CopperOptics Pairain PG-Plus PCS-719 Manual

23-inch central office terminal shelf
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
23-
C
INCH
ENTRAL
Model
List Number
PCS-719
P
E
NGINEERING
PG-P
LUS
O
FFICE
Part Number
1
150-1619-01
G
T
AIR
AIN
ECHNOLOGIES
S
T
ERVICES
ECHNICAL
S
950-719-100-03
ECTION
Revision History of this practice.
Revision 03—September 2, 1997
A) Added Pin Assignment Table
B) Corrected Connection process
T
S
ERMINAL
HELF
CLEI Code
S9MTAB0ARA
, I
.
NC
P
RACTICE

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Pairain PG-Plus PCS-719 and is the answer not in the manual?

Questions and answers

Related Manuals for CopperOptics Pairain PG-Plus PCS-719

Summary of Contents for CopperOptics Pairain PG-Plus PCS-719

  • Page 1 PG-P INCH ENTRAL FFICE ERMINAL HELF Model List Number Part Number CLEI Code PCS-719 150-1619-01 S9MTAB0ARA ECHNOLOGIES NGINEERING ERVICES ECHNICAL RACTICE 950-719-100-03 ECTION Revision History of this practice. Revision 03—September 2, 1997 A) Added Pin Assignment Table B) Corrected Connection process...
  • Page 2 Revision 03 September 2, 1997 Section 950-719-100 ©Copyright 1997 PairGain® Technologies, Inc. PairGain is a registered trademark, and PG-Plus is a trademark of PairGain Technologies, Inc. Other product names mentioned in this manual are used for identification purposes only and may be trademarks and/or registered trademarks of their respective Information contained in this document is company private to PairGain Technologies, Inc.

  • Page 3: Table Of Contents

    Section 950-719-100 September 2, 1997 Revision 03 TABLE OF CONTENTS Using This Technical Practice............................ iv Inspecting Your Shipment............................iv PCS-719 Overview ............................... 1 Description and Features ................................1 Theory of Operation ................................. 2 Data Channel Overview ..............................2 Serial Communications Bus ............................. 3 Composite Clock Signals ..............................

  • Page 4: Using This Technical Practice

    Revision 03 September 2, 1997 Section 950-719-100 SING ECHNICAL RACTICE Three types of messages, identified by icons, appear in the text: A note informs you of special circumstances. A caution indicates the possibility of equipment damage. A warning indicates the possibility of personal injury. NSPECTING HIPMENT Upon receipt of the equipment:...

  • Page 5: Pcs-719 Overview

    Section 950-719-100 August 22, 1997 Revision 03 PCS-719 O VERVIEW This practice describes the PairGain PG-Plus PCS-719 List 1B Central Office Terminal 23-inch shelf (COTS) which supports up to sixteen PG-Plus subscriber carrier systems. ESCRIPTION AND EATURES The PCS-719 provides convenient mounting of COTS Plus Alarm Unit (PAUs) and Central Office Line Units (COLUs);...

  • Page 6: Theory Of Operation

    Revision 03 August 22, 1997 Section 950-719-100 HEORY OF PERATION Data Channel Overview The COTS backplane uses redundant Pulse Code Modulation (PCM) transmit and receive buses and Serial Communications buses (SCB) for data transfer and intra-shelf communications. Individual clock, data, and synchronization buses originate from the PMX cards and terminate at each COLU position.

  • Page 7: Serial Communications Bus

    Section 950-719-100 August 22, 1997 Revision 03 Serial Communications Bus The Serial Communications Bus (SCB) provides the means for the PAU/PMU to communicate with all other boards in the COTS to allow: • Software downloads • Coordination of PMX equipment protection •...

  • Page 8: Backplane Connections

    Revision 03 August 22, 1997 Section 950-719-100 ACKPLANE ONNECTIONS Each COTS supports the connection of up to sixteen COLUs, two PMX units and one PAU/PMU. The backplane of the PCS-719 COTS contains the connectors shown in Figure 4 and Table 1. Wiring external to the COTS should follow the provisions of the current edition of the National Electrical Code and applicable local codes.

  • Page 9: Power

    Section 950-719-100 August 22, 1997 Revision 03 Power The COTS backplane has a seven-position power-terminal strip (TB1) that provides connections for dual -48 V dc, common battery return, and frame ground to each of the card slots by way of screw terminals. The COTS can be wired for redundant powering, split-powering, or single-source powering depending upon requirements.

