- Page 1 USER GUIDE & SUPPORT USB-C Lavalier Mic Kit...
- Page 2 FOR RETURNS, REFUNDS AND REPLACEMENTS EMAIL US AT: SUPPORT@PURPLEPANDASTORE.COM YOU HAVE A 1-YEAR WARRANTY...
-
Page 3: Table Of Contents
TABLE OF CONTENTS PARTS GUIDE MIC PLACEMENT FUZZY WINDSCREEN SMARTPHONES WITH 3.5MM EARPHONE PORT ANDROID - MIC RECORDING SETUP ANDROID - CALL SETUP ANDROID - MIC NOT RECOGNIZED 7 -8 IPHONE - MIC RECORDING SETUP IPHONE - CALL SETUP TABLET - MIC RECORDING SETUP TABLET - CALL SETUP IPAD - MIC RECORDING SETUP IPAD - CALL SETUP ... -
Page 4: Parts Guide
PARTS GUIDE Microphone with TRRS Connector 9.8ft (3m) Extension Cord with TRRS Connector Mic & Earphone Connector (for calls) USB-C Adapter Fuzzy Windscreen for Windy Environments... -
Page 5: Mic Placement
MIC PLACEMENT The microphone should be positioned directly underneath the speaker's mouth (as close as possible), without being subject to clothing rustle. When attaching the microphone, please ensure the microphone is pointed towards the speaker's mouth. -
Page 6: Fuzzy Windscreen
FUZZY WINDSCREEN The fuzzy windscreen is ideally used for windy environments to prevent wind noise from distorting the audio quality of the microphone. For increased wind protection, add the fuzzy windscreen when recording outdoors by sliding it over the microphone and ensuring the fur is fluffed up in all directions for best results. -
Page 7: Smartphones With 3.5Mm Earphone Port
RECORDING ON SMARTPHONES WITH 3.5MM EARPHONE PORT RECORD INSERT ATTACH THE MIC TO CONNECT THE YOUR SHIRT AND MICROPHONE PLUG START RECORDING FIRMLY INTO THE USING THE PHONE'S EARPHONE PORT OF RECORDING APP YOUR SMARTPHONE "CLICK" PLAY UNPLUG TO LISTEN TO YOUR PRESS THE "PLAY"... -
Page 8: Android - Mic Recording Setup
ANDROID - MIC RECORDING SETUP ANDROID SMARTPHONES WITHOUT AN EARPHONE PORT REQUIRE THE USB-C ADAPTER (INCLUDED) USB-C Adapter CONNECT ALL PLUGS FIRMLY UNTIL YOU HEAR A “CLICK” FOR ANDROID SMARTPHONES WITH A 3.5MM EARPHONE PORT: CONNECT THE MIC PLUG FIRMLY INTO THE EARPHONE PORT OF YOUR SMARTPHONE CONNECT THE MIC PLUG FIRMLY UNTIL YOU HEAR A... -
Page 9: Android - Call Setup
ANDROID - CALL SETUP ANDROID SMARTPHONES WITHOUT AN EARPHONE PORT REQUIRE THE USB-C ADAPTER (INCLUDED) USB-C Adapter Mic & Earphone Connector Plug earphones to listen to playback or during call CONNECT ALL PLUGS FIRMLY UNTIL YOU HEAR A “CLICK” USE THE FOLLOWING CONNECTION FOR ANDROID SMARTPHONES WITH A 3.5MM EARPHONE PORT Plug earphones to listen... -
Page 10: Android - Mic Not Recognized
ANDROID - MIC NOT RECOGNIZED SOME ANDROID PHONES REQUIRE AN EXTERNAL APP FOR THE MIC TO WORK. DOWNLOADING THE OPEN CAMERA APP WOULD BE AN EASY FIX, PLEASE TAKE THE FOLLOWING STEPS: 2. Launch the Open Camera app 1. Launch the Play Store and then press on the settings icon search for "Open Camera"... - Page 11 ANDROID - MIC NOT RECOGNIZED 3. Select Video Settings... Audio Source External Mic Then create your video recording using the Open Camera app...
