Summary of Contents for NewTek TriCaster Mini X
- Page 1 Quick Start Guide What’s in the box? 1 Mini DisplayPort to HDMI Adapter & 3 Mini DisplayPort to DisplayPort TriCaster® Mini X Adapters Removable Power Cable Power Supply Keyboard & Mouse NX-001998-0001, Rev.01...
- Page 2 Connect the power supply performance can vary and it is • cable to the power connector recommended to contact an on the unit authorized NewTek supplier • Plug in the removable power for advice. cable to an electrical power source •...
- Page 3 ® TriCaster Mini X Connections Set-Up Front Panel Connections Set-Up • Connect microphone • Connect headphone input • Connect line level audio • Connect line level audio source output • Press to turn on power to the unit NX-001998-0001, Rev.01...
- Page 4 The Register TriCaster® screen now appears. Type in the 15 character serial number and then click Continue 8. Software Update After confirmation with the NewTek registration service, the system user interface appears. Before using the system, please go to https://www.newtek.com/downloads/ to download and install the latest version of software.
