- Page 1 Assembly Instructions W18N4062W Please read this manual carefully before beginning assembly of this product.Keep this manual for future reference.
-
Page 4: Tools Required
Shelf support pin Cam bolt Screw Screw Cam lock Wooden dowel Ø5x25mm Ø3x12mm Ø3x14mm Ø6x35mm Ø15x10mm Ø6x30mm x 21 x 21 x 16 x 18 x 10 Plastic wedge Screw Magnetic plate Handle Hinge Magnetic catch Ø4x12mm Bolt Screw Anchor L-iron Ø4x18mm Ø6x30mm... - Page 5 · Gently screw cam bolts (A) into panels(1,2). · Stick parts(Q) on panels(1,2) as shown. ３...
- Page 6 Finished edge · Insert dowel(C) into panels(5,7). · Attach panels(5,7) to panel(2). · Insert and secure cam locks(B) to panels(5,7) to lock it.
- Page 7 · Insert dowels(C) into panels(5,7). · Attach panel(1) to panels(5,7). · Insert and secure cam locks(B) to panels(5,7) to lock it.
- Page 8 · Attach parts(H) to panels(9,10) with screws(D). · Gently screw cam bolts(A) into panels(8,9,10).
- Page 9 · Insert dowels(C) into panels(9,10), then attach panels(9,10) to panel(8). · Attach panels(8,9,10) to panels(1,2,7). · Insert and secure cam locks(B) to panels(1,2,7) to lock it.
- Page 10 ·Carefully insert panel(4) into the slot of panels(1,2,7).
- Page 11 · Gently screw cam bolts(A) into panel(3). · Attach magnetic catch(I) to panel(3) with screws(E). · Attach L-iron(N) to panel(3) with screws(G).
- Page 12 · Insert dowels(C) into panels(1,2,9,10). · Attach panel(3) to panels(1,2,9,10). · Insert and secure cam locks(B) to panels(1,2) to lock it.
- Page 13 · Secure parts(J) with screws(E).
- Page 14 Finished edge · Insert the shelf supports(F) at the desired level and place the adjustable shelf(6) onto the shelf supports.
- Page 15 · Attach parts(K) to panels(11,12) with screws(D). · Attach parts(L) to panels(11,12) with bolts(M).
- Page 16 · Attach panels(11,12) to panels(9,10) with screws(D).
- Page 17 Note: We recommend it to be fixed to the wall to prevent the furniture from tipping over. Wall anchor and hardware are included in the package. Please make sure hardware is suitable for your walls before installation, as different wall materials may require different types of anchors.
