  • Page 1 XT855 Operator’s Manual 053-1985 ® Issue 1.0...

  • Page 2: Table Of Contents

    XT855 Operator’s Manual Overview - 1 Overview Chapter Contents Serial Number Location ..... . 2 Intended Use ....... 3 Unit Components .

  • Page 3: Serial Number Location

    XT855 Operator’s Manual Overview - 2 Serial Number Location Serial Number Location Record serial numbers and date of purchase in spaces provided. XT855 Tier 4i serial number is located as shown. Date of manufacture Date of purchase XT855 Tier 4i serial number...

  • Page 4: Intended Use

    The XT855 is a ride-on, track-driven excavator/tool carrier unit designed for light-to medium-duty construction work. The XT855 excavator allows 260° swing and digging depths to 83” (2.1 m). The XT855 lift arms have a quick attach mount plate which makes it easy for an operator to connect different attachments.

  • Page 5: Unit Components

    XT855 Operator’s Manual Overview - 4 Unit Components Unit Components 1. attachment receiver plate 5. operator’s station 2. lift arms 6. ROPS/FOPS 3. engine compartment 7. excavator 4. tracks 8. excavator stow lock Operator Orientation 1. Front of unit 3. Rear of unit 2.

  • Page 6: About This Manual

    XT855 Operator’s Manual Overview - 5 About This Manual About This Manual This manual contains information for the proper use of this machine. See Operation Overview for basic operating procedures. Cross references such as “See page 50” will direct you to detailed procedures.
  • Page 7 XT855 Operator’s Manual Overview - 6...

  • Page 8: Foreword

    If you sell your equipment, be sure to give this manual to the new owner. If you need a replacement copy, contact your Ditch Witch dealer. If you need assistance in locating a dealer, visit our website at www.ditchwitch.com or write to the following address: The Charles Machine Works, Inc.
  • Page 9 Copyright 2009 by The Charles Machine Works, Inc. , Ditch Witch, CMW, AutoCrowd, Modularmatic, Jet Trac, Roto Witch, Subsite, Fluid Miser, Perma-Soil, Power Pipe, Super Witch, Super Witch II, Pierce Airrow, The Underground, and The Underground Authority Worldwide are registered trademarks of The Charles Machine Works, Inc.
  • Page 10 XT855 Operator’s Manual Contents - 9 Contents Overview machine serial number, information about the type of work this machine is designed to perform, basic machine components, and how to use this manual Foreword part number, revision level, and publication date of this manual, and factory contact...
  • Page 11 XT855 Operator’s Manual Contents - 10 Specifications machine specifications including weights, measurements, power ratings, and fluid capacities Support the warranty policy for this machine, and procedures for obtaining warranty consideration and training Service Record a record of major service performed on the machine...

  • Page 12: Safety

    XT855 Operator’s Manual Safety - 11 Safety Chapter Contents Guidelines ....... . 12 Safety Alert Classifications .

  • Page 13: Guidelines

    Use equipment carefully. Stop operation and investigate anything that does not look or feel right. • Do not operate unit where flammable gas is present. • Contact your Ditch Witch dealer if you have any question about operation, maintenance, or equipment use.

  • Page 14: Safety Alert Classifications

    XT855 Operator’s Manual Safety - 13 Safety Alert Classifications Safety Alert Classifications These classifications and the icons defined on the following pages work together to alert you to situations which could be harmful to you, jobsite bystanders or your equipment. When you see these words and icons in the book or on the machine, carefully read and follow all instructions.

  • Page 15: Safety Alerts

    XT855 Operator’s Manual Safety - 14 Safety Alerts Safety Alerts Electric shock. Contacting electric lines will cause death or serious injury. Know location of lines and stay away. Deadly gases. Lack of oxygen or presence of gas will cause sickness or death.
  • Page 16 XT855 Operator’s Manual Safety - 15 Safety Alerts Fall possible. Riders can fall from machine and be injured or killed. Only operator is allowed on machine. Rollover possible. If machine rolls over, you could be thrown from seat and killed or crushed. Wear seat belt.
  • Page 17 XT855 Operator’s Manual Safety - 16 Safety Alerts Moving traffic - hazardous situation. Death or serious injury could result. Avoid moving vehicles, wear high visibility clothing, post appropriate warning signs. Flying objects may cause injury. Wear hard hat and safety glasses.

