Summary of Contents for VIA Technologies 8880

  • Page 2 Preface Notebook Computer 8880 Service Manual...
  • Page 3 Preface Notice The company reserves the right to revise this publication or to change its contents without notice. Information contained herein is for reference only and does not constitute a commitment on the part of the manufacturer or any subsequent ven- dor.
  • Page 4 Preface About this Manual This manual is intended for service personnel who have completed sufficient training to undertake the maintenance and inspection of personal computers. It is organized to allow you to look up basic information for servicing and/or upgrading components of the notebook PC. The following information is included: Chapter 1, Introduction, provides general information about the location of system elements and their specifications.
  • Page 5 Preface Related Documents You may also need to consult the following manual for additional information: User’s Manual on CD This describes the notebook PC’s features and the procedures for operating the computer and its ROM-based setup pro- gram. It also describes the installation and operation of the utility programs provided with the notebook PC.

  • Page 6: Table Of Contents

    Preface Contents Introduction ............1-1 Overview ......................1-1 System Specifications ..................1-2 Processor ......................1-2 Core Logic ......................1-2 Structure ......................1-2 Security ........................ 1-2 Memory ....................... 1-2 BIOS ........................1-2 LCD ........................1-2 Display ......................... 1-3 Storage ......................... 1-3 Audio ........................
  • Page 7 Removing the TV Tuner Module ..............2-11 Removing the Keyboard ................... 2-12 Removing the System Memory ................. 2-13 Removing the CPU ................... 2-14 Part Lists ............... A-1 Part List Illustration Location ................A-2 Top (8880) ......................A-3 Bottom (8880) .....................A-4 LCD 15" (8880) ....................A-5...
  • Page 8 Floppy Disk Drive (8880) .................A-15 First Hard Disk Drive (8880) ................A-16 Second Hard Disk Drive (8880) ...............A-17 Third Hard Disk Drive (8880) ................A-18 Third Hard Disk - Dummy (8880) ..............A-19 IP Sharing Module (8880) ................A-20 MP3 Player (8880) ....................A-21 Schematic Diagrams ..........B-1 System Block Diagram ..................B-2...
  • Page 9 Preface VGA DDR DRAM Term 1 of 2 ................B-16 VGA DDR DRAM Term 2 of 2 ................B-17 Moblility M7-P Power ..................B-18 TV CRT & LVDS .....................B-19 Video In 7114 ....................B-20 ICH3 1 of 2 ......................B-21 ICH3 2 of 2 ......................B-22 USB RTC ......................B-23 HDD &...

  • Page 10: Introduction

    The 8880 series notebook is designed to be upgradeable. See “Disassembly” on page 2 - 1 for a detailed description of the upgrade procedures for each specific component. Please note the warning and safety information indicated by the “...

  • Page 11: System Specifications

    Introduction System Specifications Processor • Intel Pentium 4 Processor - (478-pin) FC-PGA2 package 1.5/ 1.6 / 1.7/ 1.8/ 1.9/ 2.0/ 2.1/ 2.2/ 2.3/ 2.4 GHz Core Logic • Intel® 845 + ICH3 Structure • Fully PC99 Compliant • ACPI 1.0B Compliant •...

  • Page 12: Display

    Introduction Display • 4 * UltraAGP™ • 64MB DDR graphic memory on board • 128-bit 2D/3D graphics engine • Motion compensation and IDCT for DVD content playback accelerator • Fully DirectX 6 compliant graphics engine • CRT resolution up to 1920*1200 * 16M Storage •...

  • Page 13: Audio

    Introduction Audio • AC'97 2.2 compliant interface • Compatible with Sound-Blaster PRO™ 16 • S/PDIF Digital output (5.1 CH) for DVD content and Stereo Audio • Built-in microphone • Audio DJ • Advanced Wavetable Synthesizer • 2 built-in speakers • Virtual AC3 •...

  • Page 14: Interface

    Introduction Interface • Built-in TouchPad (PS/2) • Four USB ports • One IEEE 1394 port • One S-Video-Out jack for TV output • One S-Video-In jack • One parallel port (LPT1), supporting ECP / EPP 1.7 and 1.9 • One COM port •...

  • Page 15: Power

    Introduction Power • Full Range 120 watts AC adapter - AC in 100~240V, 47~63Hz • Supports Smart Lithium-Ion battery 12 cells Indicators • LED indicator (HDD, power status, Num Lock, Caps Lock, Scroll Lock, AC-In, battery charging, e-mail) • Audio DJ control display (power, MP3, Audio, Play/Pause, FWD, RWD, Stop, Volume+, Volume-, EQ) Environmental Spec •...

  • Page 16: External Locator - Top Views

    Introduction External Locator - Top Views Figure 1 Top Views 1. LCD 2. LED Power, Battery & E-Mail Status Indicators 3. Built-In Micro- phone 4. Hot-Key buttons 5. LED Status Indicators 6. Power Button 7. Close Cover Switch 8. Fingerprint ID (optional) 9.

  • Page 17: External Locator - Front View & Left Side View

    Introduction External Locator - Front View & Left Side View Figure 2 Front View 1. LCD Latch 2. Audio “DJ” CD Player Control Panel On/Off Switch 3. Previous Track 4. Next Track 5. LCD 6. Play/Pause 7. Stop 8. Volume Down 9.

