Summary of Contents for Dust Free Duality-Mini-UV
- Page 1 Duality-Mini-UV Installation & Operation Manual DF Duality – Mini UV - #19200...
-
Page 2: Before Installing
GENERAL Duality - Mini UV is designed to fit and function in compact areas of HVAC components. Germicidal ultraviolet (UVGI) helps inactivate viruses and bacteria* on damp surfaces ensuring the optimal efficien- cy of your system. Based on results from the testing of SARS CoV-2, MS2, Bacillus Thuringiensis, Staphylococcus Epidermis, Aspergillus Niger, and Serratia Marcescens. -
Page 3: Safety Information
SAFETY INFORMATION UV WARNING High intensity ultraviolet light. Exposure to direct LED UV light may be harmful. Always protect eyes and skin from UV LEDs. Never look directly into UV LEDs during operation. Disconnect before servicing. After installation, all UV light should remain internal within the installed unit. -
Page 4: Specifications
SPECIFICATIONS SPECIFICATIONS Dimensions 4''L x 2.3''W x 1''H, Power Module 102.4mm L x 60mm W x 27mm H LED Strip 8.8''L x 0.4''W, 224mm L x 10.5mm W VOC filters 7.87''L x 2.3''W x 0.1''H, 200mm L x 60mm W x 2.5mm H Electrical 90-240V. -
Page 5: Installation
INSTALLATION Power connection STEP 1 STEP 1 STEP 2 Power plug Disconnect power from your system. Remove the Cover STEP 4 STEP 3 Connect the power Have a line from the UV qualified driver into the electrician power supply feed remove the of the system. - Page 6 INSTALLATION LED Driver and Airflow Sensor STEP 1 Airflow sensor LED driver Mount the LED Driver and airflow sensor above air conditioner. UV LED Strips STEP 1 Determine the best location for the UV LEDs (see UV Installation Notes). To ensure proper adhesion of 3M tape, thoroughly clean and dry area before mounting UV LEDs.
- Page 7 INSTALLATION VOC filters STEP 1 Take out the AC filters and clean with a dry cloth. STEP 2 Air filter Determine the best location for the VOC filters and fix it with provided filter clips. (Make sure the light coming off of the UV LEDs will shine directly through VOC filter VOC filter.
-
Page 8: Warning Label
EPA Device Manufacturer Establishment No. 73316-TX-1. The product and technologies described are not medical devices, and are not intended to diagnose, treat, cure, or prevent any disease or illness. For replacement UV LED arrays contact Dust Free, LP. Replacement Duality UV Array: Part # 19201... - Page 9 Dust Free USA PO Box 519, 1112 Industrial Park Drive Royse City, TX 75189 1-972-635-9564 www.dustfree.com www.dustfree.eu...