  • Page 18: Emergency Procedures

    XT855 Operator’s Manual Safety - 17 Emergency Procedures Emergency Procedures Before operating any equipment, review emergency procedures and check that all safety precautions have been taken. EMERGENCY SHUTDOWN - Turn ignition switch to STOP or press engine stop button. Electric Strike Description When working near electric cables, remember the following: •...

  • Page 19: If An Electric Line Is Damaged

    XT855 Operator’s Manual Safety - 18 Emergency Procedures If an Electric Line is Damaged If you suspect an electric line has been damaged and you are on unit, DO NOT MOVE. Remain on unit and take the following actions. The order and degree of action will depend upon the situation.

  • Page 20: If A Fiber Optic Cable Is Damaged

    XT855 Operator’s Manual Safety - 19 Emergency Procedures If a Fiber Optic Cable is Damaged Do not look into cut ends of fiber optic or unidentified cable. Vision damage can occur. If Machine Catches on Fire Perform emergency shutdown procedure and then take the following actions. The order and degree of action will depend on the situation.
  • Page 21 XT855 Operator’s Manual Safety - 20 Emergency Procedures...

  • Page 22: Controls

    XT855 Operator’s Manual Controls - 21 Controls Chapter Contents Front Console ......22 Left Console .

  • Page 23: Front Console

    XT855 Operator’s Manual Controls - 22 Front Console Front Console 1. Ignition switch 8. Horn 2. Cold start button 9. Hourmeter 3. Work mode switch 10. Hydraulic fluid temperature alarm 4. Hydraulic fluid temperature indicator 11. Fuel gauge 5. Engine coolant temperature indicator 12.
  • Page 24 XT855 Operator’s Manual Controls - 23 Front Console Item Description Notes 2. Engine cold start button To help start cold engine, turn NOTICE: Do not press and hold ignition switch to first position. button more than 20 seconds. Press cold start button as IMPORTANT: Press cold start button directed in notes.
  • Page 25 XT855 Operator’s Manual Controls - 24 Front Console Item Description Notes 6. Operator presence Lights when operator is Engine will not start unless this indicator seated. indicator is lighted. 7. Auxiliary hydraulic fluid Light when the attachment IMPORTANT: flow/pressure indicator drive switch is in the forward position.
  • Page 26 XT855 Operator’s Manual Controls - 25 Front Console Item Description Notes 10. Hydraulic oil Sounds when hydraulic oil • Allow unit to cool. temperature alarm temperature is above 210°F • Check hydraulic oil level. (100°C). c00ic232h.eps 11. Fuel gauge Displays fuel level in tank.

  • Page 27: Left Console

    XT855 Operator’s Manual Controls - 26 Left Console Left Console IMPORTANT: Controls are shown with seat facing excavator. 1. Left extension leg control* 3. Hydraulic fluid bypass control* 2. Right extension leg control* *Optional Item Description Notes 1. Left extension leg To lower, push.
  • Page 28 XT855 Operator’s Manual Controls - 27 Left Console Item Description Notes 2. Right extension leg To lower, push. control To raise, pull. 3. Hydraulic fluid bypass Lift knob and start engine. IMPORTANT: control Run engine five minutes to • Use the hydraulic fluid bypass to warm hydraulic fluid.

  • Page 29: Joysticks

    XT855 Operator’s Manual Controls - 28 Joysticks Joysticks 1. Engine stop button 4. Left joystick 2. Right joystick 5. Boom offset switch 3. Attachment drive switch...
  • Page 30 XT855 Operator’s Manual Controls - 29 Joysticks Item Description Notes 1. Engine stop button Stops engine immediately. IMPORTANT: • Except in an emergency, move throttle to idle before using stop switch. 2. Right joystick With work mode switch in IMPORTANT: tool carrier mode: •...
  • Page 31 XT855 Operator’s Manual Controls - 30 Joysticks Item Description Notes 4. Left joystick With work mode switch in IMPORTANT: tool carrier mode: • Control can perform more than • To move forward, push. one action at a time. Using them together, operator can “feather”...

