Summary of Contents for BOA 69-KEY-CARD

  • Page 1 electronic locks...
  • Page 2 We will save you money and ensure your security via a diversified vendor base with equivalent if not better products and services. Where: BOA services our clients all through the United States and Canada. When: Typical lead times for orders are 7-10 days after receipt of order.
  • Page 3 — Option for fail secure (remains locked when power is lost). — slam function (allows door or drawer to close and secure without requiring unlocking). — Allows multiple locks to connect with controllers. — no computer necessary for level or card programming. #69-key-cArd-user #69-fT200 cOnTrOller #69-fT200 cArd reAder #69-efl-3-304lOck #69-efl-1-3mlOck...
  • Page 4 cOnceAled cArd AcceSS electrOnic lOcking SyStem 69-Ft200 cOntrOller Features: — up to 228 keys can be authorized at a single terminal. — indication of lock state through leds (red/green) and audible beep. — configurable locking state. — cycle operation: can be configured for 1-120 seconds with optional configuration key card (pre-set default time 3 seconds).
  • Page 5 cOnceAled cArd AcceSS electrOnic lOckS Features: #69-eFl-3-304 lOck — slam function. Without door status contact — fail secure. #69-eFl-3-305 lOck — flat design allows for mounting beneath or beside drawers. — electromotive locking mechanism cannot be influenced by With door status contact magnetic fields.
  • Page 6 cOnceAled cArd AcceSS electrOnic lOckS #69-mcl-1 mini mAgnet lOck mini design for cabinets. Specifications: must be used in conjunction with the physical & performance at 25 °c (77 °f) #69-exT-rly external relay unit! Weight: 400 g (14 oz) max. holding load: 364 n (80 lbf.) environmental Operating temperature:...
  • Page 7 electrOnic lOcking SyStem AcceSSOrieS #69-Ft120-mlA6 multi-lock Adapter enables the user to connect up to 6 efl3s Features: — easy wiring of the locks — modular connection of the mlA6 to a fT 120 V2 with cable 237.56.340 (included) — potential free clamp terminal delivers lock status signal —...
  • Page 8 electrOnic lOcking SyStem AcceSSOrieS #69-trn-12Vdc-2.5A power supply Features: — protected from damage if the output wiring is shorted Supplied with: — (1x) power supply — Amp socket and 72” primary cord Specifications: Housing dimensions: 108 x 58 x 30 mm (4-1/4”...
  • Page 9 electrOnic lOcking SyStem AcceSSOrieS #69-eFl3-cBl-1m (1 m / 39-3/8”) #69-eFl3-cBl-3m (3 m / 118”) #69-eFl3-cBl-5m (5 m / 196-3/4”) cables for efl3(c) #69-eXt-cBl-1m (1 m / 39-3/8”) #69-eXt-cBl-2m (2 m / 78-3/4”) #69-eXt-cBl-5m (5 m / 196-3/4”) #69-eXt-cBl-10m (10 m / 393-3/4”) extension cables —...
  • Page 10 eFl SyStemS diAlOck ® rFid keyS tAg-it™ #69-key-tAg-gry-uSer #69-key-tAg-Wh-uSer key tags #69-key-tAg-grn-Add #69-key-tAg-rd-del level 1 programming Add (green) and delete (red) rfid key tags — Water-resistant — 4 dialock® segments — WxHxd: 28 x 56 x 1.7 mm (5/8” x 2-1/4” x 1/16”) #69-key cArd-uSer-White #69-key cArd-Add uSer-green #69-key cArd-delete uSer-red...
  • Page 11 electrOnic lOcking SyStem cOntrOller / reAder unit #69-Wt210 cOntrOller / reAder Wall terminal reader unit and controller in one compact unit. Allows for installation in flush-mount sockets or cavity wall boxes. Features: — red/green leds for indication of locking and unlocking —...
