- Page 1 Pneumatic presses series M Operation and maintenance manual ΑΦΟΙ ΓΑΒΡΙΗΛΙΔΗ Α.Ε.Β.Ε. Σταδίου 101, Τ.Κ. 59100 Βέροια Τηλ. 23310 20262 Fax 23310 20263 http://www.agroenos.com...
- Page 2 If shipping damage is found, note it on the packing list and report the damage to the carrier or contact the sales representetive of the manufacturer SK Group Škrlj d.o.o. The accompanying documentation of the press includes the takeover checklist, where the components that need to be checked are listed.
-
Page 3: Table Of Contents
Pneumatic presses series M TABLE OF CONTENTS INTRODUCTION ......................................5 INTENDED USE OF PNEUMATIC PRESS ..............................5 GUARANTEE ........................................5 Health and safety ......................................5 Meaning of the symbols ..................................... 5 General safety precautions ..................................6 Safety devices ........................................ 7 4.3.1 Emergency STOP button ................................7 4.3.2 Safety cord ....................................... - Page 4 10.2 Cleaning the drain channels (PST models) ............................26 10.2.1 Removing the drain channels ..............................26 10.2.2 Reassembly of the draining channels ...........................27 10.2.3 Cleaning the drain channels without removing them (optional for PST models) ..........27 10.3 Cleaning of the external parts of the press ............................28 MAINTENANCE ......................................
-
Page 5: Introduction
Pneumatic presses series M INTRODUCTION We thank you for your trust, which you demonstrated by purchasing our pneumatic press. In order for it to be used successfully and for a long period we ask you to follow the instructions and warnings for a safe and proper use. The instructions are intended for the operator and they should always be kept at hand. -
Page 6: General Safety Precautions
General safety precautions Due to its moving parts and to the pressure in the drum, the pneumatic press may be a threat to its environment. Therefore, strictly observe safety precautions when operating the press. Unqualified and unauthorized person is not allowed to use the press. -
Page 7: Safety Devices
Pneumatic presses series M Safety devices The press is equipped with safety devices which ensure safe work and undisturbed operation of the press. 4.3.1 Emergency STOP button When you push the emergency STOP button the press immediately stops its operation. Never use the emergency STOP to interrupt the grapepress normal running. -
Page 8: Overload Relays
Presses with axial filling can also be equipped with a sound alarm. The alarm is triggered if the pressure is exceeded or the press is overfilled. Make sure not to exceed the max. pressure allowed douring the filling of the press. -
Page 9: Mounting And Storage Of The Press
Pneumatic presses series M The PS_10,_12 and _16 size presses have hoisting openings in the hatch brackets. Attach the hoisting strap or lined steel rope hooks in the openings. To unload and transport the press, apply appropriate lifting equipment (forklift, lift) and hoisting straps or lined steel ropes. -
Page 10: Switching On The Press
SWITCHING ON THE PRESS Electrical connection The electrical connection of the press must be carried out by skilled personnel (electrician)! Electrical connections (including earth lead and protection) should be performed in accordance with applicable standards. Electrical diagrams are attached to the manual! Connect the press to the required source of electrical power (single phase, three phase). -
Page 11: Rotating Direction Of The Drum
Pneumatic presses series M Insert the cable into the sleeve on the electric cabinet right side and connect the supply cable leads to the corresponding terminals. Connection shall be done by a qualified technician (electrician). sleeve Close the electric cabinet and lock it with the provided key. Keep the key on a safe place. Slide the cabinet back into the housing. -
Page 12: General Data
GENERAL DATA Technical data (dimensions and capacity) open drum, semi-membrane, half of the drum perforated Drum design enclosed drum, semi-membrane, draining channel Designation PSP 5 PST 5 PSP 8 PST 8 PSP 10 PST 10 PSP 12 PST 12... -
Page 13: Pneumatic Press Operation
Pneumatic presses series M Pneumatic press operation Pneumatic press is a technical-oenological process tool designed for controlled pressing of grapes. It allows the wine- maker to actively intervene in the processes in the course of pressing, to continually adjust and govern the processes. Soft pressing of grapes or lees by means of a membrane and compressed air prevents mechanical damaging of grapes (less damage to the hard parts of grapes) and in turn minimises the leaching of undesired ingredients. -
Page 14: Description Of The Pneumatic Press
DESCRIPTION OF THE PNEUMATIC PRESS Components sliding hatch press drum control board safety cord the front cover with the drive module juice collection pan Built-in components PS_5 and PS_8 presses (piston compressor): PS_10, PS_12 and PS_16 presses (piston compressor):... -
Page 15: Materials
Pneumatic presses series M An electric motor with reduction gear drives the drum via a chain transmission. Prior to each filling of the drum / rotation of the drum, suction fix the membrane to the drum walls by means of the vacuum pump. -
Page 16: Press Drum
Press drum The press drum is constructed according to pressure vessel guidelines (PED 97/23/EC). The horizontal shape of the drum, combining large length and small diameter, allows faster outflow of juice, which results in less sediment in the must. On the inside, the drum is lined with an impermeable membrane shaped to cover half of the drum surface. -
Page 17: Control Box
Pneumatic presses series M Control box The automatics (controller) provide for proper flow of the pressing process in accordance with the set parameters. The press can be fitted with AE automatics (factory preset programmes) or AV automatics (factory preset programmes that can be set and adjusted during the pressing process). -
Page 18: Optional Equipment
Optional equipment 8.8.1 Strainer on the collection pan outlet Install the strainer on the drain opening from the inside. The strainer traps pips and other particles from the must; thereby, only pure liquid passes from the collection pan into the container. - Page 19 Pneumatic presses series M The dimensions of the hatch depend on the press type. 1 – mounting bracket 2 – fixing screw 3 – door handle 4 – door cover To perform maceration, follow these instructions: Before filling the press, rotate the drum to bring the hatch to its top position. Insert drain channel plugs.