  • Page 18: External Locator - Right Side & Rear Views

    Introduction External Locator - Right Side & Rear Views Figure 4 Right Side View 1. MP3 Player (Optional) 2. MP3 Player SD/ MMC Slot 3. MP3 Player Release Switch 4. Vent 5. Kensington Lock 6. MP3 Player Slot (no MP3 Player installed) Figure 5 Rear View...

  • Page 19: External Locator - Bottom View

    Introduction External Locator - Bottom View Figure 6 Bottom View 1. Vent/Fan Outlets 2. CPU Cover 3. Battery (the pri- mary HDD is located under the battery) 4. Primary Hard Disk 5. Changeable Drive Bay 3 (for TV Tuner or HDD) 6.

  • Page 20: Disassembly

    Disassembly 2: Disassembly Overview This chapter provides step-by-step instructions for disassembling parts and subsystems. When it comes to reassembly, reverse the procedures (unless otherwise indicated). Component Parts We suggest you completely review any procedure before you take the computer apart. Procedures such as upgrading/replacing the RAM, CD device and hard disk are included in the User’s Manual but are repeated here for your convenience.

  • Page 21: Maintenance Tools

    Disassembly NOTE: All disassembly procedures assume that the system is turned OFF, and disconnected from any power supply (the battery is removed too). Maintenance Tools The following tools are recommended when working on the notebook PC: • M3 Philips-head screwdriver •...

  • Page 22: Maintenance Precautions

    Disassembly Maintenance Precautions The following precautions are a reminder. To avoid personal injury or damage to the computer while performing a re- moval and/or replacement job, take the following precautions: Power Safety Warning 1. Don't drop it. Perform your repairs and/or upgrades on a stable surface. If the computer falls, the case and other Before you undertake components could be damaged.

  • Page 23: Disassembly Steps

    Disassembly Disassembly Steps The following table lists the disassembly steps, and on which page to find the related information. PLEASE PERFORM THE DISASSEMBLY STEPS IN THE ORDER INDICATED. To remove the Keyboard: To remove the Battery: 1. Remove the battery page 2 - 5 1.

  • Page 24: Removing The Battery

    Disassembly Removing the Battery Figure 2 - 1 Battery Removal 1. Turn the computer OFF and turn it over. Sequence 2. Remove screws in Figure 2 - 1a. 3. Apply gentle pressure at point to push the battery up and out of the computer. a.

  • Page 25: Removing The Primary Drive Bay (Bay One) Cd Device

    Disassembly Removing the Primary Drive Bay (Bay One) CD Device Figure 2 - 2 Primary Drive 1. Turn the computer OFF, remove the battery (page 2 - 5) and turn it over. (Bay One) CD 2. Remove screws in (Figure 2 - 2a), then lift the cover off the changeable drive bay and set it aside.

  • Page 26: Removing The Modular Drive Bay (Bay Two) Device

    Disassembly Removing the Modular Drive Bay (Bay Two) Device Figure 2 - 3 Modular Drive 1. Turn the computer OFF, remove the battery (page 2 - 5) and turn it over. (Bay Two) Device 2. Remove screws in (Figure 2 - 3a), then lift the cover off the changeable drive bay and set it aside.

  • Page 27: Removing The Primary Hard Disk

    Disassembly Removing the Primary Hard Disk Figure 2 - 4 Primary Hard 1. Turn the computer OFF, remove the battery (page 2 - 5) and turn it over. Disk Removal 2. Remove screws (Figure 2 - 4a) and release the HDD connector cable Sequence 3.

  • Page 28: Removing The Hard Disk Drive In Bay Two

    Disassembly Removing the Hard Disk Drive in Bay Two Figure 2 - 5 Bay Two HDD 1. Turn the computer OFF, remove the battery (page 2 - 5) and turn it over. Removal 2. Remove screws (Figure 2 - 5a), then lift the cover off the changeable drive bay and set it aside.

  • Page 29: Removing The Hard Disk Drive In Bay Three

    Disassembly Removing the Hard Disk Drive in Bay Three Figure 2 - 6 Bay Three HDD 1. Turn the computer OFF, remove the battery (page 2 - 5) and turn it over. Removal 2. Remove screws (Figure 2 - 6a), then lift the cover off the changeable drive bay and set it aside.

  • Page 30: Removing The Tv Tuner Module

    Disassembly Removing the TV Tuner Module Figure 2 - 7 TV Tuner Module 1. Turn the computer OFF , remove the battery (page 2 - 5) and turn it over. Removal 2. Remove screws ( Figure 2 - 7a ), then lift the cover off the changeable drive bay and set it aside.

  • Page 31: Removing The Keyboard

    Disassembly Removing the Keyboard Figure 2 - 8 Keyboard 1. Turn the computer OFF and remove the battery (page 2 - Removal 2. Press the two keyboard latches at the top of the keyboard to elevate the keyboard from its normal position (you may Sequence need to use a small screwdriver to do this).

