PTC-0110BA2UM, REV(A) IMPORTANT SAFETY INSTRUCTIONS • 110BA-2 contains an internal high voltage, high energy power source (96VDC battery) large high voltage (340VDC) capacitors. • The unit should not be tampered with by unauthorized personnel !!! • Turning off the Input ON/OFF Switch and/or disconnecting the input connector do not turn off the UPS !!! •...
PTC-0110BA2UM, REV(A) General Description Intended Applications 110BA-2 is a high quality, rugged, 400Hz IN 60Hz OUT, 1kW / 2KVA, 19” rack-mounted interruptible Power Source (UPS). In addition to full compliance with all the requirements of MIL- STD-1399 (Section 300), the 110BA-2 is specifically designed to meet the harsh military ship environment.
Page 5
PTC-0110BA2UM, REV(A) RFI FILTER ISOLATION RFI FILTER & VARISTOR TRANSFORMER & VARISTOR AC INPUT 115VAC,400Hz Power Conditioner Low Voltage To 2 POLES INPUT Contactors 2 POLES OUTPUT CONTACTOR CONTACTOR AC-DC DC-AC 320 Vdc CONVERTER INVERTER AC OUTPUT 115VAC,60Hz REMOTE INPUT...
PTC-0110BA2UM, REV(A) 2. (Deleted) nstallation Instructions Before installing the unit, please read carefully the Safety Instructions at the beginning of this manual. Make sure that the Master switch is in the OFF position. Two circular connectors (J1 and J2) are provided on the rear panel of the UPS (see Figure 5). J1 is the input connector, J2 is the output of the UPS.
PTC-0110BA2UM, REV(A) Front Panel Description Front Panel: Main Components (See Figure 3) Removable air filter (of the Power Conditioner’s cooling air). Visual Indicators and Switches (for detailed view see Figure 4). Air Inlet (of main UPS heatsink). Input ON/OFF Switch.
PTC-0110BA2UM, REV(A) Front Panel: Indicators and Switches (See Figure 4) Input ON/OFF switch. Master ON/OFF switch. Input Fail LED (red). Input OK LED (green). Output Standby LED (yellow). Output OK LED (green). 10. Output Fail LED (red). 11. On Battery Warning LED (blinking yellow).
PTC-0110BA2UM, REV(A) Operation, Controls and Indicators (ref. Figures 3 and 4) Turning the UPS ON and OFF In order to turn the UPS ON (after the electrical connections are made), turn ON the Input ON/OFF switch (4), the Master ON/OFF switch (5) and if used, the remote ON/OFF switch. (The order is not important).
Page 10
PTC-0110BA2UM, REV(A) Operation, Controls and Indicators (ref. Figures 3 and 4) Turning the UPS ON and OFF In order to turn the UPS ON (after the electrical connections are made), turn ON the Input ON/OFF switch (4), the Master ON/OFF switch (5) and if used, the remote ON/OFF switch. (The order is not important).
Page 11
PTC-0110BA2UM, REV(A) IMPORTANT SAFETY INSTRUCTIONS • 110BA-2 contains an internal high voltage, high energy power source (96VDC battery) large high voltage (340VDC) capacitors. • The unit should not be tampered with by unauthorized personnel !!! • Turning off the Input ON/OFF Switch and/or disconnecting the input connector do not turn off the UPS !!! •...
Charge-Discharge Cycles Temperature The battery used in the PTC-0110BA-2 is sealed and does not “dry up” or lose gasses, but its end of service life is brought about by the gradual corrosion of the electrodes. This process is accelerated by high operating temperatures. Every 10°C rise above 20°C will reduce the battery service life by half.
Replacing the Battery Pack For ease of use, the battery of the PTC-0110BA-2 is packaged within a Removable Battery Pack (P/N M357380) that may be ordered separately. During storage, the Battery Pack may be removed and stored separately in a cooled ambient.
PTC-0110BA2UM, REV(A) Communications and Remote Control Dry Contacts Interface Dry Contacts Interface is available through connector J3 ( a DB9 male connector located on the rear panel). This interface allows control and monitoring of the UPS by a server. Two configurations are available: Option 0 (Standard) and Option 1.
Page 15
PTC-0110BA2UM, REV(A) 8.1.2 Option 1 Dry Contacts Interface Table 2 shows J3 pin assignment for Option 1. In this option the server interfaces to the UPS via a quasi - RS232 communication link Table 2 Dry Contacts Connector J3 Pin Assignment, Option 1...
UPS.) This interface allows control and monitoring of the UPS by a host computer through the serial RS232 communication link. For further information about this feature refer the PTC-0120BA-1 Software User Manual. Table 3 shows the standard RS232 pin assignment.
PTC-0110BA2UM, REV(A) Specifications Voltage 85-140 VAC without switching to battery power. INPUT (below this level the battery will be used). Frequency 360-440 Hz Power Factor > 92% Spikes 200 joules clamping device Isolation Input is galvanically isolated from output and chassis (> 1 MΩ at 600VDC).
Page 18
The alarm may be silenced by pressing the "Alarm Off" push-button on the front panel. d) Power The PTC-0110BA-2 has two double-pole contactors, one on the input and Switches one on the output. The input ON/OFF contactor is controlled by the input ON/OFF switch located on the front panel.
Page 19
PTC-0110BA2UM, REV(A) Discrete Four dry contacts indicating the following conditions: INTERFACE interface "UPS ON" (Output OK) "Battery Voltage Low" "Input Power Loss" (Battery Operation) "Fault Detect" A "Shutdown" input (via opto-isolator) for remote shutdown of the UPS during AC input fail. When the AC input recovers the UPS will automatically turn ON.
