- Page 1 Installation Instructions P/N 1-960557-00 Edition 1 September 2001 Industrial/EasyLAN 100i Interface Kit for XP...
-
Page 2: Table Of Contents
Chapter 1 1. Introduction Contents 1. Introduction Table of Contents ..............1 Copyright Information............2 Trademarks................2 Description ................3 Firmware Requirements ............3 Installation Kit................ 3 2. Installation Step-by-Step Instructions ............4 3. Confi guration and Connection Industrial Interface ..............8 EasyLAN 100i Interface ............ -
Page 3: Copyright Information
When your business depends on your label printer, you can depend on the Intermec EasyLAN 100i Ethernet network interface board to provide you with dependable service and advanced management capabilities. -
Page 4: Firmware Requirements
Chapter 1 Introduction Firmware Require- Printer: EasyCoder 501 XP or EasyCoder 601 XP. Firmware: Intermec Fingerprint v7.60 or later. ments The kit contains: Installation Kit • One Industrial Interface Board. • One EasyLAN 100i Ethernet Interface Board • One fl at cable •... -
Page 5: Installation Step-By-Step Instructions
Chapter 2 2. Installation This description applies to Intermec EasyCoder 501 XP and Step-by-Step Instruc- Intermec EasyCoder 601 XP. Illustrations show an EasyCoder tions 501 XP. Warning! The electronics compartment contains high voltage compo- nents and wires. Do not open the electronics compartment before the printer is switched off and safely disconnected from any AC supply. - Page 6 Chapter 2 Installation Step-by-Step Instruc- • Remove the four #T10 Torx screws that hold the interface cover plate above the parallel interface connector on the tions, cont. printer’s rear plate. Remove the cover plate. Cover Plate #T10 Torx screws (4x) •...
- Page 7 Chapter 2 Installation • Insert the EasyLAN 100i interface board with the compo- Step-by-Step Instruc- nents facing right, as seen from behind. Check that the top tions, cont. and bottom edges of the interface board fi t between the two remaining cut-outs in the rear plate.
- Page 8 Chapter 2 Installation • This diagram shows how the boards are connected. Step-by-Step Instruc- Cable tions, cont. EasyLAN 100i Industrial Interface CPU board • Put back the cover over the electronics compartment. Press fi rmly to compress the leaf springs along the front and rear edges of the electronics compartment.
-
Page 9: Confi Guration And Connection Industrial Interface
Chapter 3 3. Confi guration and Connection The Industrial Interface provides: Industrial Interface • 8 digital IN ports with optocouplers (Opto In) • 8 digital OUT ports with optocouplers (Opto Out) • 4 OUT ports with relays (Relay Out) The Industrial Interface has no straps or circuits to be fi tted or removed. - Page 10 Chapter 3 Confi guration and Connection Digital Opto Out Industrial Interface, The current to each optocoupler of the digital OUT ports cont. 221-228 can be turned on and off by means of PORTOUT ON/OFF statements. The status of the ports can be read by means of PORTIN func- tions.
- Page 11 Chapter 3 Confi guration and Connection Relay Out Industrial Interface, The relays of the OUT ports 201-204 can be individually cont. activated by means of PORTOUT ON/OFF statements. The status of the ports can be read by means of PORTIN func- tions.
-
Page 12: Easylan 100I Interface
Chapter 3 Confi guration and Connection EasyLAN 100i Inter- Follow the instructions below to connect the printer to the network via the EasyLAN 100i interface board: face • Using a category 5 unshielded twisted par cable (or better), connect the EasyLAN 100i interface board to your Local Area Network (LAN). -
Page 13: Easylan 100I Setup Assigning An Ip Address
Address This method is described in this chapter. • Remotely from the host computer. This method is described in the Intermec EasyLAN 100i User’s Always consult your network admin- Manual, which can be found in the CD-ROM included in the istrator before setting the IP address! kit. - Page 14 Chapter 4 EasyLAN 100i Setup Assigning an IP NETWORK: NETMASK Address, cont. • Press the Enter key. The display shows for example: NETMASK: 255.255.255.0 • Similar to the IP address, enter the desired netmask, then press the Enter key. NETWORK: DEFAULT ROUTER •...
- Page 15 Chapter 4 EasyLAN 100i Setup Assigning an IP • Press the Enter key. The display shows one of the following messages: Address, cont. IP SELECTION: DHCP Choosing the “Manual” option will BOOTP disable DHCP, BOOTP, or RARP. RARP MANUAL Use the F4 or F5 key to scroll in this loop of options. When DCHP, BOOTP, or RARP is displayed, press the Enter key.
-
Page 16: Reading An Assigned Ip Address
Chapter 4 EasyLAN 100i Setup If you want to read an IP address that has already been assigned— Reading an Assigned either manually or automatically—without changing any settings, IP Address proceed as follows: • Press the Setup key on the printer’s built-in keyboard. This message appears in the display window: SETUP: SER-COM, UART1... -
Page 17: Setup Mode Overview
Chapter 4 EasyLAN 100i Setup Setup Mode Overview The diagram below illustrates the hierarchy of setup options that are added to the Setup Mode when an EasyLAN 100i interface board is installed in the printer. Like most other options in the Setup Mode, these options can be changed using setup strings and fi... -
Page 18: Printing Test Label #6
Chapter 4 EasyLAN 100i Setup You can easily check the IP address and other network setup Printing Test Label #6 parameters by printing a test label. When an EasyLAN 100i inter- face board is fi tted, a sixth test label becomes available. You can print test label #6 either via the Setup Mode or via a Fingerprint application. -
Page 19: Checking The Communication
IP address. It will, for example, look like this: Refer to the Intermec EasyLAN 100i User’s Manual included on the CD-ROM that comes with the kit for explanations of how to use the home page to set up the printer, control the communication, and manage the printing.