  • Page 32: Removing The System Memory

    Disassembly Removing the System Memory Figure 2 - 9 Memory Removal 1. Turn the computer OFF , remove the battery (page 2 - 5) and keyboard (page 2 - 12). Sequence 2. Remove screws ( Figure 2 - 9a ) from the shielding plate ( Figure 2 - 9b ), and lift the plate up off the computer.

  • Page 33: Removing The Cpu

    Disassembly Removing the CPU Figure 2 - 10 Processor 1. Turn the computer OFF , remove the battery (page 2 - 5) and turn it over. Removal 2. Remove screws ( Figure 2 - 10a ), and lift the cover ( Figure 2 - 10b ) up off the computer.
  • Page 34 Disassembly 4. Remove screws & ( Figure 2 - 12a ) from the CPU bracket, then lift the bracket off the CPU ( Figure 2 - Figure 2 - 12 12b ). Processor 5. Fully raise latch in the direction indicated in Figure 2 - 12c to unlock the CPU. Removal 6.
  • Page 35 Disassembly 2 - 16...

  • Page 36: Part Lists

    Part Lists Appendix A:Part Lists This appendix breaks down the notebook PC’s construction into a series of illustrations. The component part numbers are indicated in the tables opposite the drawings. Note: This section indicates the manufacturer’s part numbers. Your organization may use a different system, so be sure to cross-check any relevant documentation.

  • Page 37: Part List Illustration Location

    Part Lists Part List Illustration Location The following table indicates where to find the appropriate part list illustration. Table 1 Part List Illustration Part 8880 8880 Location page A - 3 page A - 13 DVD-ROM Drive page A - 4...

  • Page 38: Top (8880

    Part Lists Top (8880) Figure 1 Top (8880) Top (8880) A - 3...

  • Page 39: Bottom (8880

    Part Lists Bottom (8880) Figure 2 Bottom (8880) A - 4 Bottom (8880)

  • Page 40: Lcd 15" 8880

    Part Lists LCD 15" (8880) Figure 3 LCD 15" 8880 LCD 15" (8880) A - 5...

  • Page 41: Lcd 15.7" 8880

    Part Lists LCD 15.7" (8880) Figure 4 LCD 15.7" 8880 A - 6 LCD 15.7" (8880)

  • Page 42: Battery (8880

    Part Lists Battery (8880) Figure 5 Battery (8880) Battery (8880) A - 7...

  • Page 43: Center Cover (8880

    Part Lists Center Cover (8880) Figure 6 Center Cover (8880) A - 8 Center Cover (8880)

  • Page 44: Center Cover Finger (8880

    Part Lists Center Cover Finger (8880) Figure 7 Center Cover Finger (8880) Center Cover Finger (8880) A - 9...

  • Page 45: Cd-Rom Drive (8880

    Part Lists CD-ROM Drive (8880) Figure 8 CD-ROM Drive (8880) A - 10 CD-ROM Drive (8880)

  • Page 46: Cd-Rw Drive (8880

    Part Lists CD-RW Drive (8880) Figure 9 CD-RW Drive (5600P) CD-RW Drive (8880) A - 11...

  • Page 47: Combo Drive (8880

    Part Lists Combo Drive (8880) Figure 10 Combo Drive (8880) A - 12 Combo Drive (8880)

  • Page 48: Dvd-Rom Drive (8880

    Part Lists DVD-ROM Drive (8880) Figure 11 DVD-ROM Drive (8880) DVD-ROM Drive (8880) A - 13...

  • Page 49: Audio Dj (8880

    Part Lists Audio DJ (8880) Figure 12 Audio DJ (8880) A - 14 Audio DJ (8880)

  • Page 50: Floppy Disk Drive (8880

    Part Lists Floppy Disk Drive (8880) Figure 13 Floppy Disk Drive (8880) Floppy Disk Drive (8880) A - 15...

  • Page 51: First Hard Disk Drive (8880

    Part Lists First Hard Disk Drive (8880) Figure 14 First HDD Drive (8880) A - 16 First Hard Disk Drive (8880)

  • Page 52: Second Hard Disk Drive (8880

    Part Lists Second Hard Disk Drive (8880) Figure 15 Second HDD Drive (8880) Second Hard Disk Drive (8880) A - 17...

  • Page 53: Third Hard Disk Drive (8880

    Part Lists Third Hard Disk Drive (8880) Figure 16 Third Hard Disk Drive (8880) A - 18 Third Hard Disk Drive (8880)

  • Page 54: Third Hard Disk - Dummy (8880

    Part Lists Third Hard Disk - Dummy (8880) Figure 17 Third Hard Disk - Dummy (5620P) Third Hard Disk - Dummy (8880) A - 19...

  • Page 55: Ip Sharing Module (8880

    Part Lists IP Sharing Module (8880) Figure 18 IP Sharing Module (8880) A - 20 IP Sharing Module (8880)

  • Page 56: Mp3 Player (8880

    Part Lists MP3 Player (8880) Figure 19 MP3 Player (8880) MP3 Player (8880) A - 21...
  • Page 57 Part Lists A - 22...