  • Page 32: Upper Console

    XT855 Operator’s Manual Controls - 31 Upper Console Upper Console t10om031h.eps 1. Front light switch 2. Rear light switch Item Description Notes 1. Front light switch To turn on, press top. To turn off, press bottom. c00ic225h.eps 2. Rear light switch To turn on, press top.

  • Page 33: Seat

    XT855 Operator’s Manual Controls - 32 Seat Seat 1. Seat belt 3. Seat slide control 2. Armrest adjustment 4. Operator’s station pivot control Item Description Notes 1. Seat belt To fasten, insert latch into NOTICE: Always fasten seat belt buckle. Adjust until seat belt when operating unit.
  • Page 34 XT855 Operator’s Manual Controls - 33 Seat Item Description Notes 3. Seat slide control To slide forward or backward, move left. To lock seat in position, move right. 4. Operator’s station pivot To pivot, press and swing Seat can lock in 5 different positions control station to desired position.

  • Page 35: Battery

    XT855 Operator’s Manual Controls - 34 Battery Battery 1. Battery disconnect switch Item Description Notes 1. Battery disconnect To disconnect battery power, Green switch is located under the switch turn counterclockwise. hood on the battery cable. To connect battery power, Use when servicing unit and during turn clockwise.

  • Page 36: Tool Carrier Indicator

    XT855 Operator’s Manual Controls - 35 Tool Carrier Bucket Tool Carrier Bucket 1. Level bucket indicator Item Description Notes 1. Level bucket indicator To level bucket, adjust bucket Indicator only works with loader position until indicator is at buckets. top of sleeve.
  • Page 37 XT855 Operator’s Manual Controls - 36...

  • Page 38: Operation Overview

    XT855 Operator’s Manual Operation Overview - 37 Operation Overview Chapter Contents Planning ....... . . 38 Using Tool Carrier Mode .
  • Page 39 XT855 Operator’s Manual Operation Overview - 38 Planning Planning 1. Gather information about jobsite. See page 40. 2. Inspect jobsite. See page 41. 3. Classify jobsite. See page 42. 4. Check supplies and prepare equipment. See page 44. 5. Load unit onto trailer. See page 52.

  • Page 40: Prepare

    XT855 Operator’s Manual Prepare - 39 Prepare Chapter Contents Gather Information ......40 • Review Job Plan ......... . .40 •...

  • Page 41: Gather Information

    XT855 Operator’s Manual Prepare - 40 Gather Information Gather Information A successful job begins before you dig. The first step in planning is reviewing information already available about the job and jobsite. Review Job Plan Review blueprints or other plans. Check for information about existing or planned structures, elevations, or proposed work that may be taking place at the same time.

  • Page 42: Inspect Site

    XT855 Operator’s Manual Prepare - 41 Inspect Site Inspect Site Inspect jobsite before transporting equipment. Check for the following: • changes in elevation such as hills or other open trenches • obstacles such as buildings, railroad crossings, or streams •...

  • Page 43: Classify Jobsite

    XT855 Operator’s Manual Prepare - 42 Classify Jobsite Classify Jobsite Inspect Jobsite • Follow U.S. Department of Labor regulations on excavating and trenching (Part 1926, Subpart P) and other similar regulations. • Contact your locan One-Call (811 in USA) or the One-Call referral number (888-258-0808 in USA and Canada) to have underground utilities located before digging.

  • Page 44: Apply Precautions

    XT855 Operator’s Manual Prepare - 43 Classify Jobsite Apply Precautions Once classified, precautions appropriate for jobsite must be taken. Electric Jobsite Precautions Use one or both of these methods. • Expose line by careful hand digging or soft excavation. •...

  • Page 45: Check Supplies And Prepare Equipment

    XT855 Operator’s Manual Prepare - 44 Check Supplies and Prepare Equipment Check Supplies and Prepare Equipment Supplies • fuel • keys • personal protective equipment, such as hard hat and safety glasses Fluid Levels • fuel • hydraulic fluid •...

