Summary of Contents for MOORE HANDLEY ABFNC 1/2HP
- Page 1 MERICA'S BES TRADE MARK REG. OWNER’S MANUAL Shallow Well Jet Pumps/Tank Systems Installation • Operation • Parts MOORE HANDLEY, INC. P.O. Box 2607, Birmingham, AL 35202 AB312 (Rev. 5/28/97) PRINTED IN U.S.A.
-
Page 2: General Safety
Safety READ AND FOLLOW ELECTRICAL SAFETY SAFETY INSTRUCTIONS! Capacitor voltage may be hazardous. To discharge motor capacitor, hold insulated handle screw- This is the safety alert symbol. When you see this driver BY THE HANDLE and short capacitor terminals symbol on your pump or in this manual, look for together. -
Page 3: Table Of Contents
Table of Contents Thank you for purchasing a top quality, factory tested pump. Page General Safety .....................2 Installation ......................4,5 Connecting Discharge Piping................6 Electrical ......................7,8 Preparing To Start The Pump................9 Troubleshooting....................10 Repair Parts .......................11 Warranty ......................12 Performance Chart GPH at depth to water Model Disch. - Page 4 Installation REPLACING AN OLD PUMP To Household Pump Priming Water System Tee and Plug Hazardous voltage. Disconnect power to pump before work- ing on pump or motor. Step 1. Drain and remove the old pump. Check the old pipe for scale, lime, rust, etc., and replace it if necessary.
-
Page 5: Installation
Installation To Household Pump Priming Step 4. Install a priming tee, priming plug, and suction pipe to the pump Water System Tee and Plug (see Figure 2). Connect the pipe from the well to the pump suction port, using the fewest possible fittings – especially elbows – as fit- tings increase friction in the pipe (however, include a foot valve –... -
Page 6: Connecting Discharge Piping
Discharge Pipe and Pressure Tank Connections PRE-CHARGE TANK CONNECTION (Figure 4) To Household Pump Priming Water System Tee and Plug Step 1. Install two tees in the pump discharge port (see Figure 4). The pipe size must be at least as large as the discharge port. Step 2. -
Page 7: Electrical
Electrical VOLTAGE CONVERSION Hazardous voltage. Disconnect power at service panel before connecting pressure switch. Series 4000 Series 4100 Figure 6: 115/230 Volt Motor Wiring Connections Through Typical Pressure Switch. Dual voltage motors come factory wired for 230 Volt operation. See Page 8 for Wiring and Grounding The inset shows 115 Volt conversion. - Page 8 Electrical WIRING CONNECTIONS About Grounding NOTICE: Your pump installation must comply with the National Electrical Grounding an electrical device pro- Code (NEC) or Canadian Electrical Code (CEC) and with all local codes tects you, the user, from dangerous that apply. electrical shocks and burns by pro- viding a safe path for the electricity Step 1.
-
Page 9: Preparing To Start The Pump
Preparing to Start the Pump PRIMING Never run pump against closed discharge. To do so can boil water inside pump, causing hazardous pressure in unit, risk of explosion and possibly scalding persons handling pump. Fill pump Never run pump dry. Running pump without water may cause and piping pump to overheat, damaging seal and possibly causing burns to persons through... -
Page 10: Troubleshooting
Troubleshooting SYMPTOM POSSIBLE CAUSE(S) CORRECTIVE ACTION Motor will not run Disconnect switch is off Be sure switch is on. Fuse is blown or circuit breaker tripped Replace fuse or reset circuit breaker. Starting switch is defective DISCONNECT POWER; Replace starting switch. Wires at motor are loose, Refer to instructions on wiring (Pages 7 and 8). -
Page 11: Repair Parts
Repair Parts 2331 0296 REPAIR PARTS LIST ABFNC-02 Part Description Qty. 1/2 HP Motor A100CLL Water Slinger C69-2 Seal Plate Assembly N3-9 Gasket, Seal Plate N20-35 Shaft Seal U109-6A Impeller J105-40P Volute Diffuser L1-25P Gasket, Diffuser N20-34 Pump Body Assembly N176-38 Venturi N32P-66... -
Page 12: Warranty
LIMITED WARRANTY Moore Handley warrants to the original consumer of the products listed below, that they will be free from defects in material and workmanship for the Warranty Period from the date of installation as noted. Product Warranty Period Jet pumps/Tank Systems 3 years 4”...
