Fortress Power eVault Max Disassembly

eVault Max 18.5 BATTERY MODULES DISASSEMBLY
Contents
1 - INTRODUCTION ........................................................................................................................................................ 1
2 - eVault MAX GENERAL DISASSEMBLY ................................................................................................................... 2
3 - eVault MAX BATTERY MODULE DISASSEMBLY .................................................................................................... 2
3A - DISCONNECTING THE POWER LEADS AND BUS BARS .................................................................................. 2
3B - REMOVING THE BATTERY MODULES .............................................................................................................. 3
4 - eVault MAX BATTERY MODULE RE_ASSEMBLY ................................................................................................... 3
4A - REPLACING THE BATTERY MODULES ............................................................................................................. 3
4B -CONNECTING THE POWER LEADS AND BUS BARS......................................................................................... 4
5 - FURTHER HELP ....................................................................................................................................................... 4
APPENDIX ...................................................................................................................................................................... 5
APPENDIX A ............................................................................................................................................................... 5
APPENDIX B ............................................................................................................................................................... 9
APPENDIX C ..............................................................................................................................................................13

1 - INTRODUCTION

This guide will help with the disassembly and reassembly of the eVault Max battery to allow moving the battery
modules separately from the frame and electronics. We will be handling charged large battery modules that
can discharge over 1,000 Amps if shorted, this can be fatal. Only certified installers should perform this task.
Any damage that occurs during this is not covered by Fortress power and may void the warranty. Please
follow the installation guide prior to following any step listed here verifying the batteries operation-----make sure
you understand the proper installation before attempting to open and troubleshoot the eVault Max. Always
read the warning notices on the installation manual and take all necessary safety precautions when
dealing with 48V batteries.