  • Page 10: Colu Edge Card Connectors

    Revision 03 August 22, 1997 Section 950-719-100 COLU Edge Card Connectors Tables 2 through 17 show the backplane connector pinouts for each COLU slot. Table 2 COLU #1 (J4) Connector Pinouts Table 3 COLU #2 (J5) Connector Pinouts Pin # Assignment Assignment Pin #...
  • Page 11 Section 950-719-100 August 22, 1997 Revision 03 Table 4 COLU #3 (J6) Connector Pinouts Table 5 COLU #4 (J7) Connector Pinouts Pin # Assignment Assignment Pin # Pin # Assignment Assignment Pin # TIP13 RING13 TIP19 RING19 TIP14 RING14 TIP20 RING20 TIP15 RING15...
  • Page 12 Revision 03 August 22, 1997 Section 950-719-100 Table 6 COLU #5 (J8) Connector Pinouts Table 7 COLU #6 (J9) Connector Pinouts Pin # Assignment Assignment Pin # Pin # Assignment Assignment Pin # TIP25 RING25 TIP31 RING31 TIP26 RING26 TIP32 RING32 TIP27 RING27...
  • Page 13 Section 950-719-100 August 22, 1997 Revision 03 Table 8 COLU #7 (J10) Connector Pinouts Table 9 COLU #8 (J11) Connector Pinouts Pin # Assignment Assignment Pin # Pin # Assignment Assignment Pin # TIP37 RING37 TIP43 RING43 TIP38 RING38 TIP44 RING44 TIP39 RING39...
  • Page 14 Revision 03 August 22, 1997 Section 950-719-100 Table 10 COLU #9 (J12) Connector Pinouts Table 11 COLU #10 (J13) Connector Pinouts Pin # Assignment Assignment Pin # Pin # Assignment Assignment Pin # TIP49 RING49 TIP55 RING55 TIP50 RING50 TIP56 RING56 TIP51 RING51...
  • Page 15 Section 950-719-100 August 22, 1997 Revision 03 Table 12 COLU #11 (J14) Connector Pinouts Table 13 COLU #12 (J15) Connector Pinouts Pin # Assignment Assignment Pin # Pin # Assignment Assignment Pin # TIP61 RING61 TIP67 RING67 TIP62 RING62 TIP68 RING68 TIP63 RING63...
  • Page 16 Revision 03 August 22, 1997 Section 950-719-100 Table 14 COLU #13 (J16) Connector Pinouts Table 15 COLU #14 (J17) Connector Pinouts Pin # Assignment Assignment Pin # Pin # Assignment Assignment Pin # TIP73 RING73 TIP79 RING79 TIP74 RING74 TIP80 RING80 TIP75 RING75...

  • Page 17: Alarm Cutoff

    Section 950-719-100 August 22, 1997 Revision 03 Table 16 COLU #15 (J18) Connector Pinouts Table 17 COLU #16 (J19) Connector Pinouts Pin # Assignment Assignment Pin # Pin # Assignment Assignment Pin # TIP85 RING85 TIP91 RING91 TIP86 RING86 TIP92 RING92 TIP87 RING87...

  • Page 18: Alarm Contacts

    Revision 03 August 22, 1997 Section 950-719-100 Alarm Contacts The PG-Plus COTS provides access to the PG-Plus Alarm Unit (PAU) alarm relays by way of wire-wrap pins on the shelf backplane. Both normally open (NO) and normally closed (NC) relay operation is supported. Figure 5 shows the configuration of the alarm relays.

  • Page 19: Dsx1 Connections

    Section 950-719-100 August 22, 1997 Revision 03 DSX1 Connections The COTS provides direct 100 Ω resistive termination for eight DS1 inputs from the DSX-1 cross-connect by way of wire-wrap pins located at the bottom right-hand side of the shelf backplane. The DS1 inputs are bridged to both PMX slots to allow for 1:1 equipment protection.