  • Page 46: Drive

    XT855 Operator’s Manual Drive - 45 Drive Chapter Contents Start Unit ....... . . 46 Drive .

  • Page 47: Start Unit

    XT855 Operator’s Manual Drive - 46 Start Unit Start Unit EMERGENCY SHUTDOWN: Turn ignition switch to STOP. 1. Fasten and adjust seat belt. 2. Ensure all controls are in neutral. 3. Set engine speed to half throttle. 4. If necessary, use engine cold start button and/or hydraulic fluid bypass control to warm engine. See page 23 and page 27.

  • Page 48: Drive

    For example, an empty bucket makes the rear of the unit the heavy end while a full bucket makes the front of the unit the heavy end. Most Ditch Witch-approved attachments make the front of the unit the heavy end.

  • Page 49: Steer

    XT855 Operator’s Manual Drive - 48 Steer Steer NOTICE: When driving unit more than a few feet (meters), pivot seat so that operator is facing lift arms. If operator is facing excavator, operation of track drive controls is reversed. To steer while moving forward, push left joystick forward and then move to left or right. Unit will gradually turn to left or right.

  • Page 50: Transport

    XT855 Operator’s Manual Transport - 49 Transport Chapter Contents Lift ........50 •...

  • Page 51: Lift

    XT855 Operator’s Manual Transport - 50 Lift Lift Crushing weight. If load falls or moves it could kill or crush you. Use proper procedures and equipment or stay away. Points Lifting points are identified by lifting decals. Lifting at other points is unsafe and can damage machinery.

  • Page 52: Haul

    XT855 Operator’s Manual Transport - 51 Haul Haul Inspect Trailer • Check hitch for wear and cracks. Lubricate if needed. • Check battery for 12V charge. • Inspect lights for cleanliness and correct operation. Inspect reflectors and replace if needed.

  • Page 53: Load

    XT855 Operator’s Manual Transport - 52 Haul Load Crushing weight. If load falls or moves it could kill or crush you. Use proper procedures and equipment or stay away. NOTICE: • Load and unload trailer on level ground. • Verify that trailer wheels are blocked.
  • Page 54 XT855 Operator’s Manual Transport - 53 Haul Without Tiedown Kit IMPORTANT: Disconnect and stow front attachment before loading unit. 1. Start engine. 2. Fasten seat belt and swivel seat to face the tool carrier. 3. Ensure work mode switch is in tool carrier mode.

  • Page 55: Tie Down

    XT855 Operator’s Manual Transport - 54 Haul Tie Down Points Tiedown points are identified by tiedown decals. Securing to trailer at other points is unsafe and can damage machinery. Procedure Incorrect procedures could result in death, injury, or property damage.
  • Page 56 XT855 Operator’s Manual Transport - 55 Haul With Tiedown Kit Install tiedown through rear tiedown point. Make sure unit is secure before transporting.
  • Page 57 XT855 Operator’s Manual Transport - 56 Haul Without Tiedown Kit IMPORTANT: Do not use any point on excavator and swing arm as tiedown point. Loop tiedowns around unit at tiedown points. Make sure tiedowns are tight before transporting.

  • Page 58: Unload

    XT855 Operator’s Manual Transport - 57 Haul Unload Crushing weight. If load falls or moves it could kill or crush you. Use proper procedures and equipment or stay away. NOTICE: • Load and unload trailer on level ground. • Ensure trailer wheels are blocked.

  • Page 59: Tow

    XT855 Operator’s Manual Transport - 58 Incorrect procedures could result in death, injury, or property damage. Learn to use equipment correctly. NOTICE: • Parking brakes are set when engine is not running. Hydrostatic charge pump must be working properly to release parking brakes. If engine will not run or pilot pressure is not available, manually disengage parking brake prior to towing.
  • Page 60 XT855 Operator’s Manual Transport - 59 Prepare Unit for Normal Operation 1. Close 4 tow valves on pumps. IMPORTANT: Use 4-mm Allen wrench and 13-mm box wrench to adjust tow valves. • Loosen jam nut. • Turn set screw out 6 turns.
  • Page 61 XT855 Operator’s Manual Transport - 60...

  • Page 62: Dig

    XT855 Operator’s Manual Dig - 61 Chapter Contents Overview ....... . . 62 •...