-
Page 20: Cooling Jacket (As An Option In Pst Models)
Maceration (only available with the AV module) key for maceration program (only for Presses with drum design PST – closed drum with drain channels) After closing the hatch and plugging the drain channels, turn on the drum filling pump and activate the maceration program. - Page 21 Pneumatic presses series M Venting On the opposite side of the drum there is a venting screw for the cooling jacket. Upon the first switching of the cooling medium the surplus air from the in-between room between the cooling jacket and the drum should be released. The venting is performed by unwinding the screw on the venting connector.
-
Page 22: Operating The Press
OPERATING THE PRESS The press is designed for pressing grapes and dregs. The use for any other purpose without the approval from the manufacturer is prohibited. Before use Prior to the first startup of the press, carefully examine the instructions for safe operation and maintenance of the pneumatic press, and always observe these instructions. - Page 23 Pneumatic presses series M Ball valve for central filling connector (option): The inlet connector may be of garolla, DIN11851 or treeclamp type. 1 – shaft gasket (semering) 2 – spacer 3 – flange gasket 4 – ball valve with a flange used to attach the sound alarm unit 5 –...
-
Page 24: Selecting The Pressing Program
Presses with AV automatics: press the ROCKING program activation key. The program is meant for filling the drum through the central filling connector. Programme rocking: As the first step, the membrane is vacuum-sucked to the drum, then the drum turns into the pressing position (hatch in the bottom position). -
Page 25: 10 Cleaning Of The Pneumatic Presses
Pneumatic presses series M 10 CLEANING OF THE PNEUMATIC PRESSES Before performing any maintenance, disconnect the press from electricity. Be careful not to wet the electric equipment (control panel, electric cabinet, electric motor) with the water jet. Protect the control panel with an impermeable foil (polyvinyl) when washing the press. When the press is cleaned by chemical substances (only cleaning substances for pneumatic presses can be used), the worker is directly exposed to possible dangerous effects of these substances, used for cleaning. -
Page 26: Presses With A Cleaning Opening (Ps_10
10.1.2 Presses with a cleaning opening (PS_10, _12, _16) The PS_10, _12 and _16 series presses are equipped with a DN50 DIN11851 cleaning opening and corresponding plug. cleaning opening with plug Use the drum rotation keys to rotate the drum so that the cleaning opening is in the bottom-most position. -
Page 27: Reassembly Of The Draining Channels
Pneumatic presses series M Step 4: Remove the draining channel plugs on the drum exterior. Step 5: Following this procedure, remove all drain channels and remove them from the drum. Clean the channels with water. Clean the drum interior as well. During washing, the drum should be orientated so that the water can drain out of the cleaning opening, or in case the press does not have such an opening, out of the drain channel. -
Page 28: Cleaning Of The External Parts Of The Press
When washing, move the hose in and out for maximum effect. Use the same procedure to clean all channels. Optional: Integrated high-pressure cleaner with hose and nozzle (optional on PST) The high-pressure cleaner is built into the press. The cleaning procedure is the same as described above. -
Page 29: Membrane
Pneumatic presses series M reduction gear chain fixing screw adjustment screw Step 4: Retighten the nut. Step 5: Retighten the four reduction gear fixing screws. 11.3 Membrane The membrane is made of a custom made, PVC-coated fabric. The membrane may be cleaned only with neutral cleaning agents, and the temperature of water MUST NOT EXCEED 50°C. -
Page 30: Maintenace Of The Safety Valve
11.5 Maintenace of the safety valve Periodically, check the safety valve. The valve must not show any sign of damage or usage, air must not escape from the valve. 11.6 After the end of the vintage season After the end of the season: disconnect the press from the mains supply;... -
Page 31: Spare Parts
Pneumatic presses series M The cleaning procedures for stainless steel products If the stainless steel products are very dirty and “colouring” caused by negligence or wrong treatment with the product is present, alternative methods such as the following have to be used: TyPE OF DIRT CLEANINg METHODS NOTES... -
Page 32: 12 Correcting Errors
12 CORRECTING ERRORS For sucessful detection and correction of eventual errors the sistematic approach is required. If the errors that you can’t solve yourself appear, please contact authorized service or seller. We ask you for precise description of the error, which you can easily discover with reading of instructions listed bellow. - Page 33 Pneumatic presses series M Test for locating the error. Drum hatch has to be closed, the press switched on. ERROR/PROBLEM POSSIBLE CAUSE RECOMMENDED PRECAUTION Switch on the internal service com- Active thermo protection in vacuum pump. Wait for 5 minutes for motor to cool and auto- mands and P–...
- Page 34 NOTES ................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................
