- Page 1 AFV-P-T620 Series 620V Voltage Transform Unit for AFV-P Series User Manual AC Power Corp. (Preen) V 1.4.EN The information in this document is subject to change without notice. Copyright by AC Power Corp. (Preen). All rights reserved.
-
Page 2: Legal Notices
Copyright Notices. Copyright 2017 AC Power Corp. (Preen), all rights reserved. Reproduction, adaptation, or translation of this document without prior written... -
Page 3: Warranty
Any recommendations made by Preen for use of its products are based upon tests believed to be reliable, but Preen makes no warranty of the results to be obtained. This warranty is in lieu of all other warranties, expressed or implied, and no representative or person is authorized to represent or assume for Preen any liability in connection with the sale of our products other than set forth herein. -
Page 4: Safety Summary
WARNINGS given elsewhere in this manual will violate safety standards of design, manufacture, and intended use of the product. Preen assumes no liability for the customer‘s failure to comply with these requirements, causing malfunction or damage on the product, personal injury, death or any loss of, or damage to, property. - Page 5 WARNING LETHAL VOLTAGES. The product can supply 877V peak at its output. DEATH on contact may result if either the output terminals or the circuits connected to the output are touched when the power is applied. In the event that there is fire occurring in the vicinity, please use dry powder extinguishers.
-
Page 6: Specification
AFV-P-T620 Series 620V Voltage Transform Unit Introduction AFV-P-T620 Series is a 620V voltage transform unit, used with AFV-P series programmable AC Power Source to increase the maximum output voltage range from 0~310VAC to 0~620VAC, providing the users more extensive application range. - Page 7 AFV-P-T620 Series 620V Voltage Transform Unit ±(2% of reading + 5 Counts) at ≦500Hz Current Accuracy ±(2% of reading + 10 Counts) at >500Hz Peak Current Range 0.0~22.5A 0.0~45.0A 0.0~90.0A Peak Current Resolution 0.1A ±(2% of reading + 5 Counts) at ≦500Hz;...
-
Page 8: Installation
AFV-P-T620 Series 620V Voltage Transform Unit Installation AFV-P-T620 can only be used with the AFV-P series. Turn the AFV-P series off before ℃ installation. The power cord used must be rated at least 85 and has sufficiently gauge so they will not overheat while carrying the output current. The input power line must have a current rating which is greater than or equal to the maximum rated current of the product. -
Page 9: Setup Operation
AFV-P-T620 Series 620V Voltage Transform Unit Setup/Operation After installation, ensure AFV-P’s input is well connected. Turn on AFV-P and perform the following steps on its touch screen to setup. 1. After the power on procedure, press MENU at the main page (see Figure 2). - Page 10 AFV-P-T620 Series 620V Voltage Transform Unit 3. Press SYSTEM, and press the icon to move to the last page of the SYSTEM subpage (see Figure 4). Figure 4 4. Switch the icon status of AC-620V from OFF to ON (see Figure 5).
- Page 11 AFV-P-T620 Series 620V Voltage Transform Unit 5. Press the icon to return to the main page, the output voltage can now be set from 0 to 620 (see Figure 6). Figure 6 NOTICE While AC-620V item is set ON, the VOLTAGE SENSE (go to MENU SETTING...