  • Page 63: Overview

    IMPORTANT: This chapter covers how to use the excavator. For information on how to use front- mounted attachments, refer to controls chapter and attachment operator’s manual. The XT855 can perform a variety of different kinds of work in excavator mode. All basic excavator work involves filling and dumping the bucket.

  • Page 64: Filling Bucket

    XT855 Operator’s Manual Dig - 63 Setup Filling Bucket 45° 45° 30° 30° Jobsite hazards could cause death or serious injury. Use correct equipment and work methods. Use and maintain proper safety equipment. NOTICE: Cutting or drilling concrete containing sand or rock containing quartz may result in exposure to silica dust.

  • Page 65: Dumping Bucket

    XT855 Operator’s Manual Dig - 64 Setup Dumping Bucket Use right and left joysticks to control excavator dipper, boom, and bucket. 1. Position unit. Onto truck Into hole or onto ground Position unit between material to be loaded and Position unit to minimize the need for travel.

  • Page 66: Digging

    XT855 Operator’s Manual Dig - 65 Digging Digging Single Inline Trench 1. Position unit with tracks parallel with the intended digging path. 2. Fill and dump buckets. 3. Reposition unit as needed to continue trench. IMPORTANT: If operator is facing excavator when driving, unit movements are reversed.

  • Page 67: Multiple Trenches

    XT855 Operator’s Manual Dig - 66 Digging Multiple Trenches 1. Position unit in a central location to the intended digging paths. 2. Swing excavator and offset boom as needed to align with first digging path. 3. Fill and dump buckets.

  • Page 68: Systems And Equipment

    XT855 Operator’s Manual Systems and Equipment - 67 Systems and Equipment Chapter Contents Excavator Control Pattern ....68 • Change Pattern ......... . .68 •...

  • Page 69: Excavator Control Pattern

    Excavator Control Pattern Excavator Control Pattern Change Pattern The XT855 is built to operate according SAE specifications, but can be modified to operate according to ISO specifications. IMPORTANT: Numbers are scribed into hose connectors. These hose numbers are referenced in the instructions below.

  • Page 70: Operate Controls

    XT855 Operator’s Manual Systems and Equipment - 69 Excavator Control Pattern Operate Controls IMPORTANT: ISO excavator control pattern is shown. For information about SAE control pattern, see “Joysticks” on page 28. Item Description Notes Right joystick With work mode switch in excavator mode: •...

  • Page 71: Front Attachments

    Front Attachments Connect Attachment Attachment IMPORTANT: • Use only Ditch Witch approved front attachments. • Before connecting attachment to unit, ensure that mount and receiver plates are free of dirt and debris. 1. Position attachment on level surface with enough space behind it to accommodate unit.
  • Page 72 XT855 Operator’s Manual Systems and Equipment - 71 Front Attachments Hydraulic Hoses If attachment requires hydraulic power for operation, connect hydraulic hoses. Fluid or air pressure could pierce skin and cause injury or death. Stay away. NOTICE: • Escaping pressurized fluid can cause injury or pierce skin and poison.

  • Page 73: Of Optional Equipment

    XT855 Operator’s Manual Systems and Equipment - 72 Optional Equipment Operate Attachment See “Joysticks” on page 28 for a description of XT855 front-attachment controls and refer to attachment operator’s manual for specific attachment operating instructions. NOTICE: • Unit lift capacity is limited by stability. Unit is most likely to tip when arms are horizontal. A load picked up when arms are above or below horizontal can cause unit to tip when arms are moved to the horizontal position.

  • Page 74: Complete The Job

    XT855 Operator’s Manual Complete the Job - 73 Complete the Job Chapter Contents Rinse Equipment ......74 Disconnect Attachment .
  • Page 75 XT855 Operator’s Manual Complete the Job - 74 Rinse Equipment Rinse Equipment 1. Spray water onto equipment to remove dirt and mud. NOTICE: Do not spray water onto operator’s console. Electrical components could be damaged. Wipe down instead. 2. Open hood and remove dirt and debris from inside of unit.

