Mercury 50-879150A85 Quick Start Manual

Starter motor kit 75/90/115 efi, 80/100 eu efi fourstroke
Hide thumbs
1
2
3
4
5
6

Advertisement

Quick Links

Download this manual
50-879150A85
STARTER MOTOR KIT
75/90/115 EFI, 80/100 EU EFI FOURSTROKE
IMPORTANT: This document guides our dealers, boatbuilders, and company service
personnel in the proper installation or service of our products. If you have not been trained
in the recommended servicing or installation procedures for these or similar Mercury
Marine products, have the work performed by an authorized Mercury Marine dealer
technician. Improper installation or servicing of the Mercury product could result in
damage to the product or personal injury to those installing or operating the product.
NOTE: After completing installation, place these instructions with the product for
the owner's future use.
Components Contained in Kit
Ref.
a
b
c
d
e
f
g
h
i
90-879312059 JUNE 2009
a
Qty.
1
Starter motor assembly
1
Cable assembly
4
Bolt (M8 x 45 hex flange)
4
Washer
2
Hose clip
2
Nylon push‑in screw
1
J‑clamp
2
Oetiker clamp (15.7 mm)
1
Hose
b
i
Description
© 2009 Mercury Marine
c
d
e
f
g
h
41588
Part Number
879345T77
84‑93388A8
10‑885526 45
12‑43430
54‑8M0040205
10‑8M0037204
54‑814634
54‑888988‑015
32‑8M0040122
Page 1 / 6

Advertisement

loading
Need help?

Need help?

Do you have a question about the 50-879150A85 and is the answer not in the manual?

Questions and answers

Related Manuals for Mercury 50-879150A85

Summary of Contents for Mercury 50-879150A85

  • Page 1 If you have not been trained in the recommended servicing or installation procedures for these or similar Mercury Marine products, have the work performed by an authorized Mercury Marine dealer technician.

  • Page 2: Starter Removal

    STARTER MOTOR KIT Starter Removal WARNING Performing service or maintenance without first disconnecting the battery can cause product damage, personal injury, or death due to fire, explosion, electrical shock, or unexpected engine starting. Always disconnect the battery cables from the battery before maintaining, servicing, installing, or removing engine or drive components.

  • Page 3: Starter Installation

    STARTER MOTOR KIT 7. Remove the water hose and discard. 41700 J‑clips Bolts (M8 x 40) (4) Water hose Starter Installation NOTE: If the mounting bushings are not installed in the starter housing, refer to Mounting Bushing Installation 1. Assemble one of the mounting bolts with the metal J‑clip and a washer. NOTE: The metal J‑clip is assembled on top of the washer on the lower right starter mount.
  • Page 4 STARTER MOTOR KIT Hose Clamp Tool Kit 91‑803146A04 Aids in the installation of high pressure (Oetiker ®) hose clamps. Clamp Tool (91‑803146T) 5819 41688 Starter Washer and bolt (M8 x 45) (4) J‑clip Plastic clip Water hose Oetiker clamp (15.7 mm) (2) Description lb‑in.
  • Page 5 STARTER MOTOR KIT 17. Allow the Liquid Neoprene to dry and slide the red protection boot over the starter solenoid positive (+) cable connection. 41680 Crankcase ventilation hose Nut, lockwasher, and red protection boot Hose clips Starter ground cable Plastic push‑in screw Negative (–) battery cable Yellow/red wire Bolt...
  • Page 6 Products of Mercury Marine Mercury, Mercury Marine, MerCruiser, Mercury MerCruiser, Mercury Racing, MotorGuide, Mercury Precision Parts, Mercury Propellers, Mariner, Quicksilver, #1 On The Water, Alpha, Bravo One, Bravo W6250 Pioneer Road Two, Bravo Three, Pro Max, OptiMax, Sport-Jet, K-Planes, MerCathode, RideGuide, SmartCraft, Zero...
