BT6016
COMMUNITY DESIGN
No. 001713280-0030
Installation Safety Notes.....................................................................................................................2
Parts List.............................................................................................................................................4
Installation Instructions........................................................................................................................6
Product Dimensions............................................................................................................................7
B-Tech Contact Details.......................................................................................................................8
INSTALLATION TOOLS REQUIRED
B-TECH AUDIO VIDEO MOUNTS
FLAT SCREEN VIDEO CONFERENCING
CAMERA SHELF
INSTALLATION GUIDE & PARTS LIST
This Pack Contains 1 Camera Shelf
PLEASE KEEP THIS FOR FUTURE REFERENCE
CONTENTS
www.btechavmounts.com
FEATURES
●
Video Conferencing Camera Shelf
designed for cameras up to 3kg (6.6lbs)
●
Suitable for flat screens with a depth between
10mm (0.4") - 135mm (5.3")
●
Central slot for attaching cameras with
single point fixing
●
Easy to install
Slotted
screwdriver
Advertisement
Summary of Contents for B-Tech BT6016
-
Page 1: Table Of Contents
Central slot for attaching cameras with single point fixing ● Easy to install COMMUNITY DESIGN No. 001713280-0030 CONTENTS Installation Safety Notes........................2 Parts List.............................4 Installation Instructions........................6 Product Dimensions..........................7 B-Tech Contact Details........................8 INSTALLATION TOOLS REQUIRED Slotted screwdriver B-TECH AUDIO VIDEO MOUNTS www.btechavmounts.com... -
Page 2: Installation Safety Notes
Do not attempt to install this product until all instructions and warnings have been read and properly understood. Please keep these instructions for future reference. B-Tech International Limited, its distributors and dealers are not liable or responsible for damage or injury caused by improper installation, improper use or failure to observe these safety instructions. - Page 3 Niniejszy produkt musi być zamontowany na odpowiedniej powierzchni, a podczas użytkowania nie wolno przekraczać podanego maksymalnego obciążenia. A B-Tech International Ltd. recomenda que a instalação deste produto seja efectuada por um instalador de AV profissional ou outra pessoa devidamente habilitada. A B-Tech International Ltd. e os seus distribuidores e concessionários não são responsáveis por danos ou lesões causados por uma instalação incorrecta.
-
Page 4: Parts List
BT6016 PARTS LIST Suitable for loads up to 3kg (6.6lbs) - Page 5 PART NAME CAMERA SHELF M8 LONG HANDWHEEL M8 SHORT HANDWHEEL FOAM PAD RUBBER CAP UNC 1/4" X 3/4" SLOTTED SCREW M6 METAL WASHER PLEASE KEEP THIS FOR FUTURE REFERENCE...
-
Page 6: Installation Instructions
INSTALLATION INSTRUCTIONS Fix the most suitable handwheels Fix the camera in place using (parts 2 or 3) to the back of the parts 6 and 7 (OPTIONAL). camera shelf, then attach the rubber caps. VC CAMERA USE LONG HANDHWEELS FOR SLIM FLAT SCREENS Place the camera shelf onto the top of the flat screen, then adjust handwheels to level shelf. -
Page 7: Product Dimensions
24mm 0.4" 0.9" 135mm 5.3" 85mm 3.3" 142mm 90mm 5.6" 3.5" 135mm 5.3" 360mm 14.2" 8.5mm 0.3" THESE INSTRUCTIONS ARE INTENDED AS A GUIDE ONLY AND B-TECH ACCEPTS NO LIABILITY FOR THE ACCURACY OF THE INFORMATION CONTAINED IN THIS DOCUMENT. -
Page 8: B-Tech Contact Details
©2010 Bennett Technologies Limited. All rights reserved. B-Tech Audio Video Mounts is a division of Bennett Technologies Limited. B-Tech and Better By Design are registered trademarks of Bennett Technologies Limited. All other brands and product names are trademarks of their respective owners.
