Summary of Contents for ECCOTARP ET-ROLLER 5
- Page 1 Electric roller for fire hoses up to 5" INSTRUCTIONS FOR USE Metal Arsenal s.r.o. ECCOTARP USA, inc. T 1 929-272-2336 E o ce@eccotarp.com Fax 212-683-8516 357 West 36th Street Owner of Eccotarp USA www.eccotarp.us New York, NY 10018 trade mark...
- Page 2 This document „Instructions for use“ (hereinafter manual) is used to get acquainted with the operation and characteristics of the ET-Roller 5 – Electric roller for fire hoses up to 5" (hereinafter „the roller“ or „the winder“), and describes the manner of its use and possible risks connected with its use.
-
Page 3: Technical Data
Types of fire hoses that can be wound up to 5" 1× Instructions for use In the ET-Roller 5 package there are 2 sizes of Removable carrier fork with a handle to ensure the ability to wind different couplings of fire hose up to 5". Optional accessories Material Dimensions (w ×... -
Page 4: Battery Replacement
Safety instructions for charging The winder is completely discharged when a slow 10. The winder is fully charged when the red indicator goes rhythmical sound signal is heard and the WORK button off and the green indicator comes on. goes off. 11. -
Page 5: Charging Station Specifications
Recomended baterries Model Yuasa NPH5-12 12V 5Ah Leaftron LTX12-5.4 CSB HR 1227W CSB HRL 1225W CSB HR 1221W (12V 5.4AH) Type VRLA Battery VRLA Baterry VRLA Baterry VRLA Baterry VRLA Baterry Voltage Capacity 5.4Ah 6.2Ah 5.8Ah 5.1Ah Weight 3.5 Lbs 3.97 Lbs 4.34 Lbs 4.3 Lbs... - Page 6 Y). If thinner, C or D size hoses, are to be wound, simply pass the coupling Hose wound according Hose wound according through (see figure Z). In the ET-Roller 5 to fig. Y – see option 2. to fig. X – see option 1. package there are 2 sizes of Removable...
- Page 7 Push the WORK button on the winder handle. Hose protector The winder starts winding the hose at a speed that – see p. 12 gradually decreases so that the winding speed is safe even with increasing diameter of the winding. Towards the end of the winding process, when the couplings get close to the lower guiding coil, it is recommended that the hose should be wound in a controlled manner by pressing...
- Page 8 diameter of the winding.Towards the end of the winding process, when the couplings get close to the lower guiding coil, it is recommended that the hose should be wound in a controlled manner by pressing the WORK button intermittently until the couplings come safely close to the guiding coil. After that the hose couplings must be manually passed under the guiding coil (tilting the winder to a side in the case of the largest hoses) and with extreme care, the rest of the hose can be wound by pressing the WORK button shortly.
- Page 9 Removing carrier fork from wound hose Winder activation SWITCH PUSH SAFETY FUNCTIONS OF THE WINDER Certain safety features influence some of the winder’s reactions during the work: Stopping the winding – If the motor becomes overloaded unexpectedly (e.g. as a result of the hose being obstructed or stepped on), the winding process is interrupted immediately, the WORK button starts blinking and a fast sound signal is heard.
-
Page 10: Reverse Function
Smart winding Your winder has a smart motor control which allows you to adjust the fire hose winding speed. The reason is your convenience and safety as well as battery protection. How does it work? After WORK is pressed, the motor begins winding at zero speed. Then it switches to the highest revs very quickly and while the hose is gradually being wound, it starts lowering the revs so that with the increasing diameter of the wound hose, the winding speed for the free end of the hose remains safe. - Page 11 The winder must be turned off – the OFF position on the control panel. Pass one end of the hose over the lower guiding coil so that you can step on this hose end. If the stabilizing fold-out chassis is tilted out, tilt it down so that the winder can stand on it without being supported. Tilt the winder towards yourself and proceed slowly with the discharging (downhill, if possible) so that the hose is rolled over the coil, which pushes the water in the hose forward, towards the other end, where the water flows out of the hose.
-
Page 12: Recommended Optional Accessories
Instructions for winder charging and storing Store the winder in a dry place. If the winder is not to be used for a long time, it should be stored at room temperature (66–73 °F). The winder system is designed in such a way that the charger can be connected to it permanently and the battery is safely recharged without any risk of damage. -
Page 13: Important Contact Information
Important contact information Qualified service: ECCOTARP USA, inc. 357 West 36th Street New York, NY 10018 office@eccotarp.com T: 1 929-272-2336 Repair Any repair work must always be done by the manufacturer’s qualified personnel. In order to report any faults, spare parts orders or complaints, please contact only our qualified service department. - Page 14 Notes...
- Page 15 Pictograph meanings Observe the Instructions for use for ET-Roller 5. During the winding process, the handle must be held with both hands and the stabilizing fold-out chassis must be secured by a leg. Caution! During winding, there is a risk of serious injury as a result of clothes or limbs being caught in the carrier.
- Page 16 The winder may only be operated by 1 person. 1 person only Before the hose is taken away from the carrier, the device must be turned off. Protect the device from direct sunlight and do not expose it to temperatures higher than 104 °F for extended periods of time.