  • Page 20: Pmx Connector

    Revision 03 August 22, 1997 Section 950-719-100 PMX Connector J2 and J3 on the COTS backplane are the 160-pin DIN-type PMX connectors. Table 19 lists the PMX A (labeled as PMX 1 on the front of the shelf) connector pinouts. Table 20 lists the PMX B (labeled as PMX 2 on the front of the shelf) connector pinouts.
  • Page 21 Section 950-719-100 August 22, 1997 Revision 03 Table 20 PMX 2 160-Pin DIN-Type Connector Pin # Row A Row B Row C Row D Row E RDATB1 RDATB2 RDATB3 RDATB4 RDATB5 RSIGB1 RSIGB2 RSIGB3 RSIGB4 RSIGB5 TDATB1 TDATB2 TDATB3 TDATB4 TDATB5 TSIGB1 TSIGB2...

  • Page 22: Specifications

    Revision 03 August 22, 1997 Section 950-719-100 PECIFICATIONS Dimensions Height 6.5 inches Width 23 inches Depth 12 inches with line cards installed Weight 12.5 lbs. 23-inch equipment rack using universal mounting brackets Mounting Mounting the COTS in a 23-inch equipment rack on extended brackets is not recommended where vibration is a concern.

  • Page 23: Wiring Access

    Section 950-719-100 August 22, 1997 Revision 03 IRING CCESS All wiring to the COTS is done on the backplane. To access the backplane, remove the clear Plexiglas™ cover. LARM EADS Audible and visual alarm leads from the CO alarm panel to the COTS must be provided. Run the Alarm leads down the side of the COTS mounting frame.

  • Page 24: Power Connections

    Revision 03 August 22, 1997 Section 950-719-100 • TB1 FGND Connection The seven-position power-terminal strip termination point, TB1, is on the shelf backplane. A minimum of 12 AWG should be used for this connection. Using minimum 12 AWG wire, attach a spade lug connector to terminate the ground wire on the FGND terminal of TB1.

  • Page 25: Redundant-Shelf Powering

    Section 950-719-100 August 22, 1997 Revision 03 Redundant-Shelf Powering Each circuit card in the COTS receives power from two -48 V dc sources. If one -48 V dc source is lost, the other -48 V dc source provides power to the shelf circuit cards. Each -48 V dc source is fused at 20 amps. A four-position jumper is in place on the TB1 block (Figure 6).

  • Page 26: Split-Shelf Powering

    Revision 03 August 22, 1997 Section 950-719-100 Split-Shelf Powering One half of the shelf is powered from one -48 V dc source, the other half is powered from another -48 V dc source. Common equipment circuit cards are powered from both sources. If one power supply should fail, one- half of the shelf maintains power.

  • Page 27: Single-Source Powering

    Section 950-719-100 August 22, 1997 Revision 03 Single-Source Powering The entire shelf is powered from a single source of -48 V dc power fused at 20 amps. A four-position jumper is in place on the TB1 block. This jumper shorts all of the 48 VDC inputs together to prevent an alarm situation when only one input feed wire is connected.

  • Page 28: Audible And Visual Alarm Connections

    Revision 03 August 22, 1997 Section 950-719-100 Audible and Visual Alarm Connections Use a wire-wrap tool to terminate the alarm leads from the external alarm equipment on the alarm relay wire-wrap field. See Figure 9 for the location of the alarm relay wire-wrap field. Table 21 shows the layout of the wire-wrap pins on the COTS backplane.