  • Page 12 electrOnic lOcking SyStem PrOgrAmming FirSt time POWer-uP PrOgrAmming: 1. plug-in power. 2. When the reader flashes green, introduce the green (add)card. 3. When the reader flashes red, introduce the (delete) card. StOP! PrOgrAmming A uSer cArd: 1. now, present the green (add) card to the reader.
  • Page 13 electrOnic lOcking SyStem PrOgrAmming multi PrOgrAm (7A) – SimPle PrOgrAmming: This procedure allows you to create multi green (add) and (delete) programming keys for simple programming. To proceed with this function at least one green (add) and one (delete) key must already be enrolled into green the lock or controller.
  • Page 14 electrOnic lOcking SyStem WAll unit Wiring diAgrAm mOtiOn detectOr (above door, inside) electrOmAgnet requeSt tO eXit dOOr releASe OPtiOn B AcceSS cOntrOl reAder electric Strike dOOr releASe OPtiOn A www.boasecure.com | 516-576-0295 national service providers...
  • Page 15 electrOnic lOcking SyStem Wiring diAgrAmS BASic Wiring diAgrAmS FOr eFl3 lOckS ReadeR One lOck SetuP ReadeR multiPle lOck SetuP national service providers 516-576-0295 | www.boasecure.com...
  • Page 16 electrOnic lOcking SyStem Strike #69-Strike-elec-12/24-FS/nFS electric strike for wood and metal frames. Available in various finishes. * Parenthesis dimensions are in mm. The 4500c series electric strike is designed for installation in 2” The 4500c includes a 4500 strike body and two interchangeable ul 10c fire-rated frames with 1/2”...
  • Page 17 electrOnic lOcking SyStem mAgS #69-mAg-8371-SS 9-3/8”W x 1-7/8”H x 1”d (238mm x 48mm x 25mm) includes 3/16” (5mm) mounting bracket Armature plate: 7-1/4”W x 1-1/2”H x 1/2”d (185mm x 38mm x 13mm) These surface mag® locks are designed with a 1-7/8” width to keep undersized openings within code.
  • Page 18 electrOnic lOcking SyStem mAgS #69-mAg-SheAr securitron sAm shear Aligning magnalock 1200 lbs. [544 kg] holding force shear Aligning magnalock mounts * Parenthesis dimensions are in mm. fully concealed into wood, steel or aluminum doors. sAm can also be installed in any position on the door - top, side or bottom and is ideal for swing through and sliding doors.
  • Page 19 electrOnic lOcking SyStem mOtiOn detectOr lOck releASe #69-rte-mOtiOn for use in request-to-exit (rex) applications. complies with environmental class ii (en50130-5) provides pir 2.4 m x 3 m (8 ft x 10 ft) coverage, timers, door monitor with sounder alert, and pointable coverage. Operating Temperature: -29°c to +49°c (-20°f to +120°f) for ul certificated installations, 0°c to +49°c (+32°f to +120°f)
  • Page 20 electrOnic lOcking SyStem requeSt tO eXit ButtOn #69-rte-ButtOn 991 pneumatic Time delay exit pushbutton — red, 1-5/8” (41mm) diameter button with engraved “pusH TO exiT” — Tamper-resistant, cannot be burned or pried off — Quickly mounts to single gang box (standard) or narrow-stile door frames (narrow) —...
  • Page 21 memO ShOWcASe Security SyStem diAmOnd[e]mOtiOn SerieS The memo electronic card Access locks consist of the local controller, the card reader, the lock(s) and the power supply. The local controller is the brains of the system. it permits you to connect up to 8 locks and 2 card readers in order to secure either one or even two showcases using one controller.
  • Page 22 memO ShOWcASe Security SyStem diAmOnd[e]mOtiOn SerieS #70-cOntrOller-8/2-m2g The local controller connects to a card reader and the lock that is mounted in the showcase. and it can control up to 8 locks and 2 card readers to allow for a cost effective and secure installation.
  • Page 23 memO ShOWcASe Security SyStem diAmOnd[e]mOtiOn SerieS #70-lOck-002 spring loaded, motorized, fail secure lock with a stainless steel housing and internal components. contains a built-in door contact and can, if programmed ensure you are never left unaware that the door is not secure. national service providers 516-576-0295 | www.boasecure.com...