  • Page 58: Schematic Diagrams

    Schematic Diagrams Appendix B:Schematic Diagrams Table 1 Schematic This appendix has circuit diagrams of the systems PCB’s. The following table indicates where to find the appropriate Diagrams schematic diagram. Diagram - Page Diagram - Page Diagram - Page System Block Diagram - Page B - 2 VGA DDR DRAM Term 2 of 2 - Page B - 17 KBC H8 - Page B - 32 CPU (Northwood) 1 of 2 - Page B - 3...
  • Page 59 Schematic Diagrams System Block Diagram 8880 SCHEMATIC CK TITAN MOBILITY M7 INT#A Clocking PREQ0# GNT#0 PCI1520 SERIRQ AD25 Intel Pentiun 4 PREQ1# GNT#1 TSB43AB21 INT#B AD18 /Northwood processor PREQ3# GNT#3 LAN RTL8100 INT#C AD16 PREQ2# GNT#2 MINI PCI SERIRQ INT#A...
  • Page 60 Schematic Diagrams CPU (Northwood) 1 of 2 VCORE DP3# T144 DP2# T142 DP1# T143 DP0# T164 HA35 T163 HA34 T157 U34A HA33 T160 HD[0..63] HA32 HD[0..63] T154 HA[3..31] 5 HA31 HA30 LAYOUT NOTICE: HA29 LAYOUT NOTICE: HA28 LAYOUT NOTICE: HD[0..63] LAYOUT NOTICE: HA27 HD[0..15]»Ýµ¥ªø, »~®t...

  • Page 61: Cpu (Northwood) 1

    Schematic Diagrams CPU (Northwood) 2 of 2 GTLREF GENERATION CIRCUITS VCC3S R292 49.9_1% VCORE R293 C426 C427 C428 VCORE 100_1% 1U_0805_X7R 220P_X7R 220P_X7R VCORE R308 IERR# R313 R270 49.9_1% R312 R290 FERR# BR0# R305 51_1% VCORE FERR# 20 PROCHOT# R302 56_1% R271 C382...
  • Page 62 Schematic Diagrams CPU Decoupling CLOSE TO SO DIMM Put the cap on the North side of the processor BACK SIDE CPU DECOUPING VCORE C389 C391 C394 C400 C405 C411 C417 C419 C421 C372 C371 C370 C369 C368 CP10 VCORE 10U(1206) 10U(1206) 10U(1206) 10U(1206)
  • Page 63 Schematic Diagrams MCH (Host, AGP, Hub) HD[0..63] HD[0..63] MCH STRAP R381 R249 8.2K(R) VCC1.5S 533Mhz R378 1K(R) U36A 400Mhz R382 8.2K(R) HA[3..31] HA[3..31] R763 55_1% R765 10 C1009 10P HA3# R764 55_1% CPU66IN_MCH HA4# HA5# BCLK# MCHCLK# 10 HA6# BCLK MCHCLK 10 HA7# +-10mils...
  • Page 64 Schematic Diagrams MCH (Voltage, PLL, USS) R244 49.9_1% MCH_GTLREF VCORE U36C C999 Use 20mils trace,7mils space Voltage C1000 Place RES C1001 C1002 C309 C288 4.7U(1206) CAP should be placed near MCH 2.5V_DDR R245 4.7U(1206) Reference divider near VCC1.5S 0.1U 0.1U 1U(0805) 0.01U 100_1%...

  • Page 65: Mch (Ddr

    Schematic Diagrams MCH (DDR) 1.25V 1.25V C276D110 C276D110 C276D110 C276D110N C276D110 C209 0.1U C208 0.1U C210 0.1U C211 0.1U C212 0.1U C213 0.1U U36B C214 0.1U C215 0.1U C276D110 C276D169 C276D169 C276D169 C276D91 C672 0.1U C258 0.1U DDR Interface C206 0.1U C205 0.1U...

  • Page 66: Ddr Termination

    Schematic Diagrams DDR Termination 1.25V RN44 8P4R_22 SDQ0 MD[0..63] 1.25V MAAR1 SDQ[0..63] MD[0..63] 9 SDQ1 MAAR3 RN39 SDQ2 MAAR0 8P4R_56 SDQ3 RN94 MAAR2 SDQ4 RN83 8P4R_56 MAAR4 SDQ5 8P4R_22 MAAR5 RN84 SDQ6 MAAR6 8P4R_56 SDQ7 RN30 MAAR7 SDQ8 8P4R_56 MAAR10 SDQ9 RN43 MAAR9...

  • Page 67: Ddr Sodimm

    Schematic Diagrams DDR SODIMM 2.5V_DDR 2.5V_DDR MD[0..63] MD[0..63] MAAR[0..12] MAAR[0..12] MAAR0 MAA0 MAA[0..12] MAA[0..12] 7,8 MAAR1 MAA1 MAAR2 MAA2 MAAR3 MAA3 MAAR4 MAA4 MAAR5 MAA5 MAAR6 MAA6 MAAR7 MAA7 MAAR8 MAA8 MAAR9 MAA9 MAAR10 MD10 MD10 MAA10 A10/AP DQ10 DQ10 A10/AP MAAR11 MD11...

