Summary of Contents for Fastrack Reflex
- Page 1 USER MANUAL...
-
Page 2: Table Of Contents
CONTENTS What's in the Box Charging the Watch How To Get Started Pairing the Watch Setting Up Your Profile Application Dashboard Application Settings Notifications: Access & Customisation Access, Functionalities & Interface Swipe Down Swipe Left to Right Swipe Right to Left Swipe Up FEATURES My Fitness... -
Page 3: What's In The Box
Plug the USB port of the charger into a socket to charge your watch. Magnetic points behind the watch for charging Place the magnetic points at the back of the watch head here The average Battery Life of the Fastrack Reflex watch is 7 days. -
Page 4: How To Get Started
How to get Started Install the Fastrack Reflex World App Go through the features on your phone or skip to Signup Provide necessary permissions Disable Battery Optimization Accept the T&C Or skip this step... - Page 5 Enter your Phone number Enter the OTP received Press continue Finish the signup...
-
Page 6: Pairing The Watch
Pairing the Watch Follow the steps below to connect your watch to the Fastrack Reflex World app. Searching the Watch Choose your watch Select your watch Choose your watch. Select Reflex Watch. The app automatically starts Press Continue Press Continue... -
Page 7: Setting Up Your Profile
Setting Up Your Profile Enter your name, weight, gender, birth date and other related details for profile creation. The details must be correct and up-to-date for accurate measurement of activity-related metrics such as Distance Covered, Calories Burnt, etc. Enter your Name Select your Gender Enter your DOB Input your Height... - Page 8 Enter your Sleep Goal Enter your Step Goal Enter your Multisport Goal...
-
Page 9: Application Dashboard
Leaderboard Top Users Leaderboard On the Leaderboard The Fastrack Reflex watch ranks all its users based on the points earned by them. You have the option to check your global rank or city rank. User Rank Points Earned... -
Page 10: Application Settings
Application Settings Change Watch faces Set Steps goal Set Sleep goal Set Multi Sport goal Find your watch Do not Disturb Set an Alarm Back Automatically turns the screen off Set Interval for Auto HR Unpair the watch Update firmware Set unit system Report issues Sync data with Google Fit... -
Page 11: Notifications: Access & Customisation
Notifications: Access & Customisation Go to Settings and turn all the Notifications on or off. To enable/disable notifications for any individual app, use the toggle button next to it. Enable/Disable Notifications for any app Tap here to turn all the Notifications on/off... -
Page 12: Access, Functionalities & Interface
Access, Functionalities & Interface Control Center Swipe Down Swipe Left Swipe Right Swipe Up Activity Dashboard Notifications Apps Menu... -
Page 13: Swipe Down
Swipe Down Swipe down from the home screen to reach the Control Centre and access the Find my phone and Music options, and control your watch's brightness and turn notifications on/off. Home Screen Find My Phone Swipe Down for Notifiications Control Center Brightness Music... -
Page 14: Swipe Left To Right
Swipe Left to Right Swipe right to access the Activity Dashboard and view your Steps for the day, Distance covered and Calories burnt. Number of Steps Taken Home Screen Swipe Right for Activity Dashboard Distance Calories Covered Burnt... -
Page 15: Swipe Right To Left
Swipe Right to Left Swipe left from the Home screen to view your System and App Notifications. Home Screen System and App Swipe Left Notifications... -
Page 16: Swipe Up
Swipe Up Swipe Up from the Home screen to view all the Apps on your Fastrack Reflex watch. Home Screen Clock Apps Swipe Up Health Apps All Apps Active Sports... -
Page 17: Features
FEATURES My Fitness Go to Home Screen and swipe right to view your Steps taken, Calories burnt, and Distance covered. Step Count Calories Distance Burnt Covered You can also access your daily/weekly/monthly data on the Fastrack Reflex World App... -
Page 18: Multi-Sports Tracking
Pause or End Resume or End Active Sports Workout Summary Workout Summary End Workout Menu Saved Displayed Once the workout is over, the Fastrack Reflex The app also shows daily/weekly/monthly data for World app shows your workout summary your overall Multisport Summary... -
Page 19: Heart Rate
Tap on Measure HR Measuring in Progress HR Result Display The daily/weekly/monthly trends of your Heart Rate are available on the Reflex World app. Heart Rate is categorized into 3 buckets - Low Fat Burn, Medium Fat Burn, and High Fat Burn. -
Page 20: Sleep Monitor
The watch automatically records the duration of your sleep and buckets it into categories like Light Sleep and and Deep Sleep. Sleep Duration Sleep Start and End Time Sleep Categories Month Total Sleep Duration You can access your daily/weekly/monthly sleep data on the Fastrack Reflex World App. Sleep Score Sleep Categories... -
Page 21: Spo2
SPO2 From the Home Screen, swipe up and click on the Health Apps option and choose SPO2 from the list. SPO2 Result Display Tap Measure Clock Apps Clock Apps Alarm Stopwatch Timer Get notified by an Tap to start the Set a timer for the alarm vibration at Stopwatch... -
Page 22: Camera
Photo saved to Phone Gallery Note: You have to first open the Reflex World app on your phone and then click on the camera control on the watch to take a picture. Music Swipe down from the Home Screen to reach the All Apps option and choose Music. -
Page 23: Weather
Weather Tap on weather from the All Apps menu to check the current weather conditions on your watch. Note: Location services and Internet connectivity are needed for accurate weather information. All data is collated from the Open Weather online service. Find My Phone Swipe down from the home screen to get to the Control Center and tap on Find My Phone option. -
Page 24: Watch Faces
Watch Faces The Fastrack Reflex watch has 3 default watch faces and 1 cloud watch face. Users can choose from 25+ watch faces available on the Fastrack Reflex World app. - Page 25 To change the watch face using the app: Go to settings, click on watch faces and install the watch face you like. Click on Settings Install Watch Face To change the watch face using your watch: Go to settings, tap watch faces and select the watch face of your choice.
-
Page 26: Watch Settings
Watch Settings Home Screen Airplane Mode Adjust the brightness of your screen Details about the watch Reset your Smartwatch Settings All Apps... -
Page 27: Device Specifications
Device Specifications S.NO DESCRIPTION FASTRACK REFLEX WATCH 68024 Model No. Weight of the watch (With/Without strap) 35.5g /20g Display Type TFT-LCD (“UltraVu”) Display Size (inches) 1.4" 242 PPI Pixel Density (sharpness) Screen Resolution (pixels) 240*240 Thickness of Watch Head 12 mm... - Page 28 Q: How does the watch measure sleep quality? A: The Fastrack Reflex watch categorizes your sleep in buckets like Deep Sleep and Light Sleep. Based on the number of hours recorded in each bucket, you also get an overall Sleep Score.
-
Page 29: Fcc Statement
FCC Statement 1. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference. (2) This device must accept any interference received, including interference that may cause undesired operation. -
Page 30: Disclaimer
Disclaimer Note on the accuracy of Fitness Fitness Watches like the Fastrack Reflex watch are intended to be tools to provide you with information on your lifestyle and training performance and to encourage an active and healthy lifestyle. The watch relies on sensors that track your movement, sleep, and other metrics.