  • Page 24 memO ShOWcASe Security SyStem diAmOnd[e]mOtiOn SerieS #70-reAder - 1 Touchless card reader allows access card or fobs to open the showcase. it can be hidden beneath the surface of the showcase or mounted to it. #70-uSer FOB user fobs and user cards are programmed to unlock and serve as an electronic key to the showcase.
  • Page 25 memO ShOWcASe Security SyStem diAmOnd[e]mOtiOn SerieS #70-trAnSFOrmer 12-VOlT pOWer supply #70-PrOgrAmmer - 12 ButtOn The 12 button programmer is used to connect to the controllers to make specific changes in the event that the higher level Alarm control unit is not used. national service providers 516-576-0295 | www.boasecure.com...
  • Page 26 memO ShOWcASe Security SyStem diAmOnd[e]mOtiOn SerieS #70-AlArm cOntrOl unit The bOH control unit is an optional, additional back of House controller. it is only required when remote site ac- cess control features are to be utilized; or when additional security from the on-site, bOH is required. mOunting www.boasecure.com | 516-576-0295 national service providers...
  • Page 27 memO ShOWcASe Security SyStem diAmOnd[e]mOtiOn SerieS monitor showcase status in real time from the back of House by watching the status Tower colors. green indicates a showcase is open. yellow indicates a showcase is open longer than it should be. indicates a showcase intrusion alarm has been triggered.
  • Page 28 dOrmAkABA #00-rci-3510lm cABinet lOck The 3510lm cabinet lock features a compact, surface- mounted design for small enclosures. This electric lock has side or top mounting capability for easy installation which makes it suitable for a variety of applications. positioning of the rci Specifications: 3510lm cabinet locking pin determines —...
  • Page 29 dOrmAkABA #00-rci-9320 cOntrOller / reAder The rci 9320 controller / reader requires a power supply to operate. please see the Altronix power supply in this catalog (Part#00-SmP5ctX-Power Supply). note, if the enclosure for the power supply is too large, please contact us for a work- around.
  • Page 30 BPS electrOnic lOck bOA’s bps card Access locks are a great way to remove the lock from the face of your millwork and hide it beneath the material surface. This is a cost-effective product line that can be powered via a plug-in transformer or with batteries. it is a great alternative to a full-blown card access system and mechanical, key-driven locks.
  • Page 31 cOnceAled cArd AcceSS electrOnic lOckS BPS electrOnic lOck #18-BPS-lOck Plastic Housing version has a built-in card reader (not Antenna). However, external readers will work with the unit as well. Metal Housing Version The #18-bps-lock - m1 requires an external reader. 18-BPS-lOck-mini must be used in conjunction with either of our bps locks.
  • Page 32 cOnceAled cArd AcceSS electrOnic lOckS BPS electrOnic lOck #18-BPS-rAtchet lOck bps ratchet electronic sliding door lock based on rfid technology #18-Ac-lAtch #18-Ac-mini-ltch #18-Ac-PSh-hVydty-ltch stainless steel pin with ~440 lbs (200 kg) breaking point. intergrated push pin automatically opens light doors/drawers. * Parenthesis dimensions are in mm.
  • Page 33 cOnceAled cArd AcceSS electrOnic lOckS/lAtch OPtiOnS BPS electrOnic lOck #18-Ac-Frnt-ltch locking pin with ~77 lbs (35 kg) breaking point. The flexible pin allows a tolerance of +/- .12” (3 mm). 3/4" (19.1) 5/16" (8.0) 2-3/8" 1-1/2" (60.3) (38.1) 9/16" 1/4" (6.4) 7/32"...
  • Page 34 cOnceAled cArd AcceSS electrOnic lOcking SyStem BPS electrOnic lOck #18-digitAl kP OPtiOn A: FOr PuBlic uSe bps keypad uses a 4-digit code This version is for use in public institutions such as on lockers. The lock is open in idle mode. The user puts his/her clothes in an open compartment/locker and locks it by entering his/her to access the lock.