  • Page 68: Clk

    Schematic Diagrams CLOSED CK-408 L109 BK2125S121(R) VCC3 BK2125S121 VCC3_CLKA VCC3S VCC3 13,18,20,21,27..30,32,33,35,36,38,41,43 C322 C334 C329 CK-408/ICS950201/W320-04S VCC3S 2,3,9,11,17..21,23,24,26..33,36..38,40 10U(1206) 0.1U 0.1U L110 BK2125S121(R) VCC3 VDDA VSSA BK2125S121 VCC3_CLK VCC3S VDD48 VSS48 VSSPCI C320 C509 C357 C336 C340 C350 C353 C360 C328 C338 C348...
  • Page 69 Schematic Diagrams Mobility M7 - P G_AD[0..31] G_AD[0..31] U21A G_AD0 GPIO0 GPIO0 G_AD1 Part 1 of 5 GPIO1 GPIO1 G_AD2 GPIO2 GPIO2 G_AD3 GPIO3 VCC3S GPIO3 G_AD4 GPIO4 GPIO4 T328 G_AD5 GPIO5 GPIO5 T329 G_AD6 GPIO6 GPIO6 T330 AGP 1X clock feedback G_AD7 GPIO7 GPIO0...

  • Page 70: Mobility M7 - P

    Schematic Diagrams Mobility M7 - P Mem A/B VDDC1.8 3,6..8,38,42 1.25V 14,16,17 VDD_MEM_IO 13,15 VREF OPTIONAL SERIES OPTIONAL SERIES TERMINATION MEMORY CHANNEL A TERMINATION MEMORY CHANNEL B FOR MEMORY FOR MEMORY ADDR & CNTRL ADDR & CNTRL INSTALL INSTALL RESISTORS RESISTORS CLOSER TO CLOSER TO...
  • Page 71 Schematic Diagrams VGA DDR DRAM 1 of 2 VCC3 VCC3 R469 SSIN SSOUT 11 ICLK C591 R475 0.1U R179 +1.25V_MEM R472 0(R) C249 0.1U VCC3 MK1707(R) R468 R464 R476 C646 0.01U 0(R) 0(R) 0(R) +2.5V_MEM +2.5V_MEM MEM_MAA[13..0] 12,14 MEM_MDA[63..0] MEM_MDA[63..0] 14 MEM_MDA0 MEM_MDA32 Sheet 13 of 45...
  • Page 72 Schematic Diagrams VGA DDR DRAM 2 of 2 CHANNL B MEM_MDB[63..0] 16 VREF 12,13 +2.5V_MEM +2.5V_MEM 13 +2.5V_MEM MEM_CSB0# 12,16 MEM_RASB# 12,16 MEM_MAB[13..0] 12,16 MEM_CASB# 12,16 MEM_MDB0 MEM_MDB32 MEM_MDB1 MEM_MAB0 MEM_MAB0 MEM_MDB33 MEM_MDB2 MEM_MAB1 MEM_MAB1 MEM_MDB34 MEM_MDB3 MEM_MAB2 MEM_MAB2 MEM_MDB35 MEM_WEB# 12,16 MEM_MDB4 MEM_MAB3...
  • Page 73 Schematic Diagrams VGA DDR DRAM Term 1 of 2 MDA[63..0] Close to memory device MDA[0..63] MEM_MDA[63..0] 13 Between memory and M7 middle MDA0 MEM_MDA0 +1.25V_MEM MDA1 MEM_MDA1 1.25VS +1.25V_MEM +1.25V_MEM MDA2 RN66 8P4R-22 MEM_MDA2 RP16 MDA3 MEM_MDA3 MDA4 MDA4 MEM_MDA4 MDA5 L(1206)(R) MDA5...

  • Page 74: Vga Ddr Dram 1

    Schematic Diagrams VGA DDR DRAM Term 2 of 2 +1.25V_MEM MDB[63..0] MDB[0..63] Between memory and M7 middle Close to memory device MEM_MDB[63..0] MEM_MDB[63..0] 15 +1.25V_MEM RP34 MDB0 MEM_MDB0 MDB27 MDB1 RN17 MEM_MDB1 MDB26 C780 C245 MDB28 MDB2 8P4R-22 MEM_MDB2 MDB25 MDB29 MDB3 MEM_MDB3...

  • Page 75: Moblility M7-P Power

    Schematic Diagrams Moblility M7-P Power U21D U21E VDDC VDDC Part 4 of 5 VDDC VDDC Part 5 of 5 VDDC VDDC VCC1.5S VDDC VDDC VDDC 2.3A VDDC VDDC VDDC VDDC VDDC VDDC VDDC VDDC VDDC VDDC C687 C693 C648 C641 C628 C625 C601...

  • Page 76: Tv Crt & Lvds

    Schematic Diagrams TV CRT & LVDS VCC5S VCC5S VCC3S VCC3S VCC3S FCM2012V-301 C531 R414 C282 D33 1N4148(R) Close to CRT DB15 CN13 DA221(R) DA221(R) DA221(R) DA221(R) DA221(R) VCC5S 75(1%) C268 CRMA COMP/B DDCDATA FCM2012V-121 R201 100 0.1U COMP/B DDCDATA CN14 FCM2012V-301(R) DDCLK FCM2012V-121...
  • Page 77 Schematic Diagrams Video In 7114 R780 0(R) CRMA FCM2012V-301 C1024 0.01U T_C/R C314 C516 R398 CN12 75(1%) CRMA Video_GND COMP FCM2012V-301 C514 R393 C319 LUMA 75(1%) SVIDEO_CON R781 0(R) Video_GND LUMA FCM2012V-301 C323 C331 C1025 0.01U R233 T_Y/G 75(1%) VCC3S VCC3S C501 C517...