  • Page 76: Service

    XT855 Operator’s Manual Service - 75 Service Chapter Contents Service Precautions ......76 Lubrication Overview ..... . 78 Recommended Lubricants/Service Key .
  • Page 77 XT855 Operator’s Manual Service - 76 Service Precautions Service Precautions Incorrect procedures could result in death, injury, or property damage. Learn to use equipment correctly. NOTICE: Unless otherwise instructed, all service should be performed with engine off. Working Under Raised Lift Arms Crushing weight could cause death or serious injury.
  • Page 78 XT855 Operator’s Manual Service - 77 Service Precautions Opening Hood 1. Unlatch hood at points shown. 2. Raise hood fully. 3. Position rod in slot as shown.
  • Page 79 XT855 Operator’s Manual Service - 78 Lubrication Overview Lubrication Overview See next page for service key.
  • Page 80 For more information on engine lubrication and maintenance, see your Kubota engine manual. NOTICE: • Use only genuine Ditch Witch parts, filters, approved lubricants, TJC, and approved coolants to maintain warranty. • Use the “Service Record” on page 105 to record all required service to your machine.
  • Page 81 Biodiesel blends up to 5% (B5) are approved for use in this unit. The fuel used must meet the specifications for diesel fuel shown above. Extra attention is needed when using biodiesel, especially when operating in cold weather or storing fuel. Contact your Ditch Witch dealer or the engine manufacturer for more information.
  • Page 82 XT855 Operator’s Manual Service - 81 10 Hour 10 Hour Task Notes Check coolant level DEAC Check engine oil level Check air filter Clean radiator screen Check track tension Check hydraulic fluid level Lubricate excavator Check Coolant Level Check coolant level every 10 hours. Add coolant as needed to maintain level as shown on overflow bottle.
  • Page 83 XT855 Operator’s Manual Service - 82 10 Hour Check Air Filter Check air filter restriction indicator (1) every 10 hours and change filter only when indicator reaches the red zone. Clean dust evacuator valve (2). NOTICE: Only open the air filter canister when air restriction is indicated.
  • Page 84 XT855 Operator’s Manual Service - 83 10 Hour Check Track Tension Check track tension every 10 hours. Measure length of spring as shown. When tracks are properly tensioned, spring length (A) should be 9 1/2” (241 mm). Adjust as needed (see page 92).
  • Page 85 XT855 Operator’s Manual Service - 84 10 Hour Check Hydraulic Fluid Level Check hydraulic fluid level every 10 hours. Maintain level at halfway point on sight glass (2). Add THF as needed at fill (1). Lubricate Excavator Lubricate excavator every 10 hours of use. Apply MPG at each of the 8 zerks.
  • Page 86 XT855 Operator’s Manual Service - 85 50 Hour 50 Hour Task Notes Check pump drive belt tension use belt tension meter, p/n 499-938 Check radiator Check battery Change engine oil and filter Initial, DEO Change hydraulic filter Initial Wash drive belt area...
  • Page 87 XT855 Operator’s Manual Service - 86 50 Hour Check Battery Check battery connections for wear or corrosion every 50 hours. Keep connections clean and tight. Batteries supplied by the factory are maintenance free. Service replacement batteries according to manufacturer’s instructions.
  • Page 88 XT855 Operator’s Manual Service - 87 50 Hour Change Hydraulic Filter (Initial) Change hydraulic filter after 50 hours. Wash Drive Belt Area Wash drive belt area every 50 hours. Spray low pressure water in belt area to remove dust and...
  • Page 89 XT855 Operator’s Manual Service - 88 100 Hour 100 Hour Task Notes Check fan belt tension Check front idler roller Check Fan Belt Tension Adjust fan belt as needed. 1. Turn off engine and remove key. 2. Apply moderate thumb pressure to belt between pulleys where shown.
  • Page 90 XT855 Operator’s Manual Service - 89 150 Hour 150 Hour Change Engine Oil and Filter Change engine oil after first 50 hours, and every 150 hours thereafter. 1. Remove large cover plate under unit to access drain (3, on side of pan).