-
Page 12: Iphone - Mic Recording Setup
IPHONE - MIC RECORDING SETUP Newer iPhone models require "Lightning to 3.5mm Headphone Jack Adapter" - Sold Separately by Apple. It is recommended that it's bought directly from Apple in order to guarantee quality. NOT INCLUDED: LIGHTNING TO 3.5 MM HEADPHONE JACK ADAPTER REQUIRED CONNECT THE MIC PLUG FIRMLY UNTIL YOU HEAR A “CLICK”... -
Page 13: Iphone - Call Setup
IPHONE - CALL SETUP Newer iPhone models require "Lightning to 3.5mm Headphone Jack Adapter" - Sold Separately by Apple. It is recommended that it's bought directly from Apple in order to guarantee quality. Not Included Mic & Earphone Connector Plug earphones to listen to playback or during call CONNECT ALL PLUGS FIRMLY UNTIL YOU HEAR A... -
Page 14: Tablet - Mic Recording Setup
TABLET - MIC RECORDING SETUP TABLETS WITHOUT AN EARPHONE PORT REQUIRE THE USB-C ADAPTER (INCLUDED) CONNECT ALL PLUGS FIRMLY UNTIL YOU HEAR A “CLICK” USB-C Adapter FOR MODELS WITH A 3.5MM EARPHONE PORT CONNECT THE MIC PLUG DIRECTLY INTO THE TABLET CONNECT THE MIC PLUG FIRMLY UNTIL YOU HEAR A “CLICK”... -
Page 15: Tablet - Call Setup
TABLET - CALL SETUP CONNECT ALL PLUGS FIRMLY UNTIL YOU HEAR A “CLICK” USB-C Adapter Mic & Earphone Connector Plug earphones to listen to playback or during call USE THE FOLLOWING CONNECTION FOR TABLETS WITH A 3.5MM EARPHONE PORT Plug earphones to listen to playback or during call Mic &... -
Page 16: Ipad - Mic Recording Setup
IPAD - MIC RECORDING SETUP CONNECT ALL PLUGS FIRMLY UNTIL YOU HEAR A “CLICK” USB-C Adapter NEWER MODELS (12.9‐INCH IPAD PRO, 11‐INCH IPAD PRO, ETC.) REQUIRE THE USB-C ADAPTER (INCLUDED) FOR MODELS WITH A 3.5MM EARPHONE PORT (IPAD AIR, IPAD MINI, AND CLASSIC IPAD), CONNECT THE MIC PLUG DIRECTLY INTO IPAD CONNECT THE MIC PLUG FIRMLY UNTIL YOU HEAR A... -
Page 17: Ipad - Call Setup
IPAD - CALL SETUP CONNECT ALL PLUGS FIRMLY UNTIL YOU HEAR A “CLICK” USB-C Adapter Mic & Earphone Connector Plug earphones to listen to playback or during call CONNECT ALL PLUGS FIRMLY UNTIL YOU HEAR A “CLICK” Plug earphones to listen to playback or during call Mic &... -
Page 18: Troubleshooting
TROUBLESHOOTING HOW TO TEST IF YOUR MIC IS WORKING: Record an audio recording (preferably with a smartphone) while scratching the foam windscreen on the mic. Unplug the mic and listen to the recording, if the mic is working, the scratching sound should be loud which means the mic is active. IMPORTANT: When connecting adapters to each other, connect them firmly... - Page 19 TROUBLESHOOTING BUZZING NOISES IN RECORDING? 1. When connecting adapters to each other, connect them firmly until you hear a “CLICK”. Many issues happen due to the adapters not being connected properly. Make sure you are using the correct combination of adapters for your device by referring to the instructions in this guide.
- Page 20 TROUBLESHOOTING BUZZING NOISES IN RECORDING? 4. Check if the microphone cable or extension cables are close to or wrapped around other electrical devices (including the one you are recording with). 5. Try the microphone with a smartphone to ensure there is not a problem with the microphone itself. If you are trying to use any of the adapters, ensure that they are plugged in firmly (until you hear a click - see image on page 15) and that the correct combination of...
-
Page 21: Contact Us / Need More Help
NEED MORE HELP? EMAIL US AT: SUPPORT@PURPLEPANDASTORE.COM WE’RE ALWAYS HERE TO HELP, YOUR SATISFACTION IS OUR BIGGEST PRIORITY YOU HAVE A 1-YEAR WARRANTY... -
Page 22: Specifications
SPECIFICATIONS Capsule Diameter 7.9mm Polar Pattern Omnidirectional Sensitivity (±4dB) -40 ±3dB Frequency Range 40Hz~16kHz S/N Ratio 55dB Power Source 1.8~5V Operating -20°~+50° Temperature Output Connection TRRS / USB-C...