  • Page 78: Ich3 1

    Schematic Diagrams ICH3 1 of 2 2.5V 6,9,27,38,42 VCC1.8S VDD1.8 VCC3S VCC3 SYS3V VCC3 10,13,18,21,27..30,32,33,35,36,38,41,43 VCC3S 2,3,9..11,17..19,21,23,24,26..33,36..38,40 2.5V_DDR 4,6,7,9 VCC1.8S 6,17,21,28,42 PDD[0..15] PDD[0..15] 23 U46A VDD1.8 28,45 VCC1.5S PDD0 PDD0 A20M# AB11 PDD1 DPSLP# 10K(R) A20M# 2,3,43 DPSLP# A20M# PDD1 FERR# AA10 PDD2...

  • Page 79: Ich3 2

    Schematic Diagrams ICH3 2 of 2 VCC5S 2/21 modifty VCORE VCC1.5S VCC1.8S VCC3S VCC5REF VCC5REF C1031 0.01U R792 R793 R753 R630 C894 C156 R101 VCC3 C1032 0.1U R555 0(R) 1U(0805) 0.1U 0.1U 27,31,37 PWRSW# PWRBTN# 31 0(R) RB751V SUSB# SUSPEND# 10,30,38,42,44,45 SUSB# SUSPEND# 33,36...

  • Page 80: Usb Rtc

    Schematic Diagrams USB RTC Close to USB-PLUG SYS3V SYS5V VCC_RTC USBVCC0 F01J2E R560 J8JOPEN VCC5 R538 VCCRTC VCCRTC 21 F3 FUSE_1210(R) 750_1% 1SS355 F01J2E C393 C387 HF50ACB321611T C782 10U(1206)(R) 0.1U 2K_1% R110 1U(0805) USB-PLUG V+_OUT1 USBP0- R643 18.2_1% BK1608HS121 USBP0- BAT1 DATA_L1 C175...

  • Page 81: Hdd & Cd-R/W & Mp3 Cnn

    Schematic Diagrams HDD & CD-R/W & MP3 CNN SCD-L SCD-R 24 SCD-GND CON2 IDE1RST# VCC5S SVCC5VS SDD[0..15] 3906 SDD[0..15] 20,26 R528 PHD_LED F1AJ3 SDD[0..15] R108 SDD8 VCC5S HD_LED 37 20,26 SDD[0..15] SYS5V SDD7 SDD9 1N4148 SDD6 SDD10 9410 SDD7 SDD5 SDD11 PIDEACT# R519...

  • Page 82: Amp Tpa0132/Alc201A 1

    Schematic Diagrams AMP TPA0132/ALC201A 1 of 2 ALC201 AD1886 BK2125HS121(0805) VCC5S For some crystal, BK2125HS121(0805) VDDA Pin27 0.1UF VCC3S U2 78L05(SO8)(R) the bias resistor is needed Pin33 0.047UF Z813 VDDA Pin32 0(0805)(R) C943 C944 R706 1M(R) Pin31 R689 10U(1206) 0.1U 0.1U 10U(1206) 0(R)

  • Page 83: Amp Tpa0132/Alc201A 2

    Schematic Diagrams AMP TPA0132/ALC201A 2 of 2 VCC5S CD_ROM5V F1AJ3 SYS5V CON26 SEG0 SEG0 9410 SEG1 SEG1 SEG2 SEG2 SEG3 SEG3 SEG4 SEG4 SEG5 SEG5 SEG6 SEG6 SEG7 SEG7 R562 COM0 COM0 COM1 COM1 VOLUME+ VOLUME+ 30 C810 R563 VOLUME- 330K VOLUME- 30 C805...

  • Page 84: Audio Dj Cd-Rom

    Schematic Diagrams Audio DJ CD-ROM CD_ROM5V OZ165 IDE1RST# RP33 R530 CINTRQ SDD[0..15] IDE1RST# CRESETN 20,23 SDD[0..15] CRESETN HRESETN CRESETN CDD6 SDD0 CDD0 HDD[0] CDD[0] CDD0 CDD5 CDD0 SDD1 CDD1 CDD1 HDD[1] CDD[1] CDD4 CDD1 SDD2 CDD2 HDD[2] CDD[2] CDD2 CDD2 SDD3 CDD3 CDD3...

  • Page 85: Fan Control

    Schematic Diagrams Fan Control R742 10K(R) VCC3 VCC5S 40MIL JFAN2 Z173 R743 PWROK FAN_VCC 2.5V RESET# PWROK 10,21 C991 C992 L100 R744 100K 4.7U(1206) 0.1U RST-IN VCC3S C993 F01J2E L(1206) R745 C(0805) FAN CON VCC5S FAN_GND 40MIL 100K C994 MAX6306UKD3 0.1U VCC5S JFAN3...

