A Family Fingerprint Reader

User Manual

01750367566 B

Table of Contents

Need help?

Do you have a question about the FP A Family and is the answer not in the manual?

Questions and answers

Summary of Contents for DIEBOLD NIXDORF FP A Family

Page 1 A Family Fingerprint Reader User Manual 01750367566 B...
Page 2: Table Of Contents
6 Installing the A Family Fingerprint Reader to the BEETLE A Family........6-1 7 Software Installation ........................7-1 8 Operating the Fingerprint Reader .................... 8-1 Cleaning Instruction ......................8-3 9 A Family Fingerprint Reader Module Specification ..............9-1 Copyright © 2022, Diebold Nixdorf 01750367566 B...
Page 3: Manufacturer's Declaration And Approval
The device complies with the requirements of the EEC directive 2014/30/EU with regard to ‘Electro-magnetic compatibility" and 2014/35/EU “Low Voltage Directive” and RoHS directive 2011/65/EU. Therefore, you will find the CE mark on the device or packaging. Copyright © 2022, Diebold Nixdorf 01750367566 B...
Page 4 For more detailed information about the take-back and recycling of this product, please con- tact your supplier where you purchased this product. Changes or modifications not expressly approved by the manufacturer for compliance could void the User’s authority to operate the equipment. Copyright © 2022, Diebold Nixdorf 01750367566 B...
Page 5: Supplier's Declaration Of Conformity
2 Supplier's Declaration of Conformity Product Description: Fingerprint Reader Model: FP A Family Party issuing Supplier’s Declaration of Conformity Diebold Nixdorf Singapore PTE. LTD. 30A Kallang Place #04-01 Singapore 339213 Phone: +65 6747 3828 Responsible Party – U.S. Contact Information...
Page 6: About This Manual
This manual informs you about everything you might need to know for the installation (hardware and software), the operation and the maintenance of your A Family Fingerprint Reader. NOTE Notes in the manual are marked by this symbol. WARNING This symbol is used for warnings. Copyright © 2022, Diebold Nixdorf 01750367566 B...
Page 8: About The Device
The A Family Fingerprint Reader module delivers a secure login and identification process for the retail sector. Via biometric analysis of fingerprints, it offers a perfect authentication for securing access into EPOS systems, especially in those retail environments that are accessible and open. Copyright © 2022, Diebold Nixdorf 01750367566 B...
Page 9: Installing The A Family Fingerprint Reader To The Beetle A Family
Follow the steps below to install the reader to the display. 1. The Fingerprint kit is as seen. It contains the Fingerprint module. Copyright © 2022, Diebold Nixdorf 01750367566 B...
Page 10 Installing the A Family Fingerprint Reader to the BEETLE A Family 2. Gently remove the side cover by prying the 2 ends outwards (see arrows) with a small screwdriver. 3. Then, slide the side cover out (see arrow). Copyright © 2022, Diebold Nixdorf 01750367566 B...
Page 11 Installing the A Family Fingerprint Reader to the BEETLE A Family NOTICE! Make sure to slide out the side cover correctly. 4. On the side to install the peripheral, remove the side-attach peripheral connection cover (1) of the BEETLE A Family. Copyright © 2022, Diebold Nixdorf 01750367566 B...
Page 12 6. Insert the Fingerprint module into the now ex- posed USB port of the BEETLE A Family. 7. Fit each knob on the Fingerprint module into its respective groove on the system as indi- cated. Copyright © 2022, Diebold Nixdorf 01750367566 B...
Page 14 Installing the A Family Fingerprint Reader to the BEETLE A Family 9. Then put on and tighten two M3x7 screws with Torx screwdriver (T-10). Screw in torque = 5 to 7 kgf.cm 10. Re-attach the side cover (see arrows). Copyright © 2022, Diebold Nixdorf 01750367566 B...
Page 16: Software Installation
The SDK include complete API, drivers and biometric engine for multiple platforms and language inter- face. For more information, please visit the site with the link below. https://www.hidglobal.com/developer-center/digitalpersona-touchchip Copyright © 2022, Diebold Nixdorf 01750367566 B...
Page 17: Operating The Fingerprint Reader
8 Operating the Fingerprint Reader The operation of the FP A Family depends very much on the software used or its implementation in the customer’s POS application which Diebold Nixdorf does not provide. In any case, fingerprint reading is very simple, once it is activated and ready indicated by blue lighting on the window just press your thumb or index finger on the oval-shape window and wait for a prompt to indicate completion.
Page 18 Worn out fingers print pattern If users are facing difficulties to detect or recognize finger, users may apply a thin layer of lotion or mois- turizer on the finger skin for better detection and recognition. Copyright © 2022, Diebold Nixdorf 01750367566 B...
Page 19: Cleaning Instruction
● Do not pour cleaning fluid directly on the fingerprint capture area. ● Do not submerge the sensor in liquid. ● Do not rub the fingerprint capture area with any abrasive material, including paper. Copyright © 2022, Diebold Nixdorf 01750367566 B...
Page 20: Family Fingerprint Reader Module Specification
512 dpi Scan capture area 14.6 mm x 18.1 mm Scan Data 8-bit grayscale (256 levels) Image Distortion < 1% (Typical) Speed of Image Transfer <0.17 seconds Compatible System DN A Family and D-series Copyright © 2022, Diebold Nixdorf 01750367566 B...