  • Page 29: Subscriber Connections From Co

    Section 950-719-100 August 22, 1997 Revision 03 Subscriber Connections From CO Subscriber lines from the CO are connected to the COTS by way of 50-pin Telco connectors (P1, P2, P3, P4, and P5). Tables 22 through 25 show how the subscriber services are assigned at the Telco connectors. Tables 26 through 30 list the Telco connector pinouts.
  • Page 30 Revision 03 August 22, 1997 Section 950-719-100 Table 23 P2 Tip and Ring Pin Assignments Shelf Connector COLU Type Shelf Assignments Cardslot Ring PLL-720 PLL-721 PLL-722 PLL-723 PLL-724 POTS1 POTS1 POTS1 POTS P2-26 P2-1 POTS2 POTS2 POTS2 P2-27 P2-2 POTS3 POTS3 POTS3 P2-28...
  • Page 31 Section 950-719-100 August 22, 1997 Revision 03 Table 24 P3 Tip and Ring Pin Assignments Shelf Connector COLU Type Shelf Assignments Cardslot Ring PLL-720 PLL-721 PLL-722 PLL-723 PLL-724 POTS1 POTS1 POTS1 POTS P3-26 P3-1 POTS2 POTS2 POTS2 P3-27 P3-2 POTS3 POTS3 POTS3 P3-28...
  • Page 32 Revision 03 August 22, 1997 Section 950-719-100 Table 25 P4 Tip and Ring Pin Assignments Shelf Connector COLU Type Shelf Assignments Cardslot Ring PLL-720 PLL-721 PLL-722 PLL-723 PLL-724 POTS1 POTS1 POTS1 POTS P4-26 P4-1 POTS2 POTS2 POTS2 P4-27 P4-2 POTS3 POTS3 POTS3 P4-28...
  • Page 33 Section 950-719-100 August 22, 1997 Revision 03 Table 26 P1 Telco Connector Table 27 P2 Telco Connector Pin # Assignment Assignment Pin # Pin # Assignment Assignment Pin # RING1 TIP1 RING25 TIP25 RING2 TIP2 RING26 TIP26 RING3 TIP3 RING27 TIP27 RING4 TIP4...
  • Page 34 Revision 03 August 22, 1997 Section 950-719-100 Table 28 P3 Telco Connector Table 29 P4 Telco Connector Pin # Assignment Assignment Pin # Pin # Assignment Assignment Pin # RING49 TIP49 RING73 TIP73 RING50 TIP50 RING74 TIP74 RING51 TIP51 RING75 TIP75 RING52 TIP52...
  • Page 35 Section 950-719-100 August 22, 1997 Revision 03 Table 30 P5 Telco Connector Pin # Assignment Assignment Pin # 4WTXR1 4WTXT1 4WRXR1 4WRXT1 4WTXR2 4WTXT2 4WRXR2 4WRXT2 4WTXR3 4WTXT3 4WRXR3 4WRXT3 4WTXR4 4WTXT4 4WRXR4 4WRXT4 4WTXR5 4WTXT5 4WRXR5 4WRXT5 4WTXR6 4WTXT6 4WRXR6 4WRXT6 4WTXR7...

  • Page 36: Composite Clock Connections

    Revision 03 August 22, 1997 Section 950-719-100 Composite Clock Connections This step is required only if provisioning for DDS circuits. Termination resistors (TERM1 and TERM2) are located below the composite clock wire-wrap pins to provide the correct termination on the composite clock pins. To terminate the clock leads from the Telco Timing Source Generator to the COTS backplane: Connect CC1TIP to one terminal of TERM 1, and CC1RING to the other terminal on TERM 1 (Figure 10).

  • Page 37: Hdsl Wiring

    Section 950-719-100 August 22, 1997 Revision 03 HDSL Wiring J4 - J19 on the COTS backplane correspond to COLU slot numbers LU1 to LU16, and provide wiring support for two HDSL interfaces per COLU. Figure 11 shows HDSL connections J4 and J5. The wire-wrap pin labels for J4 - J19 correspond to the COLU slot number.

  • Page 38: External Aco Connection

    Revision 03 August 22, 1997 Section 950-719-100 External ACO Connection The ACO connection is made on the pin labeled EXT ACO as shown in Figure 12. To control the ACO remotely, connect the ACO to GROUND through a Normally Open, momentary contact switch. Figure 12 External ACO Wire-Wrap Connections P AND The following steps should be performed before any circuit cards are installed in the COTS.

  • Page 39: Product Support

    Section 950-719-100 August 22, 1997 Revision 03 RODUCT UPPORT ECHNICAL UPPORT PairGain Technical Assistance is available 24-hours-a-day, 7-days-a-week by contacting PairGain Customer Service Engineering group at: Telephone: (800) 638-0031 or (714) 832-9922 Fax: (714) 832-9924 During normal business hours (8:00 AM to 5:00 PM, Pacific Time, Monday - Friday, excluding holidays), technical assistance calls are normally answered directly by a Customer Service Engineer.

  • Page 40: Modifications

    Revision 03 August 22, 1997 Section 950-719-100 Refer to the installation section of the appropriate instruction manual for the unit you are installing to get information • Cabling • Correct connections • Grounding ODIFICATIONS The FCC requires the user to be notified that any changes or modifications made to this device that are not expressly approved by PairGain Technologies, Inc.
  • Page 41 Section 950-719-100 August 19, 1997 Revision 03 PG-Plus PCS-719 PairGain Engineering - Plant Series Page 37...
