MOTINI FAN-CL-0002 Installation And Safety Instructions

Advertisement

Quick Links

• WARNING –To make sure power is off before attempting installation.
• WARNING – Support Directly From Building Structure.
• WARNING –To reduce the risk of fire, electric shock, or injury to persons, unplug or disconnect the
appliance from the power supply before the fan installation, cleaning, or servicing.
• WARNING –To Reduce The Risk Of Fire Or Electric Shock, Do Not Use This Fan With Any Solid-State
Speed Control Device.
• WARNING –To Reduce The Risk Of Personal Injury, Do Not Bend The Blade Brackets When Installing
The Brackets, Balancing The Blades, Or Cleaning The Fan. Do Not Insert Foreign Objects In Between
Rotating Fan Blades.
• The installation is to be in accordance with the National Electrical Code, ANSI/NFPA 70-1999 and local
codes. Consult a qualified electrician if in double.
• WARNING – To Reduce The Risk Of Electric Shock, This Fan Must Be Installed With A General-Use,
Isolating Wall Control/Switch.
• All set screws must be checked, and retightened where necessary, before installation.
• After making the wire connections, the wires should be spread apart with the grounded conductor and
the equipment-grounding conductor on one side of the outlet box and the ungrounded conductor on the
other side of the outlet box.
• The splices after being made should be turned upward and pushed carefully up into the outlet box.
• Conductor of a fan identified as grounded conductor to be connected to a grounded conductor of power
supply, conductor of fan identified as ungrounded conductor to be connected to an ungrounded conductor
of power supply, conductor of fan identified for equipment grounding to be connected to an
equipment grounding conductor.
• CAUTION–To Reduce The Risk Of Electric Shock, Disconnect The Electrical Supply Circuit To The Fan
Before Installing Light Kit.
• WARNING – To reduce the risk of fire, electric shock, or personal injury, mount directly to a
structural framing member of to an outlet box marked (acceptable for fan support of 22.5 kg(50
lbs) or less). For outlet box mounting, use mounting screws provided with the outlet box.
INSTALLATION AND SAFETY INSTRUCTIONS
READ AND SAVE THESE INSTRUCTIONS
SAFETY PRECAUTION
1

Advertisement

loading
Need help?

Need help?

Do you have a question about the FAN-CL-0002 and is the answer not in the manual?

Questions and answers

Summary of Contents for MOTINI FAN-CL-0002

  • Page 1 INSTALLATION AND SAFETY INSTRUCTIONS READ AND SAVE THESE INSTRUCTIONS SAFETY PRECAUTION • WARNING –To make sure power is off before attempting installation. • WARNING – Support Directly From Building Structure. • WARNING –To reduce the risk of fire, electric shock, or injury to persons, unplug or disconnect the appliance from the power supply before the fan installation, cleaning, or servicing.
  • Page 2: Parts And Accessories

    PARTS & ACCESSORIES Canopy Downrod Housing Blade Transmitter Kit Transmitter Transmitter Holder Battery Wall Screw x 2 Wire Connectors x 6 Install the safety cable parts kit Assembly Kit Install the safety cable parts kit Install the hanger parts kit Spring Washers x 4 plastic expansion screw x 1 Spring Washers x 1...
  • Page 3 INSTALLATION INSTRUCTION STEP 1A - OUTLET BOX CEILING SWITCH OFF THE ELECTRICAL MAINS AT THE CIRCUIT BREAKER FUSE BOX. Install the mounting bracket onto outlet box with the 2 Supplied with Outlet Box Screws (2) & Spring Washers (3) & Flat Washers(4) & Antiskid gasket(5).
  • Page 4 INSTALLATION INSTRUCTION...
  • Page 5 INSTALLATION INSTRUCTION STEP 2 1) Remove the hairpin clip (7) and clevis pin (8) from the bottom of the downrod (6). Retain the pin and clip For subsequent installation. 2) Loosen the Screw (1) from Hanger Ball (3), remove the Hanger Ball (3)and Lock Pin (2). 3) Loosen the two set screws (10) in the downrod support of the motor assembly.
  • Page 6 INSTALLATION INSTRUCTION STEP 3 1) Raise the fan and place the hanger ball onto mounting bracket. 2) Rotate the fan until the notch on hanger ball snapped into the slot on mounting bracket and sits firmly. NOTE : THE DOWNROD AND HANGER BALL SHOULD NOT ROTATE IF THIS STEP IS DONECORRECTLY.
  • Page 7 INSTALLATION INSTRUCTION HANGER BLUE GROUND GREEN BRACKET BLACK MOTOR HOUSING WHITE BLACK AC POWER WHITE BLUE BLACK BLACK WHITE STEP 5 WHITE SWITCH OFF THE ELECTRICAL MAINS AT THE CIRCUIT BREAKER FUSE BOX. 1) Connect wires from controller to power supply with wire connectors. 2) Insert the controller into the BLACK ANTENNA...
  • Page 8 INSTALLATION INSTRUCTION Load the battery into the transmitter, turn on the fan power supply and use it properly. ATTENTION To make fan operational, install 6F22 9V battery (included) in hand-held remote transmitter, with fan power off. Then follow the remote code setting process. (If not used for long periods of time, remove battery to prevent damage to transmitter).
  • Page 9: Transmitter Function

    TRANSMITTER FUNCTION FUNCTIONS OF TRANSMITTER --- Turn on ceiling fan at high speed. MED --- Turn on ceiling fan at medium speed. LOW --- Turn on ceiling fan at low speed. OFF --- Turn off ceiling fan. ON/OFF: Press and release immediately to turn on / off the light.
  • Page 10: Technical Specifications

    TECHNICAL SPECIFICATIONS 1000mm Model No. of blades Fan width Light Wattage Voltage FAN-CL-0002 406mm 4 x 4W 110-120V~ 60Hz Nett Gross Speed Amps Wattage weight weight 0.207 25.5 1220 5.86KG 4.46KG 0.202 22.0 1050 0.198 19.0 Specifications & measurements shown are subject to ±10% variations.
  • Page 11: Maintenance

    MAINTENANCE Due to the fan’s natural movement, connections may get loose after a period of usage. To ensure a proper and safety usage, inspect the suspension system and tighten all connections every 6 months. Cleaning Cleaning your fan periodically will prolong its useful life. Basic cleaning procedures are as follows: 1.