  • Page 35 cOnceAled cArd AcceSS cArd PrOgrAmming OPtiOnS BPS electrOnic lOck PArt # deScriPtiOn 18-crd-Op standard operating card (single card). 18-crd-Op-seT-p standard operating card set. comes in a shadow pair the second card is meant to be kept in case a lost or stolen key needs to be removed from the programming.
  • Page 36 cOnceAled cArd AcceSS AcceSSOrieS BPS electrOnic lOck #18-cArd reAder external card reader connects directly to unit (18-lOck). Wire length 5’ (1.5 m) # 18-Ac-SPAcer-Plt spacer plate prevents wires from being crushed against the mounting surface. * Parenthesis dimensions are in mm. www.boasecure.com | 516-576-0295 national service providers...
  • Page 37 cOnceAled cArd AcceSS electrOnic lOcking SyStem BPS electrOnic lOck #18-glASS lOck mOunt kit mount bps lock unit to glass with the glass mount kit. mounting plate will add ~13/64” (5.2 mm). mounting tape has holding force up to 55 lbs (25 kg) or 99 lbs (45 kg) depending on the direction of pull.
  • Page 38 electrOnic lOcking SyStem AcceSSOrieS BPS electrOnic lOck #18-trn eliminate the need for battery power or use in conjunction with the battery. Wire length ~60” (14.5 m). * Parenthesis dimensions are in mm. #18-BAtt battery for bps electronic lock #18-BPS-huB9 connects multiple locks together for a plug-n-play splice point.
  • Page 39 electrOnic lOcking SyStem PrOgrAmming inStructiOnS BPS electrOnic lOck PrOgrAmming inStructiOnS FOr rF cArd: The user card and the shadow card are identical. The shadow card should be kept in the store safe. if the user card is lost, you can use the shadow card to delete the lost user card from the locks. ActiVAting the PrOgrAmming cArd initializing/activating a programming card 1.
  • Page 40 electrOnic lOcking SyStem OPerAting inStructiOnS BPS electrOnic lOck OPerAting inStructiOnS FOr digitAl lOck: lOck choose any open locker, close the door and insert your 4-digit code and press 4. The lock will close and the door will be locked. OPen enter the same code again, press 4 and the lock will open.
  • Page 41 electrOnic lOcking SyStem mOunting inStructiOnS BPS electrOnic lOck national service providers 516-576-0295 | www.boasecure.com...
  • Page 42 cABinet & lOcker electrOnic lOcking SyStem BPS electrOnic lOck #50-cl-AA-digitAl kp 20 battery powered, low cost cabinet lock for low to medium security applications with 75 lbs of holding force. Specifications: — fcc part 15 compliant Features: — ic compliant —...
  • Page 43 cABinet & lOcker electrOnic lOcking SyStem BPS electrOnic lOck #50-cl-regulAtOr Available in two versions: self-locking and manual locking. Applications: Features: — cabinet doors or drawers — low battery indicator — lockers — 75,000 cycles; extended battery life reduces replacement and labor/maintenance costs —...
  • Page 44 cABinet & lOcker electrOnic lOcking SyStem BPS electrOnic lOck self-lOcking features slamcAm, a spring loaded latch, which allows the user simply to close the cabinet door or drawer — no need to return the knob to the locked position. mAnuAl lOcking version, which uses existing compx national cams, requires users to rotate the knob into the unlocked and locked positions.
  • Page 45 BAck OF hOuSe electrOnic lOcking SyStem BPS electrOnic lOck #50-trilOgy-SerieS-ic-26d electronic entrance locks Trilogy series electronic entrance locks are available with keypad or rf card Access and with sfic key Access as a back-up. Trilogy models are available in Wp weatherproof and non-Wp standard models for interior doors, as well as panic bar access.
  • Page 46 electrOnic lOcking SyStem neXgen Xt nexgen xT is a pure electronic master key system providing controlled Access, Accountability, physical security and effective system management. nexgen xT offers the benefits of electronic access control in a key operated lock. keys are programmed to operate designated locks during a set schedule.
