Important - If you receive a broken or missing
part. Please contact our Customer Service
Center immediately @ 1-888-658-1658 for
assistance.
Customers agree to hold Outdoor Living Today and any Authorized Dealers free of any
liability for improper installation, maintenance and repair of any Outdoor Living Today
products.
Outdoor Living Today
12ft X 16ft Breeze Pergola
Assembly Manual
Outdoor Living Today
Note: Post Mounting Hardware is NOT
included in this kit. Please confirm with your
local building permit office to determine the
correct hardware in your area.
www.outdoorlivingtoday.com
Page 1
Important - Western Red Cedar Lumber and
Timbers will have surface splitting that occurs
as lumber seasons and drys to the moisture
content in your area. Splitting or "checking", as
it is referred to, can be 1/8" to 1/4" wide and can
run several feet. This does not diminish the
structural integrity of the material in any way.
sales@outdoorlivingtoday.com
Revision #3
Feb /2007
Advertisement
Related Manuals for Outdoor living today Breeze 12ft X 16ft
Summary of Contents for Outdoor living today Breeze 12ft X 16ft
- Page 1 This does not diminish the structural integrity of the material in any way. Customers agree to hold Outdoor Living Today and any Authorized Dealers free of any liability for improper installation, maintenance and repair of any Outdoor Living Today products.
- Page 2 1 Day (does not include site preparation) (2 Left / 2 Right) Specifications: O - Post Skirting (new) 6 Pkgs (4 skirting pcs / 4 top caps - 45 degree cut) Outside Dimension: 192” x 144” x 108” Outdoor Living Today www.outdoorlivingtoday.com sales@outdoorlivingtoday.com Page 2...
- Page 3 Side Girder is square cut on one end. Complete 2 sets of Side Girder / Post sections. Make sure Girder / Post connections are square. 8” Bolts 13.5” Side Girder (E) positioned 1/2 way on Post. Deep Notch facing down and inside Completed Post/ Side flush with post. Girder Section. Outdoor Living Today www.outdoorlivingtoday.com sales@outdoorlivingtoday.com Page 3...
- Page 4 Side Girders. The End Girder has a deep notch facing up on each end. Lift, position and attach the second Post/ Side Girder section to post hardware. Deep Notch facing Up. Outdoor Living Today www.outdoorlivingtoday.com sales@outdoorlivingtoday.com Page 4...
- Page 5 Joist, attach each Stub Joist with 2 - 3” screws. 10 Stub Joists (I). Stub Joists should be flush with top and bottom Main Joists are pre-marked for Stub Joist and of Main Joist with all notches facing down. Blocking position. Outdoor Living Today www.outdoorlivingtoday.com sales@outdoorlivingtoday.com Page 5...
- Page 6 1 - 4” screw Attach all Stub Joists to girders with 1 - 4” screw per Stub 4” long Joist. Screw from screws the top down into girder. Outdoor Living Today www.outdoorlivingtoday.com sales@outdoorlivingtoday.com Page 6...
- Page 7 Step 15. Carefully lift up one of the Ladder Sections and place between Side Girders. You will require a helper to assist in lifting up the ladder section. Outdoor Living Today www.outdoorlivingtoday.com sales@outdoorlivingtoday.com Page 7...
- Page 8 Middle Ladder Section. Use only as 2nd Ladder guide, space Section may vary. Attach Ladder to Side Girders with 4 - 4” screws per Ladder. Screw from top 4” screws down into girder. Outdoor Living Today www.outdoorlivingtoday.com sales@outdoorlivingtoday.com Page 8...
- Page 9 Joist Mount is flush with bottom of Blocking or Main Joists. Please note that bracket can mount up higher but using the bottom will make it easier to align all brackets later. Outdoor Living Today www.outdoorlivingtoday.com sales@outdoorlivingtoday.com Page 9...
- Page 10 Corner Bracket Post Mount (K) as per Step 20. however. Position Bracket so even with outside brackets and attach post mount to post with 6 - 2” Stainless Steel Screws. Attach Bracket at top using 2 - 4” screws. Outdoor Living Today www.outdoorlivingtoday.com sales@outdoorlivingtoday.com...
- Page 11 Birds Eye View of Breeze showing position of Brackets, Ladder Sections with Blocking and outside Joist Mount Stub Joists. Outdoor Living Today www.outdoorlivingtoday.com sales@outdoorlivingtoday.com Page 11...
- Page 12 @ 1-888-658-1658 or email us at service@outdoorlivingtoday.com. Thanks again! Customers agree to hold Outdoor Living Today and any Authorized Dealers free of any liability for improper installation, maintenance and repair of any Outdoor Living Today products. Outdoor Living Today www.outdoorlivingtoday.com...