  • Page 86: Flash Rom Lpt1

    Schematic Diagrams Flash ROM LPT1 Place near ICH3 VDD1.8 SYS3V C155 C120 C103 C904 C800 C104 C121 C157 C153 C105 0.1U 0.1U 0.1U 10U(1206) 0.1U 0.1U 0.1U 0.1U 0.1U 0.1U 0.1U 0.1U 10U(1206) SD[0..7] SD[0..7] VCC3S STB0# STB0# VCC5S C161 C160 C147 C141...
  • Page 87 Schematic Diagrams LPC Bridge & Super I/O VCC3S CLKRUN# RTSA# R719 4.7K(R) RIA# R714 T292 MEMR# R699 R703 VCC3S R(10K) BIOSCS# R704 FSMI# R(10K) LAD[0..3] 21,31,40 LAD[0..3] LAD0 3MODE# R721 LAD0 LAD1 DRV0# INDEX# R722 LAD1 DR0# DRV0# 30 POWER LAD2 MTR0# 8P4R-10K...
  • Page 88 Schematic Diagrams I/O Connector FIRVCC SYS3V 0_0805 VCC3S 10U(1206) C119 VCC5S 4.7U(1206) VOLUME+ VOLUME+ VOLUME- 0.1U 0.1U C133 VOLUME- RN116 RN115 R797 0(R) EXT_GPI 10,21 SUSA# EXT_GPI 31 8P4R-18 8P4R-18 T372 25,26 STOP_EJECT 25,26 25,26 R731 KB-CTL0 INDEX# 25,26 PLAY_PAUSE KB-CTL0 31 INDEX# KB-CTL1...
  • Page 89 Schematic Diagrams KBC H8 3VH8 BOOT_FLASH# BOOT_FLASH# VCC3S 3VH8 3VH8 R695 R663 R685 MAX823S_SOT23 R701 150K VCC5 2N7002 10K(R) 3VH8 KBVCC3 H8_RESET# 30,37 RESET# A20GATE A20GATE 20 3VH8 HEARTBEAT SLEEP# 25,39 CIR_RX SLEEP# C935 0_0805 0.1U(R) 1N4148 2N7002 C937 C938 C934 0.1U VCC3S...
  • Page 90 Schematic Diagrams Mini PCI/MDC T345 T346 RING T347 T348 8PMJ-3 8PMJ-1 T349 T350 8PMJ-6 8PMJ-2 T351 T352 8PMJ-7 8PMJ-4 T353 8PMJ-8 8PMJ-5 T355 LED1_GRNP LED2_YELP T357 C814 10U(1206) LED1_GRNN LED2_YELN T359 CHSGND RSVD 20,33,35,36,39 INT#B INTB# VCC5 R593 3.3V INTA# INT#A 11,20,33 VCC3...
  • Page 91 Schematic Diagrams PCI 1520 VCCA VCCB U44-2 U44-3 VCCA VCCB A_D10 B_D10 A_D10 B_D10 A_CAD31/A_D10 B_CAD31/B_D10 VCC3 A_D9 B_D9 A_D9 B_D9 A_CAD30/A_D9 B_CAD30/B_D9 A_D1 B_D1 A_D1 B_D1 U44-1 A_CAD29/A_D1 B_CAD29/B_D1 A_D8 B_D8 A_D8 B_D8 A_CAD28/A_D8 B_CAD28/B_D8 A_D0 B_D0 20,32,35,36,39 AD[0..31] A_D0 B_D0 VCCP...
  • Page 92 Schematic Diagrams PCMCIA Connector CN19 VCCB VCCA B_D0 A_D0 B_D0 A_D0 B_D0 A_D0 B_D1 A_D1 B_D1 B_D1 A_D1 A_D1 B_D2 A_D2 B_D2 B_D2 A_D2 A_D2 B_D3 C850 A_D3 C116 B_D3 A_D3 B_D3 A_D3 B_D4 A_D4 B_D4 A_D4 B_D4 A_D4 B_D5 0.1U A_D5 0.1U...
  • Page 93 Schematic Diagrams 1394 TSB43AB21 2/21 modifty VCC3 2/21 modifty R559 4.7K C812 C807 C816 C836 VCC3 R542 R107 4.7K 0.01U 0.1U 0.01U 10U(1206) R574 4.7K R575 4.7K C172 C134 C124 C125 C126 C142 C162 C166 C171 C168 AD[0:31] AD[0:31] 20,32,33,36,39 10U(1206) 10U(1206) 0.1U...
  • Page 94 Schematic Diagrams LAN RTL8100B VCTRL VCTRL SYS3V LANVDD3 LANVDD3 LANVDD3 LANVCC2.5 F01J2E 2SB1198K VCC3 C916 C915 C932 0.1U 0.1U 0.1U 0.1U 0.1U F01J2E BK2125HS121 *For RTL8100C application, all bead must be rated C933 300mA/100ohm@100Mhz 10U(1206) 10U(1206) 0.1U The maximum voltage drop when on should be less than 0.3V 10U(1206) 0.1U DE-COUPLE CAPS PLEASE CLOSE CHIP POWER PIN...
