Eurovacuum
Installations and
Operating manual
EVDR-Series
Vacuum pumps
Models:
EVDR-V010 till V040
Dry Rotary Vane Vacuum Pump

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the EVDR Series and is the answer not in the manual?

Questions and answers

Summary of Contents for Eurovacuum EVDR Series

  • Page 1 Eurovacuum Installations and Operating manual EVDR-Series Vacuum pumps Models: EVDR-V010 till V040 Dry Rotary Vane Vacuum Pump...
  • Page 2: Table Of Contents

    Contents It is mandatory that these operating instructions be read and understood prior to the vacuum pump installation and start-up. 1.0 INSTALLATION 1.1 General description 1.2 Unpacking and Storage 1.3 Location 1.4 Power Requirements 1.5 Vacuum Connections 2.0 SAFETY 2.1 General Notices 2.2 Warning Label and explanation 2.3 Risks and warnings 3.0 OPERATION...
  • Page 3: Installation

    INSTALLATION AND OPERATING MANUAL 1.0 INSTALLATION 1.1 General description The EVDR vacuum pumps are able to run 24 hours a day and especially suited for harsh industrial applications. They are supplied with self-lubricated long life graphite vanes to insure a long time between service, combined with the easy accessible service of the pump, this results in a very short service down time for the EVDR-series.
  • Page 4: Vacuum Connections

    Should process gas contain dust or other foreign particles, a suitable in line (inlet) filter should be connected to the inlet port. Consult Eurovacuum for recommendations. The vacuum piping should be designed to ensure that no liquids such a condensate or liquid carried over from the process can reach the pump.
  • Page 5: Safety

    - Any other person except authorized operator should not operate the vacuum pump - When the pump is not properly working, it should be stopped immediately. - Eurovacuum shall have no liability for any accident and failure arising from no compliance with instructions in this manual.
  • Page 6: Operation

    28 mm EVDR-V040 28 mm Caution: Only use original Eurovacuum vanes or order them at www.vanes.shop 4.2 Filter check Check the filter cartridges inside the enclosure cover of the pump and clean/replace them when necessary. You can order these from Eurovacuum or at www.vanes.shop...
  • Page 7: Maintenance Chart

    4.3 Maintenance Chart Weekly: Check inline inlet filter element / Mesh. More often if high particulates in inlet stream. Monthly: Clean the pump from dust and dirt. When inlet filter is installed: check the filter cartridge, replace if needed. Every 3.000 operating hours: Check the vanes size. Replace vanes if under the size. Semi-Annually: Check cooling fan.
  • Page 8: Technical Data

    5.4 Problem The vacuum pump runs too hot. 5.4.1 Possible cause Ambient temperature is too high. Remedy : Check the ambient temperature and take care of extra cooling. 5.4.2 Possible cause Insufficient cooling. Remedy : Remove dust and dirt from the pump. 5.4.3 Possible Cause Filters clogged.
  • Page 9 Eurovacuum Head office Tel. +31-(0)854890993 Einsteinstraat 58 info@eurovacuum.eu 2811EP Reeuwijk http://www.eurovacuum.eu The Netherlands...

This manual is also suitable for:

Evdr-v010Evdr-v040Evdr-v016Evdr-v025