  • Page 47 neXgen Xt cAm lOckS 05 cl XX(X) All cAms are sold as a set of 2. cAms containing both Vertical and Horizontal Tenons. nexgen xT series is key retaining Only. The lock must be locked in order to remove the key. OPtiOn 1 (standard) * Parenthesis dimensions are in mm.
  • Page 48 neXgen Xt cAm lOckS StrAight FlAt cAm custom sizes available. PArt # cAm length #00-CAM-0750 0.750” (19.1mm) #00-CAM-1250 1.250” (31.8mm) #00-CAM-1750 1.750” (44.5mm) #00-CAM-2000 2.000” (50.8mm OFFSet cAm custom sizes available. * Parenthesis dimensions are in mm. PArt # cAm length OFFSet 00-CAM-1250 x 0313 1.250”...
  • Page 49 neXgen Xt drAWer lOckS 05 BD l XX(X) deAd BOlt drAWer lOck nominal bolt travel is 7/16” (11.1 mm) short bolt (bs) option retracts completely into housing * Parenthesis dimensions are in mm. 05 BD l XX(X) XX(X) = BOlt tyPe XX = metAl FiniSh bs = 1-1/16”...
  • Page 50 neXgen Xt drAWer lOck 05 BDl XX(X) “Pit Bull” drAWer lOck nominal bolt travel is 7/16” (11.1 mm) short bolt (bs & bsb) options retract completely into housing. * Parenthesis dimensions are in mm. 05 BDl XX(X) XX = metAl FiniSh XX(X) = BOlt tyPe bs = 1-1/16”...
  • Page 51 neXgen Xt drAWer lOck 05 sB l SAnP BOlt drAWer lOck sold 05 sB l XX = OrientAtiOn Vi = Vertical or inverted lr = left or right XX = metAl FiniSh pn = polished nickel (standard) sc = satin chrome cf = custom finish * Parenthesis dimensions are in mm.
  • Page 52 neXgen Xt Plunger lOck 05 Pl Plunger lOck 1-9/16” 05 Pl XX = mAteriAl inStAlled On Wd = Wood mT = metal gr = glass w/round Hole XX = metAl FiniSh pn = polished nickel (standard) sc = satin chrome cf = custom finish www.boasecure.com | 516-576-0295 national service providers...
  • Page 53 neXgen Xt SFic cOreS #05-SFic-cOre small format interchangeable core (sfic) convert a besT style lock to a full blown Access control system in 5 minutes. — direct replacement for mechanical sfic cylinders without any hardware modifications. — ideal for loss and liability management —...
  • Page 54 neXgen Xt keyS #05-key-OP Slim slim line key #05-key-induStriAl Heavy duty key www.boasecure.com | 516-576-0295 national service providers...
  • Page 55 neXgen Xt AcceSOrieS PArt # deScriPtiOn 05-cHg portable key charging Adapter only (order cable separately). 05-cHg-seT portable key charging Adapter (includes 05-usb cable 05-Trn). 05-dOck-seT usb system dongle (includes 05-usb cable). 05-mObile-dOck mobile programmer allows xT industrial and slim line keys to be programmed remotely via bluetooth (on an Android device) or via a usb tether to a laptop.
  • Page 56 AltrOniX POWer SuPPly #00-SmP5ctX-POWer SuPPly power supply/charger converts a 115VAc/230VAc, 50/60Hz input into a regulated 12Vdc or 24Vdc output @ 4A continuous supply current. inPut — 115VAc, 50/60Hz, 0.95A or 230VAc, 50/60Hz, 0.5A OutPut — 12Vdc or 24Vdc selectable output —...
  • Page 60 BOA SECuRITy TECHNOLOgIES 586 New york Avenue, unit 3 Huntington, Ny 11743 T 516-576-0295 | F 631-470-8099 Alan.Lurie@BOA-ST.com www.BoaSecure.com...
