COMBINATION ELECTRIC FIREPLACE/HEATER
WARNING
CAUTION
DO NOT RETURN!
Contact our customer service team for help first.
Customer Service Center: 800-385-0608 or aftersales@cye-way.com
E appreciate the trust and confidence you have placed this electric fireplace/heater. We
strive to continually create quality products designed to enhance your home. Thank you for
choosing!
USE AND CARE GUIDE
Model # ZHX-23-040
Read and understand this entire user manual, including all safety
information, before plugging in or using this product. Failure to do so could
result in fire, electric shock, or serious personal injury.
Keep this user manual for future reference. If you sell or give this product
away, make sure this manual accompanies this product.
THANK YOU!
LOT NUMBER:
DATE PURCHASED:
/
/
Advertisement
Summary of Contents for EDYO LIVING ZHX-23-040
- Page 1 LOT NUMBER: DATE PURCHASED: USE AND CARE GUIDE COMBINATION ELECTRIC FIREPLACE/HEATER Model # ZHX-23-040 Read and understand this entire user manual, including all safety information, before plugging in or using this product. Failure to do so could WARNING result in fire, electric shock, or serious personal injury.
- Page 3 CONTENT 1. Important Safety Information..............1 2. Installation Instruction …………………………….…....……...…2 3. Operation Instruction/a. Manual Control Panel.…………....4 b. Remote Control …………………………..6 4. Care and Maintenance …………………..…........8 5. Limited Warranty …………………...……………………......8 6. Troubleshooting Guide ..……….....………………………..…..9 1.IMPORTANT SAFETY INFORMATION WARNING: Any use of this appliance other than that recommended by the manufacturer in this owners manual may cause fire, burns, electric shock and/or other serious injuries or death.
- Page 4 2. INSTALLATION INFORMATION PACKAGE CONTENTS Part Description Quantity Remote Control with Battery Fireplace Insert Side Trim Screw-short 4+1 extra Screw-long 6+1 extra TOOLS REQUIRED Phillips screwdriver (not provided) CAUTION: This insert has front panel made of GLASS! ALWAYS use extreme caution when handling glass.Failure to do so could result in personal injury or property damage.
- Page 5 2.2 Installing the fireplace insert Carefully set the fireplace insert (W into the back of the mantel and center it in the opening. Use care not to scratch the wood.Check the alignment, and then attach the fireplace insert (W) to the mantel by inserting the screws (19) through the drilled holes on the trims ( Y) and securely screw into place using a Phillips screwdriver.
- Page 6 A 15 AMP circuit is required to operate this appliance.If the breaker trips when the appliance is running, you may need to move the appliance to another location or unplug other appliances that are on the same circuit. The fireplace control functions can be accessed in two ways: - Using the control panel, located in the upper right-hand corner of the electric insert.
- Page 7 When the first time push simulated flame effect that the flame brightness is on highest setting and the flame with Amber, the digital display screen will be shown A. No action after 20s, the digital display is blank. Flame Color Display Flame Brightness...
- Page 8 3b. Remote Control lnstalling the battery The battery is supplied with the remote control. The first thing to do with the remote control is to remove the plastic sheet insulated the battery.For replacement battery, use lithium-based CR2025 battery. Please follow the sequence below to replace the battery.
- Page 9 The remote control can be used up to 13 feet (4 meters) away from the heater, so long as there are no obstructions between the remote control and the heater. the remote can control all the settings as the control panel does.
- Page 10 4. CARE AND MAINTENANCE ALWAYS turn the appliance OFF and unplug the power cord from the outlet before cleaning, performing maintenance, or moving this fireplace. Failure to do so could result in electric shock, fire, or personal injury. NEVER immerse in water or spray with water. Doing so could result in electric shock, ...
- Page 11 6. TROUBLESHOOTING GUIDE WARNING: Turn off the appliance, unplug and let cool for at least 10 minutes before attempting to service. Only a qualified professional should attempt to service or repair the appliance. PROBLEM POSSIBLE CAUSE SOLUTION 1. Dimmer control button is set too 1.
