Techwall Electronics BAP-2 Instruction Manual

1． Power On/Off button①；Power ON；Long press Power
On/off button to switch on the purifier. Indicator⑦light on
and the purifier start to work. Power OFF ； Long press
Power On/off button can switch off the purifier. The
indicator⑦will light off，the unit stop working. Wake up；
short press button ① can wake up touch function ， and
touch function indicator will light on. The function
indicator will automatically turn off after 10 seconds of no
operation.
2. Fan speed ② ； Fan speed can be adjusted to 3 levels,
high/medium/low ， press button ② can change fan speed.
Screen ⑨ can show current fan speed。
3. Automatic Fan speed mode ③；press ③ can activate /
disable automatic fan speed mode，if this mode is activated fan
speed will be changed automatically depending on air quality of
current environment.
4. Filter replacement indicator ④； need to replace a new filter if
this indicator light on. See diagram below, unscrew the bottom
cover to replace a new filter.
5. Display of Temperature / Humidity ； press ⑤ to switch
between temperature and humidity on screen.
BAP-2 Instruction Manual
