5. ASSEMBLY

Fit handles to doors, use M4x30mm screws
Fit rollcab castors (5"x2"). Attach with M8x20mm screws.
Tighten with spanner.
Fit seat handle, use M4x30mm screws.
Bearing Installation
Position the bearing over the holes on side panel. Attach with 2
bolts (M8 x 35mm) and washers and tighten with hex key.
Repeat this process on the opposite side of the seat.
© Jack Sealey Limited
Fit side handle at swivelling castor end. Attach with 4 M6x16mm
screws, tighten with hex key.
Position slider up to holes on inside panel. Attach with
M6x12mm screws, tighten with screwdriver and hex key.
Fit seat castors (3"x1") use M6x16mm bolts.
