RE451
Cat No.
Assembly Instructions - Please keep for future reference
Hampstead Rattan Lounger
No. People
Assembly Time
15 - 30
Minutes
Important - Please read these instructions fully before starting assembly
If you need help or have damaged or missing parts, call the JDW customer helpline: 0871 231 2000
Advertisement
Related Manuals for N BROWN Hampstead RE451
Summary of Contents for N BROWN Hampstead RE451
- Page 1 RE451 Cat No. Assembly Instructions - Please keep for future reference Hampstead Rattan Lounger No. People Assembly Time 15 - 30 Minutes Important - Please read these instructions fully before starting assembly If you need help or have damaged or missing parts, call the JDW customer helpline: 0871 231 2000...
- Page 2 Safety and Care Advice Important - Please read these instructions fully before starting assembly • Check you have all the • Make sure you have • We do not recommend the components and tools enough space to lay out use of power listed on the next pages.
-
Page 3: Exploded View
Exploded View... -
Page 4: Components - Fixings
Components - Panels Please check that you have all the components listed below before constructing your item. Part No Description Components - Fixings Please check that you have all the components listed below before constructing your item. M6x50mm Tools Required Allan Key Ruler - Use this to measure your screws (mm) - Page 5 Assembly Instructions Note: All Bolt Head Caps and Nut Caps should not be attached before finally tightening all Bolts with the Allen Key. Only tighten all bolts when you are satisfied with the alignment of all components. Step 1 • Fasten the leg tubes (Part B and Part C) with the seat part (Part A)