  • Page 95 Schematic Diagrams LED Indicator SYS3V 0.1U LEDDATA SCROLLOCK LEDDATA SCROLLOCK CN20A NUMLOCK LF-H80P L102 SRC-1394-201 NUMLOCK CAPSLOCK CAPSLOCK PWR/SUS_LED RXIN1+ PWR/SUS_LED 18 CHA/BATLOW CHA/BATLOW 18 LEDCLK BAT_FULL RXIN1- LEDCLK BAT_FULL 18 E-MAIL E-MAIL 18 H8_RESET# R684 0(R) 0.1U 30,31 H8_RESET# ACIN_LED 18 TXD1- 74LV164...
  • Page 96 Schematic Diagrams Power Plane SYS5V Si4800 VCC5 VCC5S R170 R492 100K 100K SUSB+ C227 C225 0.1U C700 10U(1206) 0.1U R327 21,30,42,44,45 SUSB# R324 2N7002 R322 2N7002 R323 R325 VID0 VR_VID0 VID0 VR_VID0 43 VID1 VR_VID1 VID1 VR_VID1 43 Si4800 VID2 VR_VID2 VID2 VR_VID2 43...
  • Page 97 Schematic Diagrams TV Tuner/Fingerchip 2/21 modifty VCC5 TV Tuner C750 C189 4.7U(1206) 0.1U CN17 Sheet 39 of 45 20,32,33,35,36 20,32,33,35,36 20,32,33,35,36 20,32,33,35,36 TV Tuner 20,32,33,35,36 20,32,33,35,36 PCLK_TUNER 20,32,33,35,36 20,32,33,35,36 Fingerchip 20,32,33,35,36 20,32,33,35,36 20,32,33,35,36 AD10 AD11 20,32,33,35,36 20,32,33,35,36 AD12 AD13 20,32,33,35,36 R137 20,32,33,35,36 AD14...
  • Page 98 Schematic Diagrams W83518D Media Reader VCC3S MS_VCC3S 200MA MS_MSAPWCTL# VCC3S SI2301DS 0.1U 10U(1206) RN114 8P4R_4.7K Memory Stick Socket Circuit. Sheet 40 of 45 VCC5S VCC3S W83518D Media VDD3V MS_VCC3S VCC3S C981 Reader 0.1U 0.1U R723 MS_MSAPWCTL# 4.7K MSAPWCTL#/SDAPWCTL# C988 MD_MS1 MD_MS1 MSA1/SDA1 LAD[0..3]...
  • Page 99 Schematic Diagrams System Power 1 SCH (+3V, +5V, +12V) 42,45 VIN1 1SS355 PC151 0.1A 12VIN PC131 PC145 PC149 PC153 PC146 PC148 0.1U(0805) 0.1U(0805) 470U/35V PC155 470U/35V 10U/25V 0.1U PC24 PC22 PD35 0.1U(0805) RB751V 11FS2 10U/25V *10U/25V PC157 0.1U PD34 PC12 BST3 SYS3V PL10...
  • Page 100 Schematic Diagrams System Power 2 SCH (+2.5V, +1.8V, +1.5V, +1.25V) VIAS AT 2.5V VCC1.8S LEAST6-Ó VIAS AT MIC29302BU(TO263) LEAST6-Ó PC163 PR173 PC165 ON/OFF PD24 PR100 PR171 10K 1% 41,45 VIN1 0.1U 1SS355 INTVCC PR170 SUSB PC64 PC76 PR172 PC166 PR174 41,45 VIN1 0.1U(0805)
  • Page 101 Schematic Diagrams VCORE VCC3 PR63 VCC3 PR61 PQ34 PR76 PC61 DTA114EUA PR84 *10K(M) PR73 PR108 *0(M) VIN2 INTVCC1 PQ42 *10K(M) *0.1U(M) PC85 PR62 10(0805) VIN2 *2N3906(M) PQ43 PR70 *2N3904(M) PR67 PR56 VR_PWRGD 42,45 DD_ONH PC74 PC69 *10K(M) RUN/SS INTVCC1 VIN3 PQ40 PQ36 PQ50...
  • Page 102 Schematic Diagrams Charger-PWM PQ12 2.5A Si4835 2.5A PD10 PR36 25m(2512) PQ56 CDRH-1205-470 03A04 DTA114EUA PC119 PC118 PR37 PC20 PC139 PD31 PR137 PD11 PC122 PC41 1N4148 0.1U(0805) 470U/35V 0.1U(0805) 0.1U(0805) 100K 03A04 470U/35V 0.1U(0805) PR136 PC42 PQ57 *1000P DTC114EUA PR34 PR32 SYS3V SYS3V PR23...
  • Page 103 Schematic Diagrams 3VH8 VDD1.8 SYS3V SYS3V SYS5V 3VH8 SYS3V VDD1.8 PQ14 MIC5245-3.3BM5 MIC5247-1.8BM5 DTA114EUA PR175 PR163 PR39 DD_ONH 42,43 PC168 PC158 PR134 PC167 DD_ON# 41 PQ13 0.01U 0.01U 21,25..27,31 DD_ON 2N7002 PC115 PQ54 0.1U DTC114EUA Sheet 45 of 45 3VH8 VDD1.8 SYS3V PD26 PQ62...