  • Page 91 XT855 Operator’s Manual Service - 90 400 Hour 400 Hour Replace Fuel Filter Replace fuel filter every 400 hours. 1. Remove filter. 2. Remove old filter element and replace with a new one. 3. Apply a thin layer of fuel over the gasket and hand-tighten.
  • Page 92 XT855 Operator’s Manual Service - 91 2000 Hour 2000 Hour Change Engine Coolant Drain cooling system at drain (2). Refill (1) with approved coolant every two years or 2000 hours. NOTICE: • The use of non-approved coolant may lead to engine damage or premature engine failure and will void engine warranty.
  • Page 93 XT855 Operator’s Manual Service - 92 As Needed As Needed Location Task Notes TRACKS Adjust track tension OPERATOR Empty radiator cleanout STATION ENGINE Adjust fan belt COMPARTMENT Adjust pump drive belt use belt tension meter, p/n 499-938 Adjust Track Tension Adjust track tension as needed.
  • Page 94 XT855 Operator’s Manual Service - 93 As Needed Empty Radiator Cleanout Empty radiator cleanout as needed. 1. Remove radiator screen and the radiator cover holding the screen in place. 2. Remove plate (shown) under unit. 3. Clean out all debris from cleanout area.
  • Page 95 XT855 Operator’s Manual Service - 94 As Needed Adjust Pump Drive Belt Adjust pump drive belt as needed. 1. Turn off engine and remove key. 2. Remove front grill. 3. Raise lift arms and engage props. See “Working Under Raised Lift Arms” on page 76.
  • Page 96 XT855 Operator’s Manual Specifications - 95 Specifications General Dimensions U.S. Metric Wheelbase/track length 46 in 1.2 m Overall height of machine 89 in 2.3 m...
  • Page 97 XT855 Operator’s Manual Specifications - 96 Tool Carrier Dimensions U.S. Metric Operating height with standard bucket, max 104 in 2.6 m Hinge pin height, max 83 in 2.1 m Dump height with standard bucket, max 69 in 1.75 m Bucket rollback angle, top 115°...
  • Page 98 XT855 Operator’s Manual Specifications - 97 General Dimensions U.S. Metric Machine width 50 in 1.3 m Overall machine length, excavator stowed 120 in Weight 4440 lb 2014 kg Tool Carrier Dimensions U.S. Metric Bucket width, max 52 in 1.3 m Excavator Dimensions U.S.
  • Page 99 XT855 Operator’s Manual Specifications - 98 Performance U.S. Metric Ground drive speed, forward 4.2 mph 6.8 km/h Ground drive speed, reverse 4.2 mph 6.8 km/h Ground pressure 4.0 psi 0.28 bar Angle of departure 30° 30° Tipping capacity 2500 lb...
  • Page 100 XT855 Operator’s Manual Specifications - 99 Power U.S. Metric Engine: Kubota D1105-T-E3B diesel (EPA Tier 4i, EU stage IIIA) Cooling medium: coolant (see “Approved Coolant” on page 80.) Number of cylinders: 3 Injection: indirect Displacement 68.53 in 1123 cm Bore 3.07 in...
  • Page 101 SAE reserve capacity 110 min, SAE cold crank @ 0°F (-18°C) 800 amp, 12V electrical system Vibration Levels Under normal operation of the excavator or tool carrier of the XT855, the vibration level to the arms is 6.4 m/sec . Under the same conditions, the vibration level to the body does not exceed 2.5 m/sec Operator seat complies with ISO 7096.
  • Page 102 Return damaged parts to dealer for inspection and warranty consideration if in warranty time frame. Order genuine Ditch Witch replacement or repair parts from your authorized Ditch Witch dealer. Use of another manufacturer's parts may void warranty consideration.
  • Page 103 Subject to the limitation and exclusions herein, free replacement parts will be provided at any authorized Ditch Witch dealership for any Ditch Witch equipment or parts manufactured by The Charles Machine Works, Inc. (CMW) that fail due to a defect in material or workmanship within one (1) year of first commercial use (Exception: 2 years for all SK5 attachments).
  • Page 106 XT855 Operator’s Manual Service Record - 105 Service Record Service Performed Date Hours...
  • Page 107 XT855 Operator’s Manual Service Record - 106 Service Performed Date Hours...
