- Page 1 YZ-S4 Floor Sweeper instruction manual 安 徽 扬 子 工 业 科 技 有 限 公 司 ANHUI YANGZI INDUSTRIAL TECHNOLOGY CO., LTD.
- Page 2 YZ-S4 YZ- S4 electric driving sweeper Welcome to use yz-s4 electric driving sweeper, to provide you with satisfactory service is our constant pursuit of Yangzi. The company specializes in the production of electric driving sweeper, the equipment introduces foreign advanced technology, adopts surface maintenance free power supply, integrates suction and sweeping, has strong cleaning ability, no pollution and no noise.
- Page 3 CATALOG 1. Fuselage appearance 2. Technical parameters 3. Operating instructions (1) Panel control (2) Travel accelerator, brake, lift pedal (3) Disassembly and installation of dustbin (4) Charging 4. Daily maintenance and replacement of wearing parts (1) Replacement of main brush (2) Replacement of side brush 5.
- Page 4 Instruction Manual YZ-S4 Part I fuselage appearance 1. Steering wheel and operation panel 4. Double disc brake 2. Lighting 5. Dustbin 3. Side brush 6.Main brush...
- Page 5 Instruction Manual YZ-S4 Part II technical parameters PARAMETER MODEL DATA Sweeping width 1250 Side brush width 2*220 working hours 2-2.5 Walking motor Battery capacity V/ah 48v/65ah Total weight Width of main brush work efficiency m2/h 6000 Garbage capacity Roller brush motor...
- Page 6 Instruction Manual YZ-S4 Part III operating instructions Panel description （1） 1. Power switch, turn on the power to the right and turn offthepowertotheleft 2. Forward and backward switch 3. Floor sweeping switch 4. Headlamp switch 5. Sprinkler switch 6. Horn switch 7.
- Page 7 Instruction Manual YZ-S4 Removal and installation of dustbin （3） If it is necessary to clear the garbage, first pull the buckle of the dustbin upward, and then pull the handle of the dustbin backward to separate the dustbin from the sweeper. After...
- Page 8 Instruction Manual YZ-S4 Part IV daily maintenance and replacement of vulnerable parts 5 4 3 2 1. Main brush 5. Whenthefixingnutofthemainbrush 2. Fixing nut of mainbrush side baffle connecting plate needs to be replaced 3. Main brush side baffle or cleaned, open the left door and screw 4.
- Page 9 Instruction Manual YZ-S4 PartV precautions It is forbidden to operate the sweeper by non （1） professionals It is strictly forbidden to clean the silk and （2） ribbon articles Deep discharge is strictly prohibited （3） It is strictly forbidden to park on the slope （4）...
- Page 10 Instruction Manual YZ-S4 (1) If the button of sweeping switch fails, replace the switch. (2) If the travel switch fails, adjust the main brush wire rope to make the travel switch work; ifthe travel switch is damaged, replace it (3) If 100A contactor is damaged, replace it.
- Page 11 Instruction Manual YZ-S4 8. Steering wheel failure Under normal conditions, the main causes of steering wheel failure are: (1) the chain above the front wheel is loose or broken, so replace the chain in time. (2) If the connecting spline of steering wheel is loose, tighten the spline locking screw.
-
Page 12: Inspection Certificate
Inspection Certificate Number： Model Motor Accessories Power cable Switch Shell Suction Control Fuselage Function Manual Package Warranty Card Number： Name Tell Mailing address Bill Purchase time number Fuselage Product number number Replacement Date parts Fault description: Warranty conditions: 1. Withinthedateofpurchase,themotorisguaranteedforoneyear(ifitismorethan7daysfromthedateof purchase, no replacement, only warranty).
