- Page 1 RFID POS READER V2 User’s Manual 10092348 Last Updated: April 29, 2014 Revision * Checkpoint Systems International GmbH Brentanostraße 27-29 69434 Hirschhorn (06272)928-0 MOD POS READER TR4250...
- Page 2 Checkpoint Systems, Inc. This guide and the products discussed in this guide are the exclusive property of Checkpoint Systems Inc. Copyright laws of the United States protects all information and products.
-
Page 3: Table Of Contents
Checkpoint Systems Intern. GmbH Company Confidential Table of contents 1 REVISION CONTROL ..................4 1.1 ..................4 EVISION ISTORY 2 BASIC SAFETY INFORMATION ................5 2.2 ..............6 OTE ABOUT THE DISPOSAL OF OLD UNITS 3 OPERATING INSTRUCTIONS ................6 ... -
Page 4: Revision Control
Checkpoint Systems Intern. GmbH Company Confidential For Internal Use Only 1 Revision Control 1.1 Revision History Content changes to this document from its previous version to the current level are indicated by Microsoft Word track changes bars (|) in the left margin of the document unless a complete rewrite is indicated. -
Page 5: Basic Safety Information
Checkpoint Systems Intern. GmbH Company Confidential For Internal Use Only 2 Basic safety information Read these operating instructions before using the RFID POS READER V2 for the first time! Make yourself completely familiar with the installation and operation of the RFID POS READER V2 ! Retain these operating instructions for later reference. -
Page 6: Operating Instructions
Within the member countries of the European Union In accordance with the European Union guideline 2002/96/EC, Checkpoint Systems takes back old devices within the member countries of the European Union and disposes of them in an appropriate way. The devices concerned by this are marked with the symbol shown aside. -
Page 7: Installation
Checkpoint Systems Intern. GmbH Company Confidential For Internal Use Only ATTENTION The RFID POS READER V2 antenna ports may be susceptible to damage from static discharge or other high voltage. Use proper Electrostatic Discharge (ESD) precautions to avoid static discharge when handling or making connections to the RFID POS READER V2 antenna or communication ports. -
Page 8: Accessories
Checkpoint Systems Intern. GmbH Company Confidential For Internal Use Only 3.3 Accessories 3.3.1 Power Supply The RFID POS READER V2 can be powered either by suitable AC/DC-Adapter or by Power over Ethernet (PoE). When using AC/DC-Adapter, PoE is switched off automatically. -
Page 9: Setup For Test And Demo
PoS under Desk shielded deactivation PAD EU 3.4 Setup for Test and Demo Set up PC with Checkpoint´s Demo Software Configure network adapter of PC with suitable IP-Address Connect power supply for reader and check if Power LED is on... - Page 10 Checkpoint Systems Intern. GmbH Company Confidential For Internal Use Only Select: Inventory Settings Configure: Antenna Mode, RF-Power, Trigger Mode, etc. Last Updated: 6/3/2014 11:10 AM 10 of 20...
- Page 11 Checkpoint Systems Intern. GmbH Company Confidential For Internal Use Only Configure advanced Gen2 settings and start inventory TAGs in RF-field are listed in Tag List View Last Updated: 6/3/2014 11:10 AM 11 of 20...
-
Page 12: Battery Replacement
Checkpoint Systems Intern. GmbH Company Confidential For Internal Use Only 3.5 Battery Replacement Picture shows battery in holder Plus Minus Battery: Coin Cell CR1632 3V 110mAh Before replacing battery measure battery voltage with voltmeter. New battery has 3V. Buffered SRAM and clock work with voltage down to 2V. Replace battery so soon as voltage is down to 2.2V... -
Page 13: Technical Data
Checkpoint Systems Intern. GmbH Company Confidential For Internal Use Only 4 Technical Data 4.1 Mechanical Data Size : 7.1 x 4.6 x 1.2 in (180 x 115 x 30 mm) Weight: 0.7 lbs (320g) Case material Plastic Color Black Connectors... -
Page 14: Front View
Checkpoint Systems Intern. GmbH Company Confidential For Internal Use Only 4.2 Front view RS232 ANT1 ANT2 ANT3 ANT4 Connector Connector Status LED’s Heart Beat LED ANT1 ANT2 ANT3 ANT4 Power On 4.3 Rear view USB1 USB2 USB3 RESET DIGILAL INPUTS DIGITAL INPUTS AND Outputs... -
Page 15: Reader Specifications
Checkpoint Systems Intern. GmbH Company Confidential For Internal Use Only 4.4 Reader Specifications Power Connection Input Voltage 12 VDC, Minimum 10V, Maximum 24V Input current 0.75 A at 12 VDC Power Consumption 3W ( typical while idle) 6 W ( typical at 500 mW conducted RF output power) -
Page 16: Environment Specifications
Checkpoint Systems Intern. GmbH Company Confidential For Internal Use Only 4.5 Environment Specifications Operating temperature 23F to 113F ( -5C to 45C ) Storage temperature - 40F to 158F ( -40C to 70C ) Relative Humidity 5% to 95 % non-condensing 4.6 Digital I/O Specification... -
Page 17: Ethernet Lan Specification
Checkpoint Systems Intern. GmbH Company Confidential For Internal Use Only 4.7 Ethernet LAN Specification Connector RJ-45 Ethernet 10/100 BaseT Indicators Yellow Indicates link is operational Green Indicates network traffic detected. Signals Pin 1 TXD+ (Transmit Data +) Pin 2 TXD- (Transmit Data -) -
Page 18: Usb Specification
Checkpoint Systems Intern. GmbH Company Confidential For Internal Use Only 4.9 USB Specification USB UART Converter (dual) Connector Female USB Type B Signals Pin 1 VCC (+5V) Pin 2 - DATA Pin 3 + DATA Pin 4 USB OTG Connector... -
Page 19: Ordering Information
Checkpoint Systems Intern. GmbH Company Confidential For Internal Use Only 5 Ordering Information The UHF-RFID Reader is available with the following number Order Number: 10112394 RFID POS READER V2 6 Glossary RFID Radio Frequency Identification. Electronic Product Code, a unique item identification number... -
Page 20: Annex Declaration Of Conformity
Checkpoint Systems Intern. GmbH Company Confidential For Internal Use Only 7 Annex Declaration of Conformity EMC limits and radio approvals EMV for Short Range Device ETSI EN 301 489-3 Safety of equipment of low voltage device EN 60950-1 Approval for UHF RFID READER; Europe ETSI EN 302 208-1 Approval for Short Range Device;...
