove the nuts, the front panel and proceed to the next step. • www.shakmat.com 09/13... -
Page 11: Led Push Buttons
We recommand you the place the front panel back on and tighten the Length potentiometer nut before soldering the LED buttons. Once you have soldered everything, remove the front panel and go to the next step. • www.shakmat.com 10/13... - Page 12 The long leg is the positive side and they all go into the left holes of the PCB. Place all the LEDs through the PCB paying attention to the colors and orientations but don’t solder them now. • www.shakmat.com 11/13...
- Page 13 You’re almost done! The last thing to do is to tighten the knurled nuts on the jack sockets. Finally, push the four knobs onto their metal poten- tiometer and the two button caps on the Shift buttons. • www.shakmat.com 12/13...
-
Page 14: First Startup Routine
Turn on your rack, the Mod Medusa Tap button will lit red and the Uni button is dimmed. Without anything inserted into the jack sockets press the Uni button. - Page 15 www.shakmat.com...
