PICNIC BENCH
Garden
Sheds
ASSEMBLY GUIDE
MCD
Ftatpack Assembly Guide
- Picnic Bench assembly manual.................................
- Pre-assembly Care Advise.........................................
- Timber Aftercare Guide...............................................
www.mcdgardensheds.ie
page 2-5
page 6
page 7
Advertisement
Table of Contents
Summary of Contents for MCD PICNIC BENCH
- Page 1 ASSEMBLY GUIDE PICNIC BENCH Ftatpack Assembly Guide - Picnic Bench assembly manual......... page 2-5 - Pre-assembly Care Advise......... page 6 Garden - Timber Aftercare Guide..........page 7 Sheds www.mcdgardensheds.ie...
- Page 2 PICNIC BENCH FLATPACK CONTENT Before you begin, please read ''Assembly and Care Advice", "Pre-Assembly Introduction" - page 10 - BENCH TOP 1x element PAIR OF LEGS 2x element LEGS SUPPORT 2x element BENCH SEAT 2x element SCREWS BAG approx. 45pcs...
- Page 3 ASSEMBLY INSTRUCTION BENCH TOP PAIR OF LEGS LEGS SUPPORT BENCH SEAT EAS Y DIF F I C U L T 2 person recommend www.mcdgardensheds.ie...
- Page 4 PICNIC BENCH ASSEMBLY INSTRUCTION Prepare the elements and tools. Turn the top piece upside down and then combine the double legs to the slats from the outside. Use screwdrivers to join element and screw in bolts at designated places. Then join the support boards. Both boards should fit close together and meet in the middle.
- Page 5 PICNIC BENCH ASSEMBLY INSTRUCTION Secure the supporting boards with screws.Turn the whole structure onto the legs and attach the last two elements. Tighten the screws on the sides.
- Page 6 Also check for any irregularity such as crack, flaw or improperly drilled hole. If there is any problem or missing piece, please contact MCD Garden Sheds. 5. Read the entire instruction manual and view the diagrams first before assembling. Arrange your parts in order of use and group the identical hardware together to make it easier to grab each piece as you begin to assemble.
- Page 7 TIMBER AFTERCARE GUIDE Painting & Varnishing All of our garden structures are fully pressure treated and come with a 10 year anti-rot guarantee. We advise that you protect your building by using a weatherproof preservative or stain within 8 weeks of installation.
- Page 8 Garden Sheds www.mcdgardensheds.ie Tel.: 01 804 1111 email: sales@mcdhomeandgarden.ie West Curragh, Naul, Co.Dublin Post code: K32YV74...
