Summary of Contents for LifeGuard Lift 100287
- Page 1 OWNERS MANUAL Model # 100287 - 100289 402 E Haven St. Eaton Rapids 48827 www.lifeguardlift.com...
-
Page 2: Table Of Contents
Table of Contents Assembled Lift Lift Assembly Downtube & Seat Assembly Hardware Kits Disassembly Control System Plug Orientation Remote Control Operating Instructions Pool Entry Pool Exit Safety & Care P 10 Specifications P 10 Components P 11 Troubleshooting P 12 Warranty P 13... -
Page 3: Assembled Lift P
Assembled Lift Diagram... -
Page 4: Lift Assembly P
Lift Assembly Insert anchor bushing into the anchor. Insert the mast assembly into the anchor bushing. Make sure that the mast assembly is resting firmly inside the anchor. Attach the boom to the mast by inserting one piece of hardware kit #1. Make sure that the hardware is inserted properly with two washers on either side &... -
Page 5: Downtube & Seat Assembly P
Down Tube & Seat Assembly... -
Page 6: Hardware Kits P
Hardware Kit’s... -
Page 7: Disassembly P
Disassembly NOTE: the actuator must be in the retracted position. Remove the battery by pressing in on the latch release and lift off. Unplug the remote control, the rotation plug, and actuator plug from the control box. Unscrew the control box retaining screw and remove control box. Detach and remove the down tube/seat assembly. -
Page 8: Plug Orientation P
Control Box Plug Orientation Remote Control The lift is equipped with a waterproof remote control. The remote control is for the operator or an assistant operator. The control is brightly marked for ease of operation. The remote control is programmed to perform four (4) functions as shown in the picture. -
Page 9: Operating Instructions P
Operating Instructions Raising and Lowering Seat UP button: Pressing the UP button raises the seat when the button is depressed until the lift reaches its maximum up position. Releasing the button will stop the operation. DOWN button: Pressing the DOWN button lowers the seat when the button is depressed until the lift reaches its full down position. -
Page 10: Pool Entry P
Pool Entry When the lift is in place, make a visual inspection, and make a short test run. Using the hand controller, rotate the seat in the counterclockwise direction until it reaches a safe and comfortable position for transfer. Raise or lower the seat to the proper transfer height and raise the arm rest. Transfer the occupant onto the seat, positioning the occupant’s weight in the center of the seat. -
Page 11: Safety & Care P
Safety and Care Remove and store the lift when it is not in use. Inspect the lift each time before use to ensure that there are no worn parts or loose hardware. Check and charge the battery as needed. When cleaning the lift, use a non-abrasive soap and wipe dry with a soft non-abrasive cloth. -
Page 12: Components P
Components Linak Actuator (24V) Linak Remote Controller Linak Control Box Linak Battery - 24V Planetary Gear Motor - (Waterproof to 6ft deep) Ground Lug per NEC code. Material and Finish Aluminum: 6061 - T6 Stainless Steel: Grade 304 and/or 18-8 Lift Powder Coating: Marine Grade PART NUMBER DESCRIPTION... -
Page 13: Troubleshooting P
Trouble Shooting Problem Cause Solution Low Battery Recharge the battery Loose connections at control Firmly reconnect Seat will not rotate the cables on the control Battery not installed Reinstall battery properly Firmly reconnect cable at Seat will not raise or lower Loose connections at control control box Manufacturing defect... -
Page 14: Warranty P
Authorization form stating the date and place of purchase, a full description of the product, its serial number, the date of installation, and the exact nature of the defect. Within thirty (30) days after receipt by LifeGuard Lift of a written warranty claim, and barring any unforeseen delays, the claimant will be notified of LifeGuard Lift decision regarding the claim.
Need help?
Do you have a question about the 100287 and is the answer not in the manual?
Questions and answers
i can hear my rotation motor engagement running in side of the housing but the handy cap chair does not rotate either direction. i can move it freely .seems like something is not engaging like i said i can hear the motor running. is this a part that i can replace ? i am Not finding anytghing on line and i do not have a part number. my chair is a lifeguard lift model 100287. i have called the phone number on the lift and i get no answer and says voice mail is full. Can you please help Me ?
