Summary of Contents for Ideal Curves Ultimate Contour
-
Page 2: Table Of Contents
Table of Contents 1 - INTRODUCTION ......................3 2 - USE AND SAFETY ......................4 2.1 Indications for Use ..........................4 2.2 Contra-Indications ..........................4 2.3 Training ..............................6 2.4 Device Safety & Compliance ....................... 6 2.5 Performance & Expectations ......................7 3 - DEVICE DESCRIPTION ....................7 3.1 Kit Contents ............................ -
Page 3: Introduction
If at any point you have any questions about the use or application of the Ultimate Contour, feel free to contact a customer service representative at 1-888-861-7211, or visit our website at:... -
Page 4: Use And Safety
2 - USE AND SAFETY PLEASE READ THIS SECTION CAREFULLY BEFORE ATTEMPTING TO HANDLE OR USE THE ULTIMATE CONTOUR SYSTEM. IMPROPER USE CAN CAUSE INJURY 2.1 Indications for Use The Ultimate Contour is intended for 1. Application of non-thermal radio frequency for relief of minor muscle aches and pains, relief of muscle spasm, temporary improvement of local blood circulation, and temporary reduction in the appearance of cellulite. - Page 5 Device contains high-voltage components. Changes or modifications to the equipment not expressly approved by Ideal Curves or described in this manual could void the user’s authority to operate the equipment. Unauthorized alterations may result in electric shock or damage to patient tissues.
-
Page 6: Training
• This product contains no user serviceable parts beyond what is described in this manual. • Failure of the Ultimate Contour to function as designed may result in an unintended increase in power output. • Power surges, or loss of power, may cause this device to momentarily lose power or to behave in an unexpected manner. -
Page 7: Performance & Expectations
Labeling on the handpieces are on the body of each handpiece. Access to and use of the Ultimate Contour should be limited to clinicians and technicians who are properly licensed and trained to use this device, consistent with national and state regulations. When not in use, the unit should be secured to prevent unauthorized access. -
Page 8: Explanation Of Symbols
3.3 Explanation of Symbols Symbols used on the Ultimate Contour device and within this manual indicate important safety informa- tion. These items are now explained: Non-Ionizing Radiation Hazard Type BF Applied Part Dispose of waste electronics responsibly Date of Manufacture Manufacturer information Consult the Owner’s Manual... -
Page 9: Device Unpacking And Setup
When removing the Ultimate Contour unit and accessories, take care to avoid scratching or damaging any of the components. • Remove the Ultimate Contour unit from its packaging, and stand the unit upright on a sturdy table or countertop surface. •... -
Page 10: Device Operation
5.2 Screens and Settings Make sure the Ultimate Contour unit is fully set up, and the desired handpiece is attached. Turn on the power switch on the back of the unit (press the “I” symbol). After a few moments of starting the program- ming, the display will show the Home Screen. - Page 11 • Press the Stop button on the screen. • Press the Safety Stop button on top of the unit (the button will glow red when this is activated). • Press the power switch on the back of the unit to Off (press the “O” symbol). •...
- Page 12 Ultimate Contour and address some fre- quently asked questions. You can also find an electronic version of this Owner’s Manual for the Ultimate Contour. Press on any of the buttons to launch the video, or view the manual. When done viewing the video or manual, press the Back button at upper left to return to the Media Screen.
-
Page 13: Radio Frequency Treatment
200Ω 400Ω 800Ω The Ultimate Contour is designed to have the RF signal travel between two of the three nodes on the handpiece. The system alternates which two nodes are active, changing the active nodes in a circular pattern about once per second. Between the two active nodes, the RF energy travels from one node to the other. -
Page 14: Ultrasound Treatment
5.4 Ultrasound Treatment Some patients may “hear” the ultrasound or experience a ringing sensation in their ears. Inform them ahead of time that this may occur, and to indicate if it becomes uncomfortable. Some patients may experience vertigo if they get up too quickly after the ultrasound treatment. -
Page 15: Cleaning And Maintenance
CAUTION: Ensure the alcohol has fully evaporated before using. 6.2 Unit Cleaning The surfaces of the Ultimate Contour unit and cords may be cleaned using a towel or cloth moistened with a solution of warm water mixed with soap or a mild, non-abrasive detergent. Before cleaning the unit, make sure to unplug the power supply cord from the wall outlet. -
Page 16: Fuse Replacement
Product), is warranted against defective materials and workmanship for a period of one (1) years from the date of purchase. If the Product is leased from Ideal Curves or from any of its authorized distributors, consult your lease agreement for the terms and conditions of Product repair and/or replacement. Repair and/or replacement shall occur as directed by Ideal Curves or the authorized distributor. - Page 17 If you are having trouble with the Ultimate Contour system, have questions regarding its use, or need to order replacement parts, feel free to contact a customer service representative at Ideal Curves (1-888-861- 7211) or at the distributor from whom you obtained the system.
-
Page 18: Troubleshooting
8 - TROUBLESHOOTING A number of commonly encountered issues are addressed in this section. It is recommended that you review these suggestions and follow directions to correct an issue before contacting customer service. PROBLEM SOLUTION The screen is dark - nothing is showing. Make sure the power cord is attached and plugged in. -
Page 19: Specifications
9 - SPECIFICATIONS 9.1 Unit Technical Specifications Ultimate Contour (Model: 005-00036) Weight Dimensions • Ultimate Contour 5.0 lbs • Ultimate Contour 13.75” x 14.5” x 14” Power Input Requirements 100-240 VAC @ 50-60Hz, 1.8A Audible and Visual Notification Medical Electrical Equipment Classification... -
Page 20: Electromagnetic Compatibility
Fluctuations/ Flicker emissions The Ultimate Contour is suitable for use in all establishments other than domestic and those directly connected to the public low- voltage power supply network that supplies buildings used for domestic purposes Guidance and manufacturer’s declaration – electromagnetic emissions The Ultimate Contour is intended for use in the electromagnetic environment specified below. - Page 21 RF transmitters, an electromagnetic site survey should be considered. If the measured field strength in the location in which the Ultimate Contour is used exceeds the applicable RF compliance level above, the Ultimate Contour should be observed to verify normal operation. If abnormal performance is observed, additional measures may be necessary, such as reorienting or relocating the Ultimate Contour.
- Page 22 RF communications equipment and the Ultimate Contour The Ultimate Contour is intended for use in an electromagnetic environment in which radiated RF disturbances are controlled. The customer or the user of the Ultimate Contour can help prevent electromagnetic interference by maintaining a minimum distance between portable and mobile RF communications equipment (transmitters) and the Ultimate Contour as recommended below, according to the maximum output power of the communications equipment.
- Page 23 THIS PAGE INTENTIONALLY LEFT BLANK...
- Page 24 1-888-861-7211 Manufactured for Ideal Curves, LLC. CAO Group 4628 West Skyhawk Dr. West Jordan, UT 84084 www.ultimate-contour.com...
