- Page 1 BACKPACK SPRAYER P G P S - 0 1 6 , 0 2 0 O W N E R S M A N U A L...
-
Page 2: Table Of Contents
INTRODUCTION CONTENTS This manual has been produced by Parker Products Ltd. and should be kept with the product and referenced for operation, maintenance and troubleshooting. HEALTH & SAFETY INFORMATION ................4-5 TECHNICAL DESCRIPTION ....................6-7 This manual contains an overall description of the product, together with all the PRODUCT DESCRIPTION .................... -
Page 3: Health & Safety Information
HEALTH & SAFETY INFORMATION HEALTH & SAFETY INFORMATION WORK AREA WARNING - To reduce the risk of injury, KEEP BY STANDERS AWAY - Including children and animals. • • user must read instruction manual. ALWAYS use in a well ventilated area. After every use and especially after the end of the •... -
Page 4: Technical Description
TECHNICAL DESCRIPTION TECHNICAL DESCRIPTION PGPS-016/020 PARTS INDEX SPRAY NOZZLE AIR CHAMBER HOSE OUTLET SPRAY LANCE AIR CHAMBER CAP SPRAY LANCE NUT FELT SEALING WASHER TRIGGER VALVE AIR CHAMBER STRAP WATER OUTLET TUBE FILTER BOWL HOSE VALVE SEALING BALL HOSE WATER OUTLET VALVE... -
Page 5: Product Description
FEATURES Upon opening the box of your new PGPS-016/020 please check all the parts conform to the parts index. Then assemble the machine as required. The sprayer is supplied with a selection of 3 nozzles which are suitable for the majority of spraying tasks. -
Page 6: Assembly
ASSEMBLY ASSEMBLY FIT PUMP LEVER FIT RETAINING CLIP ATTACH HANDLE TO PUMP LEVER SECURE HOSE TO AIR CHAMBER TRIGGER VALVE ATTACH HOSE TO TRIGGER ATTACH CONNECTING ROD SECURE CONNECTING ROD ATTACH HOSE TO AIR CHAMBER SECURE HOSE TO TRIGGER ATTACH LANCE TO TRIGGER ATTACH NOZZLE TO LANCE... - Page 7 ASSEMBLY ASSEMBLY THREAD STRAP THROUGH HOOK FIT TANK FILTER FIT TANK LID FIT PUMP LEVER CLAMP THREAD STRAP THROUGH CLIP LOCATE CLIP INTO HOOK SECURE HANDLE STRAP HOOK LOCATING SLOTS STRAP HOOK LOCATE HOOK INTO SLOT THREAD STRAP THROUGH LOOP THREAD STRAP THROUGH BUCKLE...
-
Page 8: Operation & Use
OPERATION & USE OPERATION & USE VOLUME OF SPRAY SOLUTIONS PREPARING SPRAY SOLUTION FILLING SPRAYING • ALWAYS prepare spray solution according to the instructions Prepare solution outside, never within living areas, When filling the spray tank always use the filter Prime the pump with a few up and down strokes of the provided by the chemical manufacturer. -
Page 9: Maintenance
• flushing it. lf the pump does not provide pressure after cleaning your Please always use ParkerBrand replacement parts available from • Empty the tank and fill with clean water (with detergent added to backpack sprayer you must also clean the pump. -
Page 10: Troubleshooting/Technical Specification
Operation Pressure (MPA) 0.2 - 0.3 Operation travel (mm) 60 - 80 Parker Products Limited Bowl Diameter (mm) Net Weight (Kg) 2.8 - 3.0 If this does not solve your problem, please contact the ParkerBrand customer service department 01507 499198. - Page 11 P G P S - 0 1 6 , 0 2 0 April 2021 Rev 1.0...
