DIEBOLD B-23E2 User Manual

User＇ s Manual for Private Container with Electronic Combination Lock
Applies to Model B-23E2
Please read this User＇ s Manual carefully before using this product.
Its factory code is: 1、5、9.
Open the door of the private container (See ＂Using the Override Key＂in Page 2).
Take out the 4AA batteries from the Private Container, and install it in its
compartment. (See＂To Replace the Batteries＂in Page 2.)
Enter the code, then pressing the＂ ＃ ＂ button. The green LED will come on. Turn
the knob clockwise
Close the door of Private Container, then turn the knob counterclockwise
and the door will be locked.
Open the door of Private Container and press the red programming button (See
the Figure) located on the back of the door inside the Private Container, coming
into process of programming the user code (yellow LED will be on).
Enter your new user code (2-8 digits) followed by pressing the ＂ ＃ ＂ button.
JJB-23E2、JJB-23E2 -1 、G1-950N、G1-951N、G1-952N、G1-953N and B-23E2-1
F i r s t T i m e O p e r a t i o n
within 5 seconds to open the door of this Private Container.
Note: The factory code 1、5、9 should be used to open the door of the
Private Container for the first time. Please program your new
user code after the first operation. Refer to ＂To Program Your
User Code＂for details.
The interval between two button pressing operations should not
exceed 20 seconds, otherwise this operation will become invalid.
T o C l o s e
T o P r o g r a m Y o u r U s e r C o d e
Note: Please repeat operating the Private Container with your new user
code according to ＂To Open＂for several times to confirm that
your new user code can open the door. Then close the door and turn
knob counterclockwise
Please keep your new user code in a safe place as the
old code becomes invalid now.
Shanghai Diebold Security Equipment Co., Ltd.
Add. : 1188 Caobao Rd., Shanghai, 201102, P.R. China
Tel : 86-21-6480 1118
Website: http:// www.diebold.cn
T o O p e n
.
Programming Button
Fax : 86-21-6480 1238
1.
,
